Installation Instructions
Models: CA60, CB60
Instrucciones de instalación
Modelos: CA60, CB60
®
BETTER BY DESIGN
CA60
CB60
®
MEJOR DISEÑO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cameo CA60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftmade Cameo CA60

Summary of Contents for Craftmade Cameo CA60

  • Page 1 Modelos: CA60, CB60 650 S. Royal Lane, Suite 100 Coppell, TX 75019 EE.UU. (800) 486- 4892 8:00 a 5:00 CST (Hora local central) Número de fax sin cargo: (877) 304-1728 ® ® Correo electrónico: customerservice@craftmade.com BETTER BY DESIGN MEJOR DISEÑO www. craftmade.com...

  • Page 2: Before Assembly

    Before Assembly Read and Save These Safety Precautions Make sure that the fan voltage (120) is compatible with your own electrical Turn off electricity at main switch before wiring or servicing fan in order to avoid system. possible electrical shock. Check to make sure that your carton contains all the parts mentioned in the All wiring must be in accordance with the National Electric Code (ANSI/NFPA 70- parts list.

  • Page 3: Preparation / Preparación

    B. Angle Mount (Normal Ceilings) Tornillos para madera Instalación con vara hacia abajo S2. Screws (for Canopy) Craftmade Part #45AD (see dealer) (cielos rasos normales) Tornillos (para la cúpula) S3. Bracket Screws & Washer Determine el método de montaje a usar.
  • Page 4 Step 3 / Paso 3 Step 5 / Paso 5 Check to make sure blades are at Locate downrod assembly (#2). Loosen ball screw on black hanging ball least 30” from any obstruction. to free lock pin. Black hanging ball will slide down. Remove ground Check downrod length to ensure 30”...

  • Page 5: Outlet Box

    Step 7 / Paso 7 Step 6 / Paso 6 Lift fan onto the mounting bracket (#1). Turn housing until Position downrod so the hole in the downrod aligns with the hole in hanging ball seats itself into ball socket (listen for click). the coupling on the motor.
  • Page 6 Step 8/ Paso 8 Step 9 / Paso 9 Ground Attach canopy (#3) to the Wire Tierra Connectors mounting bracket by placing Ceiling White (Neutral) (S7) Cielo raso Conectores Blanco (Neutro) screws (S2) into slot in canopy. de cables Twist clockwise to lock (S7) Canopy (3) Black (Power)
  • Page 7 Step 11 / Paso 11 Step 13 / Paso 13 Blade Installation / Instalación de aspas Attach two of the fixture plate screws (S10) to fan motor housing base (7) Using motor screws (S5) provided, install blade assemblies on fly wheel allowing room for fixture plate to be attached.
  • Page 8 Step 14 / Paso 14 Step 16 / Paso 16 Model: CA60/ Modelo: CA60 Wiring Instructions/Instrucciones de cableado Alabaster Glass/Vidrio de alabastro NOTE: Use instructions packed with celing fan to wire ceiling fan. WARNING: To avoid overheating and possible damage to his device and Attach glass (9) to mounting other equipment, do not install to control a receptacle, fluorescent lighting, bracket for glass (3) using...
  • Page 9 Operation Instructions/Instrucciones de uso Step 16 Continued/ Paso 16 Continuación… Wiring Instructions/Instrucciones de cableado ON/OFF For emergency shut off. 1. Quite el aislamiento para exponer el alambre de cobre de _ pulg. al extremo de los conductores del circuito. Mantenga rectos los extremos de los cables. HIGH Controls fan motor speed.

  • Page 10: Common Problems

    Common Problems Setting Frequency Switches Ajuste de los interruptores de frecuencia Problem A: Fan Will not Start Remedies: 1. Check fuse or circuit breaker and replace if necessary 2. Turn off electrical power and check all wire connectors. The wall control unit is operated by a set of frequency switches and are 3.
