1.5.1.1 Using the "Stop / Reset" button

This button allows several actions to be performed on the product in correlation with the Error/Info LED.
Action
Block triggering
of alerts
(BLOCK mode activated)
Unblock triggering
of alerts
(BLOCK mode disabled)
Reset the product.
Reset to factory
configuration
(loss of configuration)**.
* This action causes a warning SMS to be sent to the contacts programmed in the configuration.
* Returning to factory settings will return the unit's default PIN code: 1513. The SIM card PIN code, on the other
hand, does not change.

1.5.1.2 Behaviour of the LEDs

The behaviour of the LEDs can be interpreted as follows:
LED(s) Colour
Error/Info Red
GSM Green
32V IN4
Green
32V IN5
OUT1
OUT2 Orange
OUT3
1.5.2.

General operation

The INCALL(1/2/3) functions linked to the OUT(1/2/3) relay outputs respectively allow the remote triggering of an
alert or event by an incoming call. To do this, the call must be made to the SIM card number in the GSM control from
a registered number with the appropriate rights to the product.
The ALARMSMS function uses the IN(4/5) alarm inputs and activates the sending of an SMS notification following
the triggering of an alarm or event to authorised numbers.
The SMSFORWARD function enables the transfer of SMS messages sent by the telephone operator on the GSM
control to authorised numbers. This function is dedicated to the administrator role.
The NEWS function allows anyone who knows the PIN code of the GSM control to send messages to it, which will
then be forwarded to all contacts with the assigned NEWS function.
10
User action required
Press the button for 2 seconds.
Press the button again (after the previous
operation above) for 3 seconds.
Press the button for 8 seconds.
- Press for 8 seconds,
- Release the button when the Error/Info LED
starts flashing rapidly,
- Then press immediately until the same LED
flashes slowly,
- Then release the button permanently.
- Off: Normal operation,
- Continuously lit: "BLOCK" mode activated, the alarms cannot be triggered,
- Flashes continuously: GSM connection error detected (PIN code,...),
- Lit for 3 seconds: receiving an SMS.
The behaviour of the LED during Reset/Return to factory configuration operations is
defined in section 1.5.1.1 Using the "Stop/Reset" button.
- Off: GSM deactivated,
- Continuously lit: GSM signal search,
- Flashes at 3-second intervals: valid GSM reception,
- Flashes every second: incoming call in progress.
- Lit: input activated.
- Off: input not active.
- Lit: output activated.
- Off: output inactive.
Error / Info LED status(es)
Off > continuous red.
Solid red > off.
Continuous red > flashing (after 8
seconds) > off (when the button
is released).
Off > continuous red (first press)
> rapid flashing (after 8 seconds)
> slow flashing (after releasing
and pressing again) > off (after
releasing).
Behaviour
