- Page 1 Hood type Dishwasher Undercounter Dishwasher Glasswasher GENERAL INSTRUCTIONS FOR INSTALLATION, USE AND MAINTENANCE MODELS MOD: COP-174 W COP-504 W CO-502 W CO-500 W CO-402 W CO-400 W CODE: 12220401 REV.: 05 (2021)
-
Page 2: Read First
READ FIRST THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. WARNING IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATION &... -
Page 3: Limited Warranty
Warranty Coverage: If there is a defect in material or factory workmanship covered by this Warranty reported to Fagor during the period the applicable Warranty is in force and effect, Fagor will repair or replace, at Fagor’s option, that part of the Equipment that has become defective. - Page 4 1. INDEX INDEX ............................4 GENERAL MEASUREMENTS AND CONNECTIONS ............. 5 QUICK STARTUP GUIDES ..................... 8 ELECTRICAL DIAGRAM ....................... 10 ELECTRIC DIAGRAMS LEGEND ..................12 GENERAL INFORMATION AND WARNINGS ............... 13 PRODUCT DETAILS ......................13 TECHNICAL SPECIFICATIONS ......................14 INSTALLATION INSTRUCTIONS ..................17 Removal of packaging ........................
-
Page 5: General Measurements And Connections
2. GENERAL MEASUREMENTS AND CONNECTIONS Hood type Dishwasher COP-174 W Connection Water Drain Power Supply Cable Rinse aid Detergent Equipotential Strip inlet hose Strain Relief inlet inlet bond (Inside) - Page 6 Hood type Dishwasher COP-174 W HRS Connection Water Drain Power Supply Cable Rinse aid Detergent Equipotential Strip inlet hose Strain Relief inlet inlet bond (Inside)
- Page 7 Undercounter Dishwasher CO-500 W /CO-502 W / COP-504 W Glasswasher CO-400 W / CO-402 W Connection Water Drain Power Supply Cable Rinse aid Detergent Equipotential Strip inlet hose Strain Relief inlet inlet bond (Inside)
-
Page 8: Quick Startup Guides
3. QUICK STARTUP GUIDES... -
Page 10: Electrical Diagram
4. ELECTRICAL DIAGRAM... -
Page 12: Electric Diagrams Legend
5. ELECTRIC DIAGRAMS LEGEND Terminal block bridge Drain Pump A1, A2 Electronic Board MDet Detergent Dispenser A1-P1 Electric Bridge / Jumper MHRS HRS Fan Boiler temperature probe ML, ML1, ML2 Wash Pump Tank Temperature Probe Neutral C1, C2 Capacitor Tank Pressure Switch Fuse Tank Safety Pressure Switch Boiler Safety Thermostat... -
Page 13: General Information And Warnings
6. GENERAL INFORMATION AND WARNINGS This manual has been created to help you understand the operation, installation and maintenance of the machine. It contains all the necessary information and warnings to ensure that the appliance is installed and used correctly, together with information about the characteristics and possibilities offered, so that you may enjoy your machine to the full. -
Page 14: Technical Specifications
DATA PLATE APPLIANCE MODEL NAME ELECTRICAL SPECIFICATIONS APPLIANCE REFERENCE WATER INLET SPECIFICATIONS SERIAL NUMBER + MANUFACTURE DATE These details should be quoted when the technical service is called. 7.1 TECHNICAL SPECIFICATIONS WASH GALLONS RACKS DISHES GLASSES WATER INLET WATER INLET MODEL TANK PER HR. -
Page 15: Undercounter Dishwashers
HOOD TYPE DISHWASHERS Total Total Pump Pump Tank Boiler CONNECTION Voltage Load Power Load Power Power Power MODEL TYPE (kW) (kW) (kW) (kW) COP-174W 208-240V 208V 40,33 14,09 2,87 0,60 3,68 9,81 COP-174W HRS 60Hz 220V 42,65 15,76 3,04 0,67 4,12 10,98 Full Power... - Page 16 COP-174W / COP-174W HRS 208-240V, 60Hz 208-240V, 60Hz BRIDGE Full Power Boiler & Tank 2/3 Power AWG 6 AWG 6 MCA 47,3 / MOP 55 MCA 54 / MOP 60 CO-502W / COP-504W BRIDGE 208-240V, 60Hz 208-240V, 60Hz 208-240V, 60Hz 208-240V, 60Hz Boiler Full Power Boiler Full Power Boiler 2/3 Power Boiler Half Power AWG 12...
-
Page 17: Installation Instructions
8. INSTALLATION INSTRUCTIONS The dishwasher shall be installed in accordance with local codes, or in the absence of local codes, installed in accordance with the applicable requirements in the National Electrical Code, NFPA 70, Canadian Electrical Code (CEC), Part 1, CSA C22.1, and Standard for Ventilation Control and Fire Protection of Commercial Cooking Operations, NFPA 96. -
Page 18: Hydraulic Connection
• Refer to the wiring diagram, the machine data plate and technical specifications for service size requirements. • Check that the mains voltage corresponds to that indicated on the nameplate. • The power-supply cord shall be Type S, SE, SO, SOO, ST, STO, or STOO (with or without W at the end). -
Page 19: Drainage Connection
Use 3/4” copper tubing inlet line. It is necessary to remove all foreign debris from the water line that may potentially get trapped in the valves or cause an obstruction, prior to connecting to the machine. Use only the supplied hoses (3/4” Female hose connector) at the water connections. Failure to do so may result in damage to the solenoid valve threads and leaking. -
Page 20: Hydraulic Rinse Aid Dispenser (Co Models)
Fig. 3. Installation of drainage at a height using drainage pump. The drainage pump must only be installed by personnel authorised by the manufacturer, and the manufacturer does not accept liability in the event of incorrect installation. 8.6 Hydraulic rinse aid dispenser (CO MODELS) Installation: Take the tube located in the back or your machine marked “Rinse Aid”... - Page 21 Rinse Aid Rinse Line Filter Regulation 8.7 Electric rinse aid dispenser (COP MODELS) Installation: Take the tube located in the back or your machine marked “Rinse Aid” and place inside rinse container. Tubes are transparent to provide you visible mean that chemicals are being dispensed. Operation: this dispenser absorbs the rinse aid when the rinse pump is switched on.
-
Page 22: Detergent Dispenser
If you require the installation of a NON FAGOR Detergent and/or Rinse pump, a form MUST be fill out prior to installation by your installer. Failure to do so will void your Warranty. - Page 23 8.9 Recycling The product packaging consists of: • A wooden pallet. • Cardboard. • A polypropylene band. • Expanded polyethylene. All the packaging used around the machine can be recycled. The correct disposal of these products will help to protect the environment. For further information regarding the recycling of these products, please refer to the relevant office of the local body Dispose of these materials in accordance with current legislation.
-
Page 24: Use And Maintenance Instructions
9. USE AND MAINTENANCE INSTRUCTIONS BEFORE STARTING THE APPLIANCE, PLEASE READ THE INSTRUCTIONS CONTAINED IN THIS MANUAL CAREFULLY. THE APPLIANCE IS EXCLUSIVELY FOR PROFESSIONAL USE AND SHOULD ONLY BE USED BY QUALIFIED PERSONNEL. 9.1 Operation The steps required to optimise the operation of your dishwasher are shown below, with all the available options. - Page 25 9.1.2 Switching on the machine Before switching on the machine, check the following: ✓ The mains switch must be on. ✓ The water stop cock must be open. ✓ There must be water in the mains network. ✓ The corresponding filters must be in place. ✓...
- Page 26 9.1.5 Selecting the wash cycle Before starting the wash cycle, place the corresponding basket containing the dishes in the machine and close the hood/door. Before starting the wash cycle, the machine should have the ideal temperature for washing the dishes properly, indicated by the selected/default program led switched on and the temperature on thermometers, advising the user that the machine is ready.
- Page 27 9.1.5.2 Hood type HRS models The HRS hood type dishwashers integrate the HRS system, which recycles steam energy to heat incoming water and keeps steam out when opening the hood. When the cycle finishes, the HRS system works for another 50 seconds, indicated in the thermometers by flashing “HrS”...
-
Page 28: Cleaning And Maintenance Instructions
9.1.7.2 Drainage using the drainage pump (Optional) The drainage using the drainage pump option is only available on request. To drain the machine using this method, proceed as follows: • Open the hood/door and remove the filter tray. (Fig. 4) •... -
Page 29: Faults, Alarms And Breakdowns
9.2.2 Rinse aid and detergent If you change the rinse aid or detergent, the settings should be adjusted accordingly. This adjustment must be carried out by qualified personnel. Only use detergents suitable for industrial dishwashers. Do not use foam-producing detergents. Detergents designed for domestic use should not be used under any circumstances. - Page 30 FAULT POSSIBLE CAUSE SOLUTION Wash distributors Clean distributors thoroughly. obstructed. Shortage of detergent. Call the technical service to reset the dispenser. Dirty filters. Clean the filters thoroughly. Unsuitable detergent. Call the technical service to supply correct detergent. Unsatisfactory wash. Presence of foam. Too much rinse aid.
- Page 31 10.1 Error diagnosis The errors and warnings are indicated in the thermometers display by the following codes: ERROR IN DESCRIPTION CONSEQUENCE DISPLAY Faulty boiler temperature probe (Not detected or out of range [23ºF-392ºF]). Machine disabled. (E1 / BP) E1 / Boiler Probe Faulty tank temperature probe (Not detected or out of range [23ºF-392ºF]).
- Page 32 Fagor Commercial Inc. 13105 NW 47th Avenue Miami, FL. 33054, USA T. 305 779 0170 Fax. 305 779 0173 1-866-GO FAGOR www.fagorcommercial.com...
