Bodet GSM CONTROL Installation And User Manual page 24

26
ALARM ENABLE
27
SET IDLEALARM
SET TEL +33xxxxxxxxx
28
MARTIN #PINcode
29 TEST TEL #G1
30 TEST G1 #PINcode
31
STATUS #PINcode
32
SET PIN 1234
24
#PINcode
1 #PINcode
G1
#PINcode
#PINcode
Bodet GSM 0.48 Client product name - Firmware version
Alarm: ON Alarm status (ON/OFF)
GSM: 50% Level of GSM reception
Temp: 19.3C Temperature of the device
230V List of 230V inputs (IN1/2/3)
IN1: LO Not used
IN2: LO Not used
IN3: LO Not used
32V List of 32V inputs (IN4/5)
IN4: LO Alarm input status - Selectable alert*.
IN5: LO Alarm input status - Selectable alert*.
OUT1: OFF Control status - Alert A (ON/OFF)
OUT2: OFF Control status - Alert B (ON/OFF)
OUT3: OFF Control status - Alert C (ON/OFF)
BLOCK: OFF "BLOCK" mode status (ON/OFF)
ON: enabled, OFF: disabled
* LO: no alarm HI: active alarm
BodetGSM 0.48 Client product name - Firmware version
----------- -----------
Time: 15:35 Time programmed in the device
Date: 19.07.21 Mo Date programmed in the device
Relays time: 5s Time between 2 status changes of a relay
Alarm every 1 min Time between 2 alarm messages
BodetGSM 0.48 Client product name - Firmware version
Tel01 Name: MARTIN Location number and name of the registered contact
Tel01 Ne: +33xxxxxxxxx Location number and telephone number registered
Tel01 Group: G1 Location number and group assigned to the contact
BodetGSM 0.48 Client product name - Firmware version
Grp: G1 Group identification
Member
List of contacts registered in the group
01 MARTIN
BodetGSM 0.48 Client product name - Firmware version
G1_ALARMSMS: ON Function enabled
G1_INCALL1: NO Function disabled
G1_INCALL2: NO Function disabled
G1_INCALL3: NO Function disabled
G1_NEWS: ON Function enabled
G1_SMSFORWARD: NO Function disabled
BodetGSM 0.48 Client product name - Firmware version
Alarm: ON Alarm status (ON/OFF)
GSM: 50% Level of GSM reception
Temp: 19.3C Temperature of the device
230V List of 230V inputs (IN1/2/3)
IN1: LO Not used
IN2: LO Not used
IN3: LO Not used
32V List of 32V inputs (IN4/5)
IN4: LO Alarm input status - Selectable alert*.
IN5: LO Alarm input status - Selectable alert*.
OUT1: OFF Control status - Alert A (ON/OFF)
OUT2: OFF Control status - Alert B (ON/OFF)
OUT3: OFF Control status - Alert C (ON/OFF)
BLOCK: OFF "BLOCK" mode status (ON/OFF)
ON: enabled, OFF: disabled
* LO: no alarm HI: active alarm
BodetGSM 0.48 Client product name - Firmware version
----------- -----------
The PIN code has been Confirmation message indicating the change of PIN
changed to 1234 code for the device and the SIM card.
Please use now #1234
EN
