Craftmade CXL52 Specifications

DIMENSIONS
3 1
A (2" DR) – 11 ⁄ C – 11
8
A (6" DR) – 15 3 ⁄ D – 5 1 ⁄
8 8
B (2" DR) – 9 1 ⁄ E – 4 1 ⁄
2 2
B (6" DR) – 13 1 ⁄
2
All Craftmade fans are shipped with
two down rods, a 2" for mounting
close to the ceiling, a 6" rod for
mounting farther away.
WARRANTY
Limited Lifetime Warranty
MODEL CXL52

SPECIFICATIONS

Blade Sweep – 52" or 56"
# of Blades – 5
Blade Pitch – 14°
Motor Size – 188 x 15
AMPS (HI Speed) – .70
Watts (HI Speed) – 80
RPM (HI⁄MED⁄LO) – 210/120/78
CFM (HI Speed) – 7680
⁄
2
Almond, Antique Brass, Antique White, Bronze, Bronze,
Brownstone, Brushed Nickel, English Toffee, European Bronze,
Flat Black, Galvinized, Graystone, Mocha, Morrocan Gold,
Old Iron, Pearl Essence, Pewter, Polished Brass, Rust, Rustic Iron,
Sandstone White, Textured White, Verde Green, White,
White Brass, Oiled Bronze, Aged Bronze, Burnt Sienna,
CXL
CXL52AB with B5/52S-WB6 and LKE116
Antique Brass CXL and light kit with Walnut blades.
STANDARD
OPERATION
FINISHES
Saddle Leather
