PROAIM Cinema Series Assembly Manual

Monitor articulated arm for camera cart

Hide thumbs Also See for Cinema Series:

Monitor Articulated Arm for Camera Cart

(VCTR-MA)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

2 x Rods (Length 40cm each)

Mounting Arm

2 X Pair Monitor Arm Clamps

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable

Table of Contents

Need help?

Do you have a question about the Cinema Series and is the answer not in the manual?

Page 1 Monitor Articulated Arm for Camera Cart (VCTR-MA) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Monitor Articulated Arm for Camera Cart Setup  Mount the monitor arm clamp onto the cart post and tighten the knob to secure it.  Similarly, mount the second clamp on the same cart post and secure it well.  Connect both the 40mm rods properly.
Page 3  After mounting the arm, tighten the knob properly. Loosen the bolts from both sides using the Allen key. Note: By loosening the bolts, you can move the mounting arm up to 180° up-down, as shown in the images.  Loosen the bolt on the top of the mounting arm to rotate the arm up to 360°.
Page 4 YOUR PROAIM MONITOR ARTICULATED ARM FOR CAMERA CART ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
