- Page 1 Crestron TPS-6X-DSC-LP Low-Profile Desktop Docking Station for TPS-6X (Charging Only) Installation Guide...
-
Page 2: Regulatory Compliance
CE marking and standards per EMC and Radiocommunications Compliance Labelling. Crestron, the Crestron logo and Isys are trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and other countries. Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. -
Page 3: Table Of Contents
Crestron TPS-6X-DSC-LP Low-Profile Docking Station for TPS-6X Contents Low-Profile Desktop Docking Station for TPS-6X (Charging Only): TPS-6X-DSC-LP Description..........................1 Features and Functions ....................1 Specifications ......................2 Physical Description....................3 Setup ............................5 Hardware Hookup ....................... 5 Recommended Cleaning....................5 Resources........................... -
Page 5: Low-Profile Desktop Docking Station For Tps-6X (Charging Only): Tps-6X-Dsc-Lp
Station for TPS-6X (Charging Only): TPS-6X-DSC-LP Description The TPS-6X-DSC-LP is an optional desktop docking station designed for charging the Isys™ TPS-6X Wireless Touchpanel. Its angled cradle enables full wireless touchpanel operation while charging. A single connector is provided at the rear of the docking station for connection of the wall mount power pack (included). -
Page 6: Specifications
Low-Profile Docking Station for TPS-6X Crestron TPS-6X-DSC-LP Specifications Specifications for the TPS-6X-DSC-LP are listed in the following table. TPS-6X-DSC-LP Specifications SPECIFICATION DETAILS Power Requirements Power Pack 0.75 Amps @ 24 Volts DC; 100-240 Volts AC, 50/60 Hz power pack, included... -
Page 7: Physical Description
Low-Profile Docking Station for TPS-6X Physical Description This section provides information on the connections, controls and indicators available on your TPS-6X-DSC-LP. TPS-6X-DSC-LP Physical View TPS-6X on TPS-6X-DSC-LP Low-Profile Docking Station for TPS-6X: TPS-6X-DSC-LP • 3 Installation Guide – DOC. 7143A... - Page 8 CONTROLS & INDICATORS TOUCHPANEL (1) 10-pin connector for connecting to CONNECTOR touchpanel POWER (1) 2.1 mm barrel DC power jack; 24 Volt DC power input; Power supply included 4 • Low-Profile Docking Station for TPS-6X: TPS-6X-DSC-LP Installation Guide – DOC. 7143A...
-
Page 9: Setup
Crestron TPS-6X-DSC-LP Low-Profile Docking Station for TPS-6X Setup Hardware Hookup The only connection to the TPS-6X-DSC-LP is for the included 24 Volt power pack. When connecting the TPS-6X-DSC-LP, consider the following: • ® Use Crestron power supplies for Crestron equipment. -
Page 10: Resources
Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron Web site (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 11: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 7143A 15 Volvo Drive Rockleigh, NJ 07647 (2029615) Tel: 888.CRESTRON 03.11 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
