3.3.4. Setting the OUT relays

Steps Command to be sent by SMS
16
SET NAMEOUT1
17
SET INCALL1
18
SET NAMEOUT2
19
SET INCALL2
20
SET NAMEOUT3
21
SET INCALL3

3.3.5. Setting the IN alarm inputs

Steps Command to be sent by SMS
22
SET NAMEIN4
23
SET IN4 LH
24
SET NAMEIN5
25
SET IN5 LH

3.3.6. Activation and setting of the alarm

Steps Command to be sent by SMS
26
ALARM ENABLE
27
SET IDLEALARM

3.3.7. Adding contacts

The following step must be repeated for each of the contacts you wish to save in each of the groups.
Please make sure that the contact name (PERSON_NAME) is short (max 10 characters, no spaces
allowed).
Use the same contact name if the contact is registered in 2 groups (the only combination allowed is: G5 +
one other group). It should then be added once to each group.
Telephone numbers must be entered in international format.
Steps Command to be sent by SMS
SET TEL +33xxxxxxxxx
28
PERSON_NAME
NEWNAME #PINcode
2 #PINcode
NEWNAME #PINcode
2 #PINcode
NEWNAME #PINcode
2 #PINcode
NEWNAME #PINcode
1 #PINcode
NEWNAME #PINcode
1 #PINcode
#PINcode
1 #PINcode
GX
#PINcode
Description
Setting the name of output OUT1
(max 10 characters).
Example: newname = Intrusion
Configuration of relay OUT1.
Setting the name of output OUT2
(max 10 characters).
Example: newname = Lockdown
Configuration of relay OUT2.
Setting the name of output OUT3
(max 10 characters).
Example: newname = Flood
Configuration of relay OUT3.
Description
Setting the name of the IN4 alarm input that will appear on
the SMS when the corresponding alert is activated (max
10 characters). Example: newname = Intrusion
Configuration of the IN4 input.
Setting the name of the IN5 alarm input that will appear on
the SMS when the corresponding alert is activated (max
10 characters). Example: newname = Lockdown
Configuration of the IN5 input.
Description
Activation of alarm sending.
Alarm configuration.
Description
Adding a contact (number + name) to the GX group.
(X= 1,2,3,4,5). Replace GX with G1, G2, G3, G4 or G5
depending on the rights you wish to assign to the
contact.
Example:
SET TEL +33xxxxxxxxx
will add the contact "Luc Robin" to group 1.
This contact will therefore have the rights attached to group G1.
EN
G1 LUC_ROBIN #PINcode
