6. APPENDICES

As an example, here is the list of responses received by SMS for the configuration and verification stages
sent by SMS (for simplicity, we will deliberately limit ourselves to a single contact / a single group to illustrate the
commands sent by SMS in steps 28/29/30).
Steps Command sent by SMS
1
STATUS #PINcode
2 Set language EN
SET TIME 15 30
3
#PINcode
4
SET NAME BodetGSM
5
RESET G1 #PINcode
6 SET G1 ALARMSMS
7 RESET G2 #PINcode
SET G2 INCALL1
8
#PINcode
Response received by
SMS
GX155 0.48
Alarm: OFF
GSM: xx%
Temp: xxC
230V
IN1: LO
IN2: LO
IN3: LO
32V
IN4: LO
IN5: LO
OUT1: OFF
OUT2: OFF
OUT3: OFF
BLOCK: OFF
GX155 0.48
#PINcode -----------
Language: EN
GX155 0.48
-----------
Time : 15:30
19 07 21
Date 19.07.21 Mo
Relays time: 5s
Alarm every 5 min
BodetGSM 0.48
#PINcode
The name was changed
from GX155 to BodetGSM
BodetGSM 0.48
G1_ALARMSMS: OFF
G1_INCALL1: NO
G1_INCALL2: NO
G1_INCALL3: NO
G1_NEWS: OFF
G1_SMSFORWARD: NO
BodetGSM 0.48
G1_ALARMSMS: ON
G1_INCALL1: NO
NEWS #PINcode G1_INCALL2: NO
G1_INCALL3: NO
G1_NEWS: ON
G1_SMSFORWARD: NO
BodetGSM 0.48
G2_ALARMSMS: OFF
G2_INCALL1: NO
G2_INCALL2: NO
G2_INCALL3: NO
G2_NEWS: OFF
G2_SMSFORWARD: NO
BodetGSM 0.48
G2_ALARMSMS: ON
G2_INCALL1: YES
ALARMSMS NEWS
G2_INCALL2: NO
G2_INCALL3: NO
G2_NEWS: ON
G2_SMSFORWARD: NO
Comments
Client product name - Firmware version
Alarm status (ON/OFF)
Level of GSM reception
Temperature of the device
List of 230V inputs (IN1/2/3)
Not used
Not used
Not used
List of 32V inputs (IN4/5)
Alarm input status - Selectable alert*.
Alarm input status - Selectable alert*.
Control status - Alert A (ON/OFF)
Control status - Alert B (ON/OFF)
Control status - Alert C (ON/OFF)
"BLOCK" mode status (ON/OFF)
ON: enabled, OFF: disabled
* LO: no alarm HI: active alarm
Client product name (by default) - Firmware version
-----------
Language of SMS responses
Client product name (by default) - Firmware version
-----------
Time programmed in the device
Date programmed in the device
Time between 2 status changes of a relay
Time between 2 alarm messages
Client product name - Firmware version
Confirmation message indicating the change of the
device name
Client product name - Firmware version
Function disabled
Function disabled
Function disabled
Function disabled
Function disabled
Function disabled
Client product name - Firmware version
Function enabled
Function disabled
Function disabled
Function disabled
Function enabled
Function disabled
Client product name - Firmware version
Function disabled
Function disabled
Function disabled
Function disabled
Function disabled
Function disabled
Client product name - Firmware version
Function enabled
Function enabled
Function disabled
Function disabled
Function enabled
Function disabled
