- Page 1 Crestron DA-1700CW Docking Assembly for STX-1700CW/CXPW Operations and Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron DA-1700CW Contents Docking Assembly for STX-1700CW/CXPW: DA-1700CW Introduction ... 1 Functions and Features ... 1 Specifications ... 2 Physical Description... 2 Industry Compliance ... 5 Setup ... 5 Network Wiring... 5 Identity Code ... 6 Installation ... 7 Programming Software ... 9 Earliest Version Software Requirements for the PC ... -
Page 5: Docking Assembly For Stx-1700Cw/Cxpw: Da-1700Cw
STX-1700CW/CXPW: DA-1700CW Introduction Functions and Features The DA-1700CW docking assembly is wall-mounted hardware that is used to dock a Crestron BB-1700CW back box (sold separately), the DA-1700CW provides operating power, hard-wire communications with a standard Crestron remote control system (herein referred to as the Cresnet Rechargeable Power Pack (ST-BTPN) of the docked touchpanel. -
Page 6: Specifications
.exe files containing the .cuz or .upz file. All can be obtained from the Downloads section of the Crestron website. To avoid program problems, make sure you are using the update file with the correct suffix letter (e.g., S, V, W, X) Operations and Installation Guide - DOC. - Page 7 Crestron DA-1700CW Docking Assembly for STX-1700CW/CXPW DA-1700CW Physical View Manual Release DA-1700CW Dimensions 5.57 in (14.14 cm) 3.56 in (9.05 cm) 6.51 in (16.54 cm) Docking Assembly for STX-1700CW/CXPW: DA-1700CW • 3 Operations and Installation Guide - DOC. 6104A...
- Page 8 Docking Assembly for STX-1700CW/CXPW Front View Components RECHARGE POWER) Side View (with Partial Cut-Away) Components UNLATCH Rear View Components 4 • Docking Assembly for STX-1700CW/CXPW: DA-1700CW TOUCHPANEL LATCHING HOOKS ELECTRICAL CONTACTS (CRESNET Y DATA & Z DATA) ELECTRICAL CONTACTS (OPERATING &...
-
Page 9: Industry Compliance
Cresnet power usage of the entire chain. If the unit is a home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. -
Page 10: Identity Code
Refer to “Setting the Net ID in Device Settings” on page 11 for details of the SIMPL Windows procedure. The Net ID of the DA-1700CW is factory set to 51. The Net IDs of multiple DA-1700CWs in the same system must be unique and changed from a personal computer (PC) via Crestron Viewport. -
Page 11: Installation
9. In the "Set Network ID" window, click Close. 10. Repeat this procedure for each DA-1700CW to be added to the system. 1. Position the DA-1700CW to the back box and connect the Cresnet wiring to the rear port using the supplied connector. The rear port connections are shown in the following graphic. - Page 12 8 • Docking Assembly for STX-1700CW/CXPW: DA-1700CW 3. As shown in the following illustration, position the front panel to the DA-1700CW. Install four hex screws (supplied) to finger-tight then, using a 5/64-inch hex wrench, tighten an additional 1/8-turn. Operations and Installation Guide - DOC. 6104A...
-
Page 13: Programming Software
Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com/. -
Page 14: Programming With Simpl Windows
It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. SIMPL Windows offers drag and drop functionality in a familiar Windows NOTE: The following assumes that the reader has knowledge of SIMPL Windows. - Page 15 PRO2 C2Net-Device slot in System Views. The System Views upper pane displays the BB/DA-1700CW device icon below the PRO2 graphic. The PRO2 system tree displays the BB/DA-1700CW in Slot 9, with a default Net ID of 51. Refer to the graphic below.
- Page 16 BB/DA-1700CW Symbol in Programming Manager Programming Manager is where programmers “program” a Crestron control system by assigning signals to symbols. The graphic below shows the BB/DA-1700CW symbol in the Detail View of the Programming Manager. Detail View of the BB/DA-1700CW Symbol in SIMPL Windows’ Programming Manager NOTE: All signals listed in the tables below and on the next page are DIGITAL signals unless noted otherwise.
-
Page 17: Operation
The DA-1700CW docks the touchpanel, provides power and communication, and recharges the ST-BTPN. Operation consists of docking the touchpanel (performed by hand) into the DA-1700CW or undocking electrically via the control system and then removing by hand. Docking the Touchpanel To dock the touchpanel, refer to the procedure below. -
Page 18: Undocking The Touchpanel
Dock Touchpanel Undocking the Touchpanel During normal operation, the DA-1700CW unlatches the touchpanel electrically via the control system program. When the touchpanel is unlatched, it snaps outward slightly, and then may be removed by hand. The control system program defines the method (i.e., touchpanel button) of unlatching. - Page 19 3. As shown below, lower the handle of the screwdriver until the touchpanel unlatches (handle of screwdriver will be approximately level and touchpanel will snap outward slightly). Docking Assembly for STX-1700CW/CXPW: DA-1700CW • 15 ) until the tip of the screwdriver...
-
Page 20: Problem Solving
Re-Install Access Hole Plug Problem Solving Troubleshooting The table below and continued on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. DA-1700CW Troubleshooting The DA-1700CW does not unlatch the touchpanel. - Page 21 For further information, refer to the latest revision of the ST-BTPN Installation Guide (Doc. 6088). The latest version can be obtained from the Crestron website. For further information, refer to the latest revision of the BB-1700CW Installation Guide (Doc. 6105). The latest version can be obtained from the Crestron website.
-
Page 22: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 23: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 24 Crestron Electronics, Inc. Operations and Installation Guide – DOC. 6104A 15 Volvo Drive Rockleigh, NJ 07647 03.05 Tel: 888.CRESTRON (2002117) Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
