Programming with SIMPL™ Windows
SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use programming
language that is completely integrated and compatible with all Crestron system hardware. The
objects that are used in SIMPL Windows are called symbols. SIMPL Windows offers drag and
drop functionality in a familiar Windows environment.
SIMPL Windows is Crestron Electronics' software for programming Crestron control systems.
It provides a well-designed graphical environment with a number of workspaces (i.e.,
windows) in which a programmer can select, configure, program, test, and monitor a Crestron
control system.
The next two sections describe a CNWM-LT9 within a SIMPL Windows program. The first
section details the SIMPL symbol and the second section describes how an example program
works by using a textual description and a block diagram.
NOTE: The following descriptions assume that the reader has knowledge of SIMPL
Windows. If not, refer to the extensive help information provided with the software.

CNWM-LT9 Symbol

The diagram below shows the CNWM-LT9 symbol. The symbol contains nine button press
outputs and nine feedback indicator inputs. Refer to "CNWM-LT9 Physical Views" on page 2
for the actual button layout.
Detail View of the CNWM-LT9 Symbol in SIMPL Windows' Programming Manager

How the Example Program Works

NOTE: There is no need to recreate the example SIMPL Windows program. The program is
available from the Software Downloads page (EXAMPLES Library) of Crestron's website
(www.crestron.com). Search for CNWM-LT9.SMW. New users are required to register in
order to obtain access to the FTP site.
