Connery
Installation Guide
For Model:
CON48
E124404
net weight of fan: 14.33 lb (6.5 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 2
Unpacking Your Fan. pg. 3
Parts Inventory. pg. 3
Installation Preparation. pg. 4
Hanging Bracket Installation. pg. 4
Fan Assembly. pg. 5
Wiring. pg. 6
Canopy Assembly. pg. 7
Blade Assembly. pg. 7
Light Kit Assembly. pg. 8
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Parts Replacement. pg. 9
Warranty. pg. 9
page 1
PRINTED IN CHINA
Advertisement
Related Manuals for Craftmade Connery
Summary of Contents for Craftmade Connery
- Page 1 READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Connery Installation Guide For Model: CON48 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.
- Page 2 SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
- Page 3 1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
- Page 4 3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the inches blades a clearance of 7ft. (2.13m) from the 7 feet (76cm) floor and 30in. (76cm) from any wall or (2.13m) obstruction. This fan is suitable for room sizes up to 12ft.
- Page 5 5. Fan Assembly. 5. Fan Assembly. wood ceiling joist With the hanging bracket secured to the outlet box and able to support the safety cable loop fan, you are now ready to hang your fan. Loosen canopy set screw and lower canopy to expose hanging ball at top of downrod.
- Page 6 6. Wiring. WARNING: Turn off circuit breakers to white supply wire current fixture from breaker panel and black supply wire be sure switch is turned to the OFF position. from ceiling CAUTION: Be sure outlet box is properly black grounded and that a ground wire (GREEN white or Bare) is present.
- Page 7 7. Canopy Assembly. Raise canopy to hanging bracket until canopy touches the ceiling. Tighten the canopy set screw to secure canopy. canopy Carefully remove protective paper from canopy set screw downrod. downrod 8. Blade Assembly. WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the larger screws...
- Page 8 9. Light Kit Assembly. Partially loosen 3 thumbscrews at bottom of motor housing and raise glass shade to motor housing. Secure glass shade with thumbscrews. NOTE: Be sure thumbscrews make contact reverse switch with rubber ring on glass shade but DO NOT overtighten thumbscrews as glass may crack or break.
- Page 9 Troubleshooting. Warranty. WARNING: Failure to disconnect power supply CRAFTMADE 15-YEAR LIMITED WARRANTY: CRAFTMADE warrants this fan to the original purchaser for prior to troubleshooting any wiring issues may indoor use under the following provisions: result in serious injury. 1-YEAR WARRANTY: CRAFTMADE will replace or repair any fan which has faulty performance due to a defect in Problem: Fan fails to operate.
