WICED Smart Quick Start Guide
Figure 1: WICED Smart Tag and Key Component Locations
RD5
Broadcom
®
March 12, 2016 • WICED-Smart-QSG302-R
Accelerometer
Gyroscope Combo
App.
Boot
(SW2)
(SW1)
SW8
R29
J12
Pressure
Sensor
1
1 VUSB
SW4
2 VREGIN
3 VCOIN
Humidity
and
and
Temperature
Reset
(SW3)
SW9
SW6
Magnetometer
1
1 VCOIN
SW5
2 VDDIO
3 VREG
WICED Smart Tag
RD6
WICED Smart Development System
