INSTRUCTIONS - MASTERFIT IP
COMMONLY USED REGISTERS
Register Number
65 Operation PIN
66 Programming PIN
67 Partial Pos 1 – Lo
68 Partial Pos 1 – Hi
69 Partial Pos 2 – Lo
70 Partial Pos 2 – Hi
71

SWITCH MODE

72 Partial 1 Open Mode
73 Partial 2 Open Mode
74 SWITCH GROUP Bitmapped Register below
75 IR GROUP Bitmap Register Below
76 Timer Up
77 Timer Down
78 MODULE_ID
82 Time_delay_up (100mS)
83 Time_delay_down (100mS)
12. INFRA-RED GROUP BITMAP CALCULATOR
• Add the value of IR groups
• If you wish the module to operate on Group 1 only –
change register 75 to a value of 2
• If you wish the module to operate on Group 1 & 2
only – change register 75 to a value of 6
INFRA-RED GROUP BITMAP REGISTER 75
• Calculate the register number by using the table:
- Transfer the value for each required group to the
right column.
• The total of the values in the right column then
becomes the Register Value
• E.g. to set groups 1, 2 & 4 then the total value is 22.
A, A+, B, B+, C, C+ Projection Screen
Group
1
2
3
4
5
6
7
8
9
13. CONTACT CLOSE SWITCH GROUPS
• Add the value of switch groups
• If you wish the module to operate on Switch Group 1
only – change register 74 to a value of 2
• If you wish the module to operate on Group 1 & 2
only – change register 74 to a value of 6
SWITCH GROUP BITMAP REGISTER
• Calculate the register number by using the table: -
• Transfer the value for each required group to the
right column.
• The total of the values in the right column then
becomes the Register Value
• E.g. to set groups 1, 2 & 4 then the Total value is 22.
14. IP CONNECT SERIAL PROTOCOL
• This serial command protocol is essentially the same for all console channels
- TELNET via TCP/IP (2 ports 3001)
- HTTP via port 80
FORMAT
The stream is made up of messages. A message consists of 1 to 80 printable ascii characters
followed by and end of message. An end of message is one or more of CR and LF optionally
combined with any number of delimiters.
A message is made up of unsigned numerical value fields in decimal format separated by one or
more delimeters. A delimiter is any single or combination of space, comma or tab.
Examples of valid messages to the IP Connect module are given below. All these messages have
the same meaning.
Value
1,3,45<CR>
2
1,3,45<LF>
4
1,3,45<CR><LF>
,1,3,45<CR><LF>
8
1,3,45,<CR><LF>
16
1,3,,45,<CR><LF>
32 1,3, 45,<CR><LF>
1,3,45,<CR>, ,<LF>
64
01,3,45<CR><LF>
128
000000001,3,45<CR><LF>
256 1 3 45<CR><LF>
1, 3, 45<CR><LF>
512
TOTAL
5
Group Value
1 2
2 4
3 8
4 16
5 32
6 64
7 128
8 256
9 512
TOTAL
Continued Over.../
