1. INITIAL CHECK AND GENERAL INFORMATION

Thank you for choosing the GSM control box for the BODET lockdown alert. This product has been carefully designed
for your satisfaction according to the rules of the ISO9001 and ISO14001 quality system.
We recommend that you read this manual carefully before installing the product.
Keep this manual for the life of your product so that you can refer to it whenever necessary.
Any use not in accordance with these instructions may cause irreversible damage and invalidate the warranty.
BODET cannot therefore be held responsible.
Non-contractual data. BODET reserves the right to make certain functional, technical or aesthetic changes to the
products without prior notice.
This manual is subject to change without notice.
To obtain the latest version of this documentation, please visit our website: www.bodet-time.com.

1.1 Introduction

With the GSM control box, up to 50 telephone numbers can be defined to:
- Trigger up to 3 types of alert by telephone call, including, for example, the lockdown intrusion alert: connected to
an external input (3-input option card) of the Sigma master clock or to the control box of the stand-alone Melodys
lockdown pack*, the GSM control allows audio systems (Harmonys or Melodys or Sigma Sound) to be controlled,
- Receive a warning SMS in case of triggering for 2 types of alarms, including, for example, lockdown intrusion: in
case of an alarm on an input of the GSM control box (activated by a relay output of the Sigma master clock or
another system), an SMS will be sent to the programmed telephone numbers.
*In this case, only one input and one output can be used.
The GSM control box is set by SMS.
This device cannot be the only means of triggering a lockdown alert. A wired control solution must be present on site.

1.2 How it works

GSM control box
(ref.: 907 557)
gSM control system
Eco-system

1.3 Unpacking the product

Carefully unpack the product and check the contents of the package. This must include:
- the GSM control pre-wired to the OUT1 output and the IN4 alarm input with a 2-pair cable,
- a 3-pair cable to connect other inputs/outputs as required,
- the GSM antenna with its 3 metre long cable,
- this manual.
SMS
230V
ANTENNA
OR
HARmonys
External input of the Sigma master clock
3-input expansion card
OR
melodys
Eco-system
AUX AUX
LOC LOC
melodys
Eco-system
