Parts List - Linear Technology DC1498A Demo Manual

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 4 CIN2, CIN3, CIN4, CIN5
2 2 COUT1, COUT7
3 2 COUT4, COUT5
4 3 R3, R22, R26
5 1 R19
6 1 R25
7 1 R30
8 1 U1
Additional Demo Board Circuit Components
9 1 CIN1
10 0 COUT2, COUT3, COUT6, COUT8
11 0 C1
12 1 C2
13 2 C5, C7
14 0 C3, C4, C6, C8-C12
15 2 C13, C14
16 2 C15, C16
17 1 Q1
18 1 R1
19 0 R2, R4, R6, R8, R11, R14, R16, R17, R20
20 4 R5, R24, R27, R36
21 4 R7, R21, R29, R32
22 5 R9, R12, R15, R18
23 2 R10, R13
24 1 R34
25 0 R35
26 1 R37
27 0 R38
Hardware – For Demo Board Only
28 16 E1, E3-E10, E12-E16
29 3 J1, J2, J3
30 6 J4–J9
31 1 JP1
32 1 JP6
33 3 JP2, JP3, JP4
34 1 JP5
35 6 XJP1–XJP6
36 4 (Stand-Off)
DEMO MANUAL DC1498A
PART DESCRIPTION
Capacitor, X5R, 22µF , 25V, 10%,1210
Capacitor, 470µF , 4V, POSCAP , F8
Capacitor, X5R, 100µF , 6.3V, 20% 1210
Resistor, Chip, 10k, 1%, 0603
Resistor, Chip, 60.4k, 1%, 0603
Resistor, Chip, 40.2k, 1%, 0603
Resistor, Chip, 158k, 1%, 0603
LTM4620EV, 15mm × 15mm × 4.41mm LGA
Capacitor, 150µF , 25V, Aluminum Electr.
Optional
Optional, 0805
Capacitor, X7R, 1µF , 25V, 10%, 0805
Capacitor, X5R, 0.1µF , 25V, 10%, 0603
Optional, 0603
Capacitor, X5R, 0.01µF , 50V, 10%, 0603
Capacitor, X7R, 1µF , 10V, 10%, 0603
N-Channel 30V MOSFET
Resistor, Chip, 10k, 1%, 0603
R23, R28, R31, R33, R39, R40
Resistor, Chip, 10k, 1%, 0603
Resistor, Chip, 0k, 1%, 0603
Resistor, Chip, 60.4k, 1%, 0603
Resistor, Chip, 6.04k, 1%, 0603
Resistor, Chip, 0Ω, 0.5W, 2010
Optional, 2010
Resistor, Chip, 0.015Ω, 2W, 2512
Optional, 2512
Testpoint, Turret, 0.094" PBF
Conn, BNC, 5 Pins
Jack Banana
Header 4 Pin 0.079 Double Row
Header 4 Pin 0.079 Single Row
Header 3 Pin 0.079 Single Row
Header 3 Pin 0.079 Double Row
Shunt, 0.079" Center
Stand-Off, Nylon 0.50"
MANUFACTURER, PART NUMBER
Murata, GRM32ER61E226KE15
Sanyo, 4TPE470MCL
AVX, 12106D107MAT2A
NIC, NRC06F10R0TRF
Vishay, CRCW060360K4FKED
Vishay, CRCW060340K2FKED
Vishay, CRCW0603158KFKED
Linear Technology, LTM4620EV
Sun Electronics, 25CE150AX
1210
AVX, 08053C105KAT2A
AVX, 06033D104KAT
AVX, 06035C103KAT
AVX, 0603ZC105KAT
Vishay, SUD50N03-09P
NIC, NRC06F10R0TRF
Optional, 0603
Vishay, CRCW060310K0FKED
Vishay, CRCW06030000Z0ED
Vishay, CRCW060360K4FKED
Vishay, CRCW06036K04FKED
Vishay, CRCW20200000Z0EF
Vishay, WSL2512R0150FEA
Mill-Max, 2501-2-00-80-00-00-07-0
Connex 112404
Keystone, 575-4
Samtec, TMM104-02-L-D
Samtec, TMM104-02-L-S
Samtec, TMM103-02-L-S
Samtec, TMM-103-02-L-D
Samtec, 2SN-BK-G
Keystone, 8833 (Snap On)
dc1498afa
7
