- Page 1 Crestron TPMC-10-DSW Docking Assembly for TPMC-10 Operations and Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron TPMC-10-DSW Docking Assembly for TPMC-10 Contents Docking Assembly for TPMC-10: TPMC-10-DSW Introduction ..........................1 Functions and Features ....................1 Specifications ......................2 Physical Description....................2 Industry Compliance ....................4 Setup ............................4 Network Wiring......................4 Identity Code ....................... 5 Installation ........................ -
Page 5: Docking Assembly For Tpmc-10: Tpmc-10-Dsw
TPMC-10-DSW Introduction Introduction Functions and Features ® The TPMC-10-DSW is a wall-mounted docking station for the Crestron TPMC-10 ™ Isys i/O WiFi Touchpanel. The TPMC-10-DSW, recessed in the wall, turns the TPMC-10 into a fully-functioning wall mounted touchpanel, and charges its built-in battery at the same time. -
Page 6: Specifications
Weight: 11.0 lb (5.0 kg) Includes power for the touchpanel. The latest versions can be obtained from the Crestron website. Refer to NOTE after last footnote. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product Catalog for a complete list of 2-Series control systems. - Page 7 Turns on only if the touchpanel is properly inserted in the cradle and plugged into the interface connector. Audio Transducer (Internal) Generates an audible beep when the unit’s buttons are pressed. Docking Assembly for TPMC-10: TPMC-10-DSW • 3 Operations and Installation Guide - DOC. 6400...
-
Page 8: Industry Compliance
Cresnet power usage of the entire chain. If the unit is a home-run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable length value on the equation’s left side. -
Page 9: Identity Code
10 for details of the SIMPL Windows procedure. The Net ID of the TPMC-10-DSW is factory set to 22. The Net IDs of multiple TPMC-10-DSWs in the same system must be unique and changed from a personal computer (PC) via the Crestron Toolbox software program. -
Page 10: Installation
Docking Assembly for TPMC-10 Crestron TPMC-10-DSW Installation To install the TPMC-10-DSW, complete the following procedure in the order provided. Tools required are a #2 Phillips screwdriver and a 9/64-inch Allen wrench. NOTE: The TPMC-1-DSW is designed for mounting in a vertical configuration only. - Page 11 Routing and Attaching the Cresnet Cable Terminal Block Connector PC Board Tie-Wrap Grommet 5. As shown in the following illustration, position the TPMC-10-DSW into the wall opening. Secure it to the wall using four screws A (not supplied). Installing the TPMC-10-DSW Screws A Latch...
-
Page 12: Programming Software
Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website (www.crestron.com). To post your own question or view questions you have submitted to Crestron’s True Blue Support, log in at http://www.crestron.com/accounts/login.asp. First-time users will need to establish a user account. -
Page 13: Programming With The Crestron Systembuilder
The Crestron SystemBuilder then programs the system, including all touchpanel projects and control system logic. The Crestron SystemBuilder is fully integrated with Crestron's suite of software development tools, including SIMPL Windows, VT Pro-e, Crestron Database, User IR Database, and User Modules Directory. The Crestron SystemBuilder accesses these tools behind the scenes, enabling you to easily create robust systems. - Page 14 Other Modules subfolder of the Touchpanels folder in the Device Library and drop it on the Cresnet Units symbol in System Views. The MC2E system tree displays the TPMC-10-DSW in C2Net-Device, Slot 1, with a default Net ID of 22, as shown in the following graphic.
-
Page 15: Example Program
Detail View. A description for each signal in the symbol is provided in the SIMPL Windows help file (F1). Example Program An example program for the TPMC-10-DSW is available from the “Example Program” section of the Crestron website (http://www.crestron.com/exampleprograms . -
Page 16: Operation
(0.64 cm) (0.64 cm) 2. Insert the bottom edge of the touchpanel into TPMC-10-DSW cradle so that it engages the interface connector, and push the touchpanel back to rest against the plate. Note that the magnets hold the touchpanel in position. The green LED in the upper right corner of the docking station illuminates indicating that the touchpanel is present and mated with the connector. -
Page 17: Undocking The Tpmc-10
NOTE: Between steps and button pushes, the docking station remains in pass code entry mode. If five seconds elapse without completing the pass code entry, the setup mode is exited and the existing pass code is retained. Docking Assembly for TPMC-10: TPMC-10-DSW • 13 Operations and Installation Guide - DOC. 6400... -
Page 18: Problem Solving
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 19: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 20 Crestron Electronics, Inc. Operations Guide - DOC. 6400 15 Volvo Drive Rockleigh, NJ 07647 (2013787) Tel: 888.CRESTRON 10.05 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
