Captivate
Installation Guide
For Model:
CPT52
WARNING:
DC Motor will not
operate until blades
are installed
4009218
APPROVED FOR USE IN
DAMP LOCATIONS
net weight of fan: 12.28 lb (5.57 kg)
READ THESE INSTRUCTIONS AND
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 7
Warranty. pg. 12
page 1
PRINTED IN CHINA
