Technical Specifications
5.6 Operating Environment
d
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of
patches and splices. Consult a Siemens sales associates when determining maximum segment distances.
GBIC Gigabit (1 Gbps) Transceiver Specifications
Note
GBIC transceivers have a temperature range of -40 to 85 °C (-40 to 185 °F), unless
specified otherwise.
Mode Connector
Type
SM SC
SM SC
e
SM SC
a
All cabling is duplex type unless specified otherwise.
b
Typical.
c
All optical power numbers are listed as dBm averages.
d
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of
patches and splices. Consult a Siemens sales associates when determining maximum segment distances.
e
Operating temperature range of -25 to 85 °C (-13 to 185 °F).
5.6

Operating Environment

The RUGGEDCOM RSG2200 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage
Temperature
Ambient Relative
Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the RUGGEDCOM
SFP Transceivers Catalog for SFP temperature ratings.
c
Non-condensing
5.7

Mechanical Specifications

Weight
Ingress Protection
Enclosure
34
Cable Tx λ
b
Type (nm)
Minimum Maximum
a
(µm)
9/125 1310
9/125 1310
9/125 1550
-40 to 85°C (-40 to 185 °F)
a b
-40 to 85°C (-40 to 185 °F)
5% to 95%
c
2000 m (6562 ft)
4.8 kg (10.6 lbs)
IP30
18 AWG Galvanized Steel
c
Tx (dBm)
Sensitivity
(dBm)
-9.5 -3 -21
-7 -3 -24
0 5 -23
Rx Rx Distance
Saturation (km)
c c
(dBm)
-3 10
-3 25
-3 70
Installation Manual, 04/2021, C79000-G8976-1043-17
Power
d
Budget
(dB)
11.5
17
23
RUGGEDCOM RSG2200
