CRESTRON CNWM-29A

SYNTAX:

NET.ID <10 to FE>: CNWP
i1,o1 = <signal name>
i2 = <signal name>
o2 = <signal name>
" = " "
" = " "
i29 = <signal name>
o29 = <signal name>

DESCRIPTION:

The CNWM-29A wired panel interfaces to a CRESNET II control system over the CRESNET II network. The panel uses 29
miniature pushbuttons. The CNWM-29A is designed for wall-mounting using a standard double-gang electrical box. Custom
panel finishes, engraving, colored button caps, and the omission of unused buttons are all standard. Custom inter-mixing of
buttons with and without self-contained feedback LED's is standard.
Each unique panel or component on the CRESNET II network requires the setting of an identity code (ID CODE). ID CODES
are two-digit hexadecimal numbers, from 10 to FE. The ID CODE of the panel should be set to match the ID CODE specified in
the NET.ID statement of the CRESNET II SIMPL-C program referencing the panel (see syntax above). To set an ID CODE,
remove the panel from the electrical box and disconnect power.
Accessible through the back plate are two miniature circuit-mounted rotary switches, identified as H and L. These 16-
position hexadecimal switches can be set to 0 through F. Using a small screwdriver, rotate the arrow in the center of the
R E M O T E C O N T R O L S Y S T E M S
1 2
26
6 7
27
11 12
28
16 17
29
21 22
CRESTRON
\ button and LED combined
\ independent button
\ independent LED
Wall-Mount Wired Panel
3 4 5
8 9 10
13 14 15
18 19 20
23 24 25
1 DOC. 8000B
