Dotz Par
The LCD backlight will shut off after 30 seconds. To illuminate the background again, press
the MODE button for 5 seconds.
DMX Mode - Set the DMX Address and DMX Channel Mode.
1. Press the MODE button until "AXXX" is displayed. "XXX" represents the currently used address.
2. Use the UP or DOWN buttons to change the DMX address.
3. After setting your DMX address, press ENTER. You can now select your desired DMX channel
mode. Use the UP or DOWN buttons to find your desired DMX channel mode, then press ENTER
to confirm your selection.
4. Next, select your dimmer curve setting. There are 5 available options. Select you desired dimmer
curve setting, and press ENTER.
5. Lastly, you can set your NO DMX setting. This setting is a precaution setting. This setting is used
in the event that the DMX signal is lost or interrupted. Press ENTER when you are finished to
return to the DMX address setting.
Dimmer Curve - This setting will let you select your desired dimmer curve.
1. Press the MODE button until "AXXX" is displayed. "XXX" represents the current displayed
address.
2. Press the SET UP button until "dcXX" is displayed, then press ENTER.
3. 1 of 5 dimming curve settings will be displayed: Standard, Stage, TV, Architectural, or Theatre.
Use the UP and DOWN buttons to select your desired dimming curve and press ENTER to con-
firm. See the Dimmer Curve Chart section of this manual for detailed information.
NO DMX - This setting defines the behavior of the fixture in the event that the DMX signal is
lost, interrupted, or power is lost. It also defines the default mode that the fixture will go into
immediately after powering up.
1. Press the MENU button until "NO DMX" is displayed, and either "Sound", "Black", or "Hold" will
be displayed beneath.
2. Press ENTER and the bottom line of text will begin to flash. Use the UP or DOWN buttons to
choose an operating mode.
• Sound - The unit will automatically go into sound active mode.
• Black (Blackout) - The unit will automatically go into stand by mode.
• Hold - The fixture will stay in the last DMX setting. If power is applied and this mode is set,
the unit will automatically go into the last DMX set up.
3. Press ENTER to confirm your desired set up.
Secondary Mode - This will let you set your unit as a secondary unit in a primary/secondary
configuration.
1. Press the MODE button until "Secd" is displayed. Your unit will now follow the Primary unit.
