- Page 1 Crestron IDOC-PAD-DSWC and IDOC-PAD2-DSWC ™ ® iPanel In-Wall Docking Stations for iPad Operations & Installation Guide...
- Page 2 Inc. in the United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
-
Page 3: Table Of Contents
Crestron IDOC-PAD(2)-DSWC iPanel™ In-Wall Docking Stations Contents ® iPanel™ In-Wall Docking Stations for iPad IDOC-PAD-DSWC and IDOC-PAD2-DSWC Introduction ..........................1 Features and Functions ....................1 Specifications ......................2 Physical Description....................3 Setup ............................6 Wiring.......................... 6 Mounting Options......................6 Installation ........................6 Docking Station Removal.................... -
Page 5: Ipanel™ In -Wall Docking Stations For Ipad : Idoc-Pad-Dswc And Idoc -Pad2-Dswc
Available in smooth white or black finishes 1. The iPad is not included. For the original iPad, use model IDOC-PAD-DSWC. For the iPad 2 or iPad (3rd generation), use model IDOC-PAD2-DSWC. To convert the IDOC-PAD-DSWC to an IDOC-PAD2-DSWC, use the IDOC-PAD-DSW_CONVERSION_KIT (sold separately). For instructions on installing the conversion kit, refer to the latest version of the IDOC-PAD- DSW_CONVERSION_KIT Installation Guide (Doc. -
Page 6: Specifications
2, or the new iPad generation). For the original iPad, use model IDOC-PAD-DSWC. For the iPad 2 or iPad (3rd generation), use model IDOC-PAD2-DSWC. To convert the IDOC-PAD-DSWC to an IDOC-PAD2-DSWC, use the IDOC-PAD-DSW_CONVERSION_KIT (sold separately). -
Page 7: Physical Description
In-Wall Docking Station for iPad 2 and iPad (3 generation), Smooth White Available Accessories Crestron Mobile Pro G Control App for Apple iPad IDOC-PAD-DSW _ Conversion Kit for IDOC-PAD-DSWC CONVERSION KIT IDOC-PAD-DSW-FPLT Faceplate for Left-Hand Installation PMK-IDOC-PAD-DSW Pre-Construction Wall Mount Kit Power Pack... - Page 8 In-Wall Docking Stations Crestron IDOC-PAD(2)-DSWC iPanel Overall Dimensions (Front and Side Views with Faceplate, Mounting Clips Not Shown) 11.2 9 in 0.24 in (287 (7 mm) 8.61 in 9.54 in (219 mm) (243 mm) .75 in (70 mm) iPanel Overall Dimen...
- Page 9 Crestron IDOC-PAD(2)-DSWC iPanel™ In-Wall Docking Stations Connectors, Controls & Indicators CONNECTORS*, DESC RIPTION CONTROLS & INDICATORS Dock Connection (1) M ulti-pin connector for connection of iPad. POWER INPUT 24 VDC (1) 2-pin 3.5 mm detachable terminal block; 24 Volt DC power input;...
-
Page 10: Setup
Provide sufficient power to the system. CAUTION: Insufficient power can lead to unpredictable results or damage to the equipment. Use the Crestron Power Calculator to help calculate how much power is needed for the system (www.crestron.com/calculators). For more details, refer to “Check Wiring” on page 13. - Page 11 Crestron IDOC-PAD(2)-DSWC iPanel™ In-Wall Docking Stations other is similar to a frame, with the inner area of the frame the shape of the required ing (r efer to the illustration s below and on pag e 8). Use the template t...
- Page 12 Refer to the latest v ersion of the PMK-IDOC-PAD-DSW Installation Guide (Doc. 7088) which is available from Crestron Web site (www.crestron.com/manuals). 8 iPanel™ In-Wall Docking Station: IDOC-PAD(2)-DSWC Operations & Installation Guide – DOC. 7084B...
-
Page 13: Docking Station Removal
Install the Faceplate The iPanel ships with a faceplate for use in right-hand installations only. For left-hand installation, the IDOC-PAD-DSWC-FPLT (sold separately) must be used. Install the faceplate as follows: 1. Carefully position the faceplate over the face of the docking station. -
Page 14: Hardware Hookup
Refer to “Wiring” on page 6 before attaching the 2-position terminal black connector. Apply power after the connection has been made. When making the connection to the iPanel, use a Crestron power supply. Hardware Connections for the iPanel (Rear View) -
Page 15: Operation
Crestron IDOC-PAD(2)-DSWC iPanel™ In-Wall Docking Stations Operation iPad Sleeve docking station contains a retractable sleeve that provides a power connection for th e iPad while also providing a flush-mount appearance. The sleeve is moved m the “open” position to the “closed” p osition by pushing the sleeve. -
Page 16: Remove The Ipad
In-Wall Docking Stations Crestron IDOC-PAD(2)-DSWC 2. Push the sleeve to make the sleeve flush with the wall. Remove the iPad To remove the iPad from the dock: Push the sleeve to make the sleeve pop out of the wall. -
Page 17: Problem Solving
Cresnet power usage of the entire chain. If the unit is run from a Crestron system power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable length value on the equation’s left side. -
Page 18: Reference Documents
Check the Crestron Web site periodically for manual update availability and its relevance. Updates are identified as an “Addendum” in the Download column. -
Page 19: Return And Warranty Policies
(property or economic damages inclusive) arising from the sale o r use of this equipment. Crestron is not liable for any claim made by a third par ty or made by the purchase r for a third party. - Page 20 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 7084B 15 Volvo Drive Rockleigh, NJ 07647 (2030457) Tel: 888.CRESTRON 06.12 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
