Craftmade OL52 Specifications

DIMENSIONS
A (2" DR) – 22 1 ⁄ C – 18
2
A (6" DR) – 26 1 ⁄ D – 6
2
B (2" DR) – 19 1 ⁄ E – 5
2
B (6" DR) – 23 1 ⁄
2
The Ol' Madrid fan is shipped with two down rods,
a 2" for mounting close to the ceiling, a 6" rod for
mounting farther away. If using Tripod Close Kit
with this fan, A & B measurements are approximate
to those of the CXL fan.
WARRANTY
Limited Lifetime Warranty
MODEL OL52

SPECIFICATIONS

Blade Sweep – 52" or 56"
# of Blades – 5
Blade Pitch – 14°
Motor Size – 188 x 15
AMPS (HI Speed) – .70
Watts (HI Speed) – 80
RPM (HI⁄MED⁄LO) – 210/120/78
1 ⁄
2
CFM (HI Speed) – 7680
FINISHES
Antique White, Brownstone,
European Bronze, Mocha
Ol' Madrid
STANDARD
OPERATION
®
