  • Page 1 BAKE Product Manual Installation, use and maintenance mychefcooking.com PRODUCT MANUAL BAKE DT.MP.BA.2103.2...

  • Page 2: Table Of Contents

    INDEX 1. INTRODUCTION ................... 4 2. TECHNICAL CHARACTERISTICS ..............5 2.1. Main characteristics Mychef Bake ............... 5 GENERAL SAFETY AND ACCIDENT PREVENTION REGULATIONS ....6 3.1. Personnel responsible for using the equipment ..........6 3.2. Electrical hazard ....................6 3.3. Thermal hazard...................... 6 3.4.
  • Page 3 7.3. Support functions ....................48 7.3.1. Reset Wi-Fi settings ................. 48 7.3.2. Show MAC address ................. 48 7.3.3. Unlink the "Mychef Control" service ............. 48 7.3.4. Desktop application for intelligent control .......... 49 7.4. Table of states ..................... 50 7.5. Recipes ......................... 50 8.

  • Page 4: Introduction

    The equipment is shipped from the factory once it has been calibrated and has passed rigorous quality and safety tests that ensure its correct operation. The manufacturer will disclaim any responsibility for problems caused by improper installation, modification, use or maintenance. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 5: Technical Characteristics

    760x785x750 760x785x865 760x785x1155 Height) (mm) Capacity 4 600x400 6 600x400 10 600x400 Distance between guides (mm) Table 1. Main characteristics of Mychef Bake ovens The maximum recommended food load per 600x400 tray is 5 Kg. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 6: General Safety And Accident Prevention Regulations

    60°C. Touch only the handle and the control panel. 3.4. Corrosion hazard When using cleaning products, special attention and appropriate safety measures should be taken when handling these products. Always read the safety data sheet for the different PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 7 MyCare CleanDuo and DA21 cleaning products have been specially formulated for the correct cleaning and protection of Mychef ovens with automatic washing. The product contains, in addition to detergent, polish for a perfect finish. The use of this detergent is mandatory in the Mychef Bake ovens.

  • Page 8: Reception, Transport And Positioning

    Make sure that during transport it does not tip over and is not hit by any object. Be careful with the legs and the siphon when positioning the oven on the final location. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 9: Positioning

    50mm from the back o 500mm from the top The equipment should be placed on a Mychef support table or wall mount. If there are sources of heat or steam near the equipment (stove, grill, iron, deep fryer, pasta cooker, kettle, tilting frying pan etc.), these must be at a distance of more than 1 metre.
  • Page 10 Be extremely careful with the cooling areas of the oven. If it sucks in vapours or hot air it can drastically reduce the life span of the components. For the installation of Mychef stacked ovens, follow the instructions supplied with the corresponding stacking kit.

  • Page 11: Installation

    The wiring and other safety devices used for the electrical installation must have the appropriate section for the equipment in question. In any case, respect the regulations in force for the connection of the equipment to the low voltage network. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 12: Three-Phase Connection 400V 3L+N

    Never connect a phase to neutral or ground. Check that the installation voltages correspond to those of the equipment. The following subchapters show the three possible types of connections for Mychef ovens. The voltage of each oven can be found on its identification sticker.

  • Page 13: Single-Phase Connection 230V L+N

    Copper (Cu) less than 0.05 mg/L Conductivity less than 20uS/cm Use of descaler and Mychef filter mandatory. The use of water with different characteristics than those indicated may cause serious problems in the components of the oven, such as corrosion in the cooking chamber or the glass, premature failure of the solenoid valves, etc.

  • Page 14: Drain

    For correct operation, bear in mind that the pipe must have a constant slope of at least 5º. 5.2.2. Drain For the correct operation of the steam system of the Bake ovens, the equipment must be connected to a drainage system with a nominal diameter of 40mm (DN40) through a heat- resistant pipe.

  • Page 15: Vapour Condensation Hood

    Figure 4. Drainage For correct operation, bear in mind that the pipe must have a constant slope of at least 5º. Only applicable to Mychef Bake ovens. The drain must be a maximum of 1 meter long, have a diameter greater than the drain connection and be free of bottlenecks.

  • Page 16: Use

    6. USE 6.1. Control Panel The figure below shows the control panel for the Mychef Bake ovens. It consists of a central screen with displays, indicators and buttons. Figure 5. Control panel PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 17 The functionality of each of them is explained below: Figure 6. Control panel detail PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 18 Table 6. Control panel description The central display is a very important part when interacting with the oven, since it indicates the value of each cooking parameter. Figure 7. Central screen PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 19 COOL is displayed, indicating that cooling of the chamber must be performed prior to self-cleaning. To start both self-cleaning and cooling, press START/STOP. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 20: Switching On The Equipment

    When the oven is at a safe temperature it will automatically turn off. If the equipment does not turn on, check the status of the safety thermostat and the service switch, located at the rear of the equipment. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 21: Cooking Modes

    To do this, press the humidity button and adjust with the +/- buttons to the desired value. This value is shown in the central indicator. Figure 10. Humidity setting in mixed mode PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 22: Cooking Control

    Steam 30ºC to 130ºC 100% Table 8. Cooking modes in Mychef ovens In order to prolong the life of your oven, it may automatically reduce the maximum temperature of the cooking chamber. In all cooking modes it is possible to humidify the chamber at will. To do so, press the HUMIDITY button until the oven sprays water into the cooking chamber.
  • Page 23 At this point, the time indicator will display the keyword "End", the oven will beep for one second and the interior light will light up until the user finishes cooking by pressing the START/STOP button slightly. Example of cooking at 90º for 10 minutes: PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 24: Start Of The Cooking Cycle

    If a parameter other than time is selected on the display, the last point of this will flash to indicate that cooking is in progress. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 25: End Of Cycle

    In any cooking mode the user can select the speed of the convection fan that best suits his needs. To do so, press the fan speed button. Then select the appropriate speed with the +/- buttons. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 26: Automatic Cleaning

    This allows you to use only one CleanDuo tablet per wash, with the consequent savings and ease of use. Use CleanDuo in Bake ovens that are equipped with the automatic self- cleaning system. The use of other products will void the warranty.
  • Page 27 Once in this mode, the display alternately shows the temperature of the cooking chamber. To exit the fast cooling mode, briefly press START/STOP. Please note that in this mode the convection fan works with the door open. Take the appropriate precautions. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 28 If cooling is not required, you can place the MyCare detergent directly in its allocated space, and start the cleaning or rinsing cycle by pressing the START/STOP key. Place as many tablets as there are holes in your oven. Figure 21. CleanDuo holder PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 29: Nightwatch

    The oven will turn off automatically at the end of the cleaning process (only firmware 1.7 and higher). 6.2. NightWatch NightWatch allows the oven to automatically continue a cooking process after a power failure. This functionality is especially useful for unattended cooking. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 30: Errors And Alarms

    Processor communication EEPROM ERROR EEPROM working. Check the control board. Engine error. Check motor wiring. ERROR MOTOR Overtemperature in the engine. Engine nailed down. ALARM WATER Reserved. Not used. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 31 ERROR CLEANING PROGRAM Reserved. Not used. NOT TERMINATED ERROR CLEANING Reserved. Not used. TEMPERATURE TOO HOT ALARM RECOVERY TEMP TOO Reserved. Not used. ERROR INVERTER Reserved. Not used. Table 10. Errors, alarms and possible solutions PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 32: Remote Control Use

    It is recommended to use the Google Chrome browser for better performance. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 33: Wi-Fi Connectivity

    Figure 25. Access point of the oven from Windows Then, this Wi-Fi network will be selected on the device with which we want to link the oven. After selecting the Wi-Fi network, enter the code or password given by Mychef and wait for a configuration web portal to open automatically.
  • Page 34 5GHz networks are not compatible with Smart Control functionality. If the MAC address of the equipment has not been noted, it can be displayed in the control panel of the oven once the Wi-Fi network has been set up. See section 7.3.2. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 35: Linking The Oven To The Device (Mobile Phone, Tablet Or Computer)

    Once the Wi-Fi network is configured, it is important to wait a few minutes until the Wi-Fi network disappears (Mychef + MAC address), if this does not happen it means that the configuration data entered to authenticate the Wi- Fi network is not correct, then the process must be started again.

  • Page 36: Control Panel

    7.1.4. Control panel In the Figure 29 shows the control panel for the ovens linked to the user account. The functionality of each panel element is explained below. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 37 Figure 29. Control panel detail PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 38 (N). It opens a window with information about the equipment: the user linked to the equipment, the minutes of "More information" button operation of the oven and the temperatures of the electronics of the equipment. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 39: Google Home Setup And Voice Assistant

    1. On the app's Home screen, select "Add" and then "Configure the device”. Mychef's Intelligent Voice Control is currently only available in English, so you need to change the language of the mobile device you are using to English to enjoy the full functionality.
  • Page 40 3. Finally, the user will be redirected to the authentication server page to log in with the user and password created in section 7.1.1. It will wait for the authentication to be validated and then all the devices created in the control web application will be synchronized. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 41 Whenever you add or remove an oven in the control web application, the Google Home startup screen will automatically update with the new devices, otherwise you need to unlink your account from the Mychef Control service and repeat the steps in this section to make the devices appear or disappear on the Google Home startup screen.
  • Page 42 Figure 34. Google Home Home screen where all the ovens linked to the user's account will appear, along with all the smart devices that the user has associated with his Google account PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 43: Voice Commands For Oven Control

    Table 12. Different voice commands compatible with the intelligent control The word "Mychef" appears in these commands to refer to the oven in question, but this word can be replaced by the name you want to give the oven once it is added to the web control.

  • Page 44: Adding Automated Routines

    Below is an example where just by saying "Cook Pizza", Google Home will execute all the necessary commands to turn on the oven, set the desired temperature, humidity and cooking time and finally start a bake with these parameters. 1. Go to settings in Google Assistant and select the "Routines" icon.
  • Page 45 Figure 36. Google Assistant application capture 2. Then manage routines and press the add icon (+). Figure 37. Google Assistant Routines capture PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 46 Google Assistant application The word "Mychef" appears in these commands to refer to the oven in question, but this word can be replaced by the name you want to give the oven once it is added to the web control.
  • Page 47 Figure 39. Executing the configured routine by voice command in the Google Assistant application PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 48: Support Functions

    Wi-Fi access point. 7.3.3. Unlink the "Mychef Control" service To unlink the Google account to the "Mychef Control" service, follow the steps in section 7.2.1 until the list of service providers appears, this screen will show that we are linked to the "Mychef Control"...

  • Page 49: Desktop Application For Intelligent Control

    Figure 42. Pop-up window for adding the application to the home screen and application icon on a mobile device In order to add the shortcut to the home screen, the Chrome application must have permissions to do this. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 50: Table Of States

    Figure 43. Recipe creation form If a recipe is selected, the cooking parameter input fields are locked with the values of the recipe in question. To change the cooking values again, select Manual cooking. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 51: Maintenance

    Mychef Bake ovens equipped with this self-cleaning system. MyCare makes greater energy savings possible with lower detergent consumption and fewer toxic emissions. In the models Mychef Bake, there is only one washing cycle in which one CleanDuo tablet is used per compartment.

  • Page 52: Suction

    Extreme care must be taken when cleaning this part of the oven. Leave the door ajar and wait until the chamber fan stops. When this process has been completed, the chamber fan suction part must be replaced in reverse. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 53: Door Gasket

    To clean this compartment, the outer door must be opened and the inner door clips opened so that the door can be opened and the chamber between the outer and inner door can be accessed. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
  • Page 54 Do not use the hand shower accessory on the door glass while it is hot, there is a danger of breakage due to thermal shock. For the stainless-steel housing use a cloth dampened in a mixture of water and detergent, or specific detergent for stainless steel. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...

  • Page 55: Preventive Maintenance

    These periodic checks must be carried out by an authorized service technician. The following table shows the operations to be performed on Mychef ovens at each of the revisions. The table is circular, and from 20.000h of use or 10 years would start counting again on the left of the table.
  • Page 56 Before any handling for maintenance or repair, the equipment must be disconnected from the power supply. If the power cable is damaged, it must be replaced by your service department or similarly qualified personnel in order to avoid risks. PRODUCT MANUAL BAKE DT.MP.BA.2103.2 mychefcooking.com...
