ADJUSTING THE SCALE

The scale setting is displayed above the graph. You can adjust the
scale to provide the best view of the carrier levels by pressing the
soft key. A new set of soft keys appears. Use the
soft keys to increment and decrement the scale value. Press the
soft key when you have finished.

CHECKING LIMITS

You can verify that the carrier levels are within limits. First, you
need to tell microStealth which test point you are at. This deter-
mines which set of limits are used. Press the
sequence through the available test points. The test point that you
have selected is represented in the upper portion of the screen by
one of the following icons:
Note
Be sure that you have enabled all of the test points that you are
interested in using. The
more than one enabled test point. (see EDIT TEST POINTS).
When you have selected the proper test point, microStealth shows
the minimum and maximum carrier level limits for that test point
on the graph. The out-of-limit portions appears as diagonal "hash"
areas. You can toggle the hash lines on and off by pressing the
key.
42
Subscriber Drop
Ground Block
Tap
User Defined
soft key is only available if there is
and
soft key to
