Crestron CNWM-LT9
CAUTION: Excess wire that is pinched between the keypad and electrical box could short-
circuit. Make sure that all excess wire is completely inside the electrical box and not between
the box and the keypad.

Identity Code

Every user interface within the Cresnet network requires a unique network identity code (NET
ID). These codes are recognized by a two-digit hexadecimal number from 03 to FE. The NET
ID of the keypad must match an ID code specified in the SIMPL Windows program. The NET
ID of the CNWM-LT9 is factory set to 4D. The NET IDs of multiple keypads must all be
unique and changed from a personal computer (PC) via VisionTools™ Pro-e (VT Pro-e) or
SIMPL Windows.
NOTE: VT Pro-e is a Windows compatible software package for creating Crestron touchpanel
screen designs.
The method for changing the unit's NET ID is identical regardless of the software chosen.
Attach one of the keypads to the control system (verify that the software is running) and
complete the following steps to change the NET ID:
Operations & Installation Guide - DOC. 5785
4. Make sure the LEDs are oriented above the keypad buttons and position the
keypad into the electrical box.
5. Install the keypad into the electrical box. (Mounting screws are not provided.)
6. Make sure that the LED openings of the magnetic faceplate are aligned with
the LEDs and install the faceplate.
7. Turn Cresnet system power ON.
1. Disconnect all Cresnet devices from the control system, except for the keypad
that needs to have its NET ID changed.
2. Select Tools | Viewport to open the "Crestron Viewport" dialog box.
3. Select Functions | Set Network ID. The software checks the baud rate and
then opens the "Set Network ID" dialog box.
4. In the "Set Network ID" dialog box, highlight the keypad.
5. The NET ID of the keypad appears in the box below the list. Use the scroll
arrow to assign another NET ID.
6. When the assigned NET ID appears, select the Set ID button to initiate the
change.
7. The software responds with a successful message to confirm the changed NET
ID.
8. To verify this procedure, select Diagnostics | Report Network Devices.
Confirm that the keypad has a new NET ID code.
9. Reconnect other Cresnet devices that were disconnected in step 1.
®
LiteTouch
LiteTouch® Keypad: CNWM-LT9
Keypad
5
