2.4 Electrical installation

IN4 OUT 1
green
brown
yellow
white
2-pair cable
supplied and
wired
white
yellow
green
External
C1 OV
COM
Input A
IN5 OUT 2
green
brown
yellow
grey
white
3-pair cable
supplied unwired
grey
white
yellow
green
brown
C2 OV External
COM
Input B
Wiring details (for A-alert commissioning only):
Power supply 230V
- Blue wire: Neutral (N)
- Brown wire: Live (L)
- Yellow / Green wire: Earth
Alert control output A (OUT1) to be wired to external input A of the SIGMA 3-input add-on board:
- Brown Wire
- White wire
Cable cross-section up to 2.5 mm².
Alarm input IN4 to be wired to the relay output C1 of the SIGMA (for activation, the relay must be closed at least
3 seconds on the SIGMA):
- Green wire
- Yellow wire
Cable cross-section: 1.5 mm².
Note: the connection of a 2-pair cable for input IN4 and output OUT1 is already made at the factory on the box side.
For the connection of the alarm input IN5 and the 2 other outputs OUT2 and OUT3, refer to the
diagram above and use the 3-pair cable supplied.
Important:
- configure the 3-input option card and the relay contacts of the Sigma master clock: refer to the product
manual.
12
brown
yellow
OUT 3
pink
pink
External
Input C
:
brown
blue
yellow
green
yellow
EN
yellow / green
brown
white
brown
white
pink
grey
External
Input
C B A
3-input option card
