WICED Smart Quick Start Guide
Application running
09:51:18 Build Finished (took 11s.939ms)
A red LED labeled D1 on the WICED Smart Tag blinks to indicate that the firmware download is complete.
If the WICED Smart tag is not recognized or detected by the programming tools, the following message may be
displayed:
Detecting device...
+------------------------------------------------------------------------------------------+
| No BCM20736 detected
| 1. Verify the BCM20736 tag is connected _AND_ powered
Verify SW2 and SW3 switches
| 2.
| switches are set to ON
| 3. Press the reset button on the tag and retry
|
| If this problem persists, the EEPROM on the tag may be corrupted
| Please see Appendix D in the Quick Start Guide for recovery instructions
+------------------------------------------------------------------------------------------+
Download failed. This version of the SDK only supports download to BCM20736A1 and BCM20737A1 devices
Note: Press the reset button (SW3, see
If this message is displayed, do the following:
1. Verify that the WICED Smart tag is plugged into the development PC.
2. Verify that the USB-UART driver is correctly installed and all switches (SW4, SW5, SW6, and SW8) are
correctly set as described in
3. Press the WICED Smart tag Reset button (see
tag for firmware download on the UART interface.
4. Double-click the build target to rebuild and download the application to the tag.
Note: If the problem persists after following the instructions above, the EEPROM on the WICED Smart
tag may be corrupted. See the instructions in
to erase the EEPROM on the tag.
Broadcom
®
March 12, 2016 • WICED-Smart-QSG302-R
are towards Vusb and Vreg respectively and all SW4
Figure 1 on page
"Connect the WICED Smart Tag" on page
Figure 1 on page 9
"Recovering a Corrupt WICED Smart Tag" on page 27
Build and Load a Sample Application
9) before every download.
13.
for component locations) to prepare the
WICED Smart Development System
|
|
|
|
|
|
|
|
