Crestron CNWM-LT9

Leading Specifications

The table below provides a summary of leading specifications for the CNWM-LT9.
Dimensions and weight are rounded to the nearest hundredth unit.
Leading Specifications of the CNWM-LT9
SPECIFICATION
Power Requirements
Default Network ID
SIMPL Windows
CNMXS-AV/Pro Upgrade File
CNRACKX/-DP Upgrade File
Dimensions & Weight
1 The latest software versions can be obtained from the Downloads page (SIMPLWIN
Library) of Crestron's website (www.crestron.com). New users are required to register in
order to obtain access to the FTP site.
2 CNX upgrade files are required for either CNMSX-AV/Pro or CNRACKX/-DP.
Filenames for upgrade files have a UPZ extension and can be obtained from the
Downloads page (OPSYS Library) of Crestron's website
3 The depth of the keypad is listed without the Cresnet connector (approximately 0.45 in,
1.14 cm) plus clearance for the wiring.
As of the date of manufacture, this unit has been tested and found to comply with
specifications for CE marking:
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including that may cause undesired operation.

Setup

Network Wiring

NOTE: If making category 5 wire connections, refer to the latest revision of the Cresnet Mini
Network Cat 5 Interconnect Drawing (Doc. 5819). The document can be obtained from the
Downloads page (CABLES and MANUALS Libraries) of Crestron's website
(www.crestron.com). Search for the CAT5.PDF file.
Operations & Installation Guide - DOC. 5785
DETAILS
24VDC Cresnet power, load factor of
six (6) Watts.
4D
Version 1.30.01 or later
update files smwlib62.exe and
1
smwlib62.txt or later.
Version 50135X.UPZ or later
Version 50706W.UPZ or later
Height: 4.60 in (11.68 cm)
Width: 2.83 in (7.19 cm)
Depth: 1.15 in (2.92 cm)
Weight: 7.30 oz (0.21 kg)
.
LiteTouch® Keypad: CNWM-LT9
®
LiteTouch Keypad
1
with library
2
2
3
3
