  • Page 1 AXICON BARCODE VERIFIER Model 12600 Model 12700 (with “Trucheck” software) DOCUMENTATION BOOKLET www.axicon.com © Copyright 2014 Axicon Auto ID Ltd...

  • Page 3: Table Of Contents

    User Calibration  How to use the verifier  The Verification Report  Explanation of the 2D ISO parameters AXICON SOFTWARE LICENCE AGREEMENT AND TERMS (INCL DISCLAIMER ETC) AXICON WARRANTY AND SERVICE CONTRACT  Warranty on all Products  Service Contract VERIFIER SERVICING &...
  • Page 4 - 4 -...
  • Page 5 Thank you for purchasing an Axicon Model 12700 2D Verifier. This short guide will enable you to get started with your Axicon 2D Verifier quickly and easily. This Axicon Verifier is a precision piece of quality control equipment. It has been manufactured to the highest standards through our ISO 9001 Quality Management System and has been thoroughly and extensively tested immediately prior to shipment.

  • Page 6: Important Information

    2. Please retain the plastic transit case. It will protect the equipment in transit. 3. Only use power and data cables supplied by Axicon. Use of non- approved accessories will invalidate the warranty. 4. If the verifier is dropped (or subjected to similar misuse) the accuracy of the results may be affected.

  • Page 7: Minimum System Requirements

    - A USB 2.0 port - Microsoft .NET Framework Version 3.5 SP1 or later The following table shows the various models in the Axicon 12000 series which can be used in conjunction with this software – and their typical applications:...

  • Page 8: What's In The Transit Case

    • Wallet containing Documentation Booklet (includes Start Up Guide), Conformance Certificate and Calibration Sheet OPTIONAL EXTRAS Axicon also offer the following optional extras to be used in conjunction with the system:- - IQ/OQ Procedural Documentation - Performance Qualification Test Kit – Comprising a set of test cards traceable to international standards and full procedural instructions.

  • Page 9: Software Installation

    Install program should start automatically. If not run “Setup.exe” Set the location where you would like the software installed (the default shown). Also at this stage specify whether installation should be for a single user or all users. Axicon 12700 Start-Up Guide...
  • Page 10 At this point the user will be asked to confirm that they want to install the (essential) USB drivers. Please press “Install” to install the drivers After the software installation has been completed, please connect the verifier to install the USB drivers prior to running the software. Axicon 12700 Start-Up Guide...

  • Page 11: Hardware Installation

    Select as appropriate and then click OK. 4.3 If in any doubt select the “Non UID” and “Don’t print report after each scan” options. (You can always change these later if required. Click on the “OK” button. Axicon 12700 Start-Up Guide...

  • Page 12: Software Configuration

    1D (linear) and 2D barcodes. Configuration of the software to meet the requirements of each should be made independently through the different configuration icons. 5.1 Configuration of the 1D mode Double click the icon to display the configuration screen Axicon 12700 Start-Up Guide...
  • Page 13 If in any doubt about the settings to be used please contact your Axicon reseller for more information. We would also remind you that in many countries Axicon are able to offer on-site installation and/or training services should these be considered beneficial.
  • Page 14 . As you will notice the user can also set up different file saving and printing options. If in any doubt about the settings to be used please contact your Axicon reseller for more information. Axicon 12700 Start-Up Guide...

  • Page 15: User Calibration

    Take the calibration card out of the plastic pouch and check that it is not creased, damaged or stained – If it is damaged then it should be replaced as soon as possible – Contact Axicon or your Axicon reseller to obtain a replacement calibration card.
  • Page 16 - Set the Rmin and Rmax value to the ones shown on your calibration card (Generally 5% and 85%) - Set the calibration reminder to 30 days or less. 5.3.7 Finally click on the calibrate button of the software Axicon 12700 Start-Up Guide...
  • Page 17 5.3.8 The calibration is done automatically in about 5 seconds and then the following windows pops up. 5.3.9 Press « OK » to confirm. 5.3.10 Press “Close” to close the Calibration Dialog window Axicon 12700 Start-Up Guide...

  • Page 18: How To Use The Verifier

    Section 6 – How to use the verifier 6.1 – Activate the camera Press either the “start” button on the verifier hardware or press the • “Activate” button on the software The LEDs should start flashing and the software displays the camera •...
  • Page 19 6.3- Verify the barcode • Click again on the start button or the activate button to take the picture and start the verification process. • Once the code has been decoded the results will be displayed. Axicon 12700 Start-Up Guide - 19 -...

  • Page 20: The Verification Report

    2D barcode Click here to export data to an Excel sheet Detailed results – Click on the enlarge window ISO Grade icon to show this panel; Decoded data Image of the bar code Axicon 12700 Start-Up Guide - 20 -...
  • Page 21 The user can also select from a range of different display options by clicking on the appropriate tab Axicon 12700 Start-Up Guide - 21 -...

  • Page 22: Explanation Of The 2D Iso Parameters

    • Modulation is a measure of variability of reflectance for each module in the symbol. • Reflectance margin is also a measure of variability but unlike modulation, reflectance margin also takes into account whether Axicon 12700 Start-Up Guide - 22 -...
  • Page 23 Average Grade, might result in an overall grade for Fixed Pattern Damage which is less than any of the individual test grades. Axicon 12700 Start-Up Guide - 23 -...

  • Page 24: Axicon Software Licence Agreement And Terms

    SOFTWARE LICENCE TERMS -LICENCE GRANT  Axicon grants you a Licence to use any number of copies of the Software, but only for Use in conjunction with the Axicon hardware product that accompanied the Software.
  • Page 25 The transferee must accept these Licence Terms as a condition of the transfer. TERMINATION  Axicon may terminate your Licence upon notice of failure to comply with any of these Licence Terms.  Upon termination, you must immediately destroy the Software, together with all copies, adaptations and merged portions in any form.
  • Page 26 However since we have no control over the circumstances in which you might use the Verifier, you must satisfy yourself that the performance of the Verifier is suitable for your needs. Neither Axicon Auto ID Limited nor the vendor of this Verifier can accept any liability for any loss or damage (consequential or otherwise) which may be caused by use of this Verifier.

  • Page 27: Axicon Warranty And Service Contract

    AXICON WARRANTY AND SERVICE CONTRACT WARRANTY ON ALL PRODUCTS  The Axicon 2D verification equipment is sold with a one year parts and labour warranty against manufacturing defects.  This is a Return to Bench warranty with shipping costs in one direction being borne by the customer/distributor.

  • Page 28: Service Contract

    NOTE: Please see your Service Contract for full details including hire charges. For current cost of a Service Contract or equipment hire please contact either Axicon or your approved Axicon reseller. Axicon 12700 Start-Up Guide - 28 -...
  • Page 29 Should you decide not to take advantage of this service, we must remind you that Axicon Auto ID Ltd is unable to accept any responsibility for non- compliance to the appropriate International Standards once your verifier has exceeded the standard guarantee period provided on date of purchase.

  • Page 30: Other Faults Or Damage

    EQUIPMENT RENTAL SCHEME Axicon Auto ID Ltd also offers an equipment rental scheme for customers who require replacement equipment for the duration of the service Please contact us for further details.

  • Page 31: Contact Us

    HOW TO CONTACT AXICON Axicon Auto ID Ltd Church Road, Weston on the Green, Oxfordshire OX25 3QP, UK Tel.: +44 (0) 1869 35 11 55 Fax: +44 (0) 1869 35 1 205 Fax VCAS/Repairs: +44 (0) 1869 35 24 04 Email : info@axicon.com...

  • Page 32: Service Record

    VCAS SERVICE RECORD Verifier Model Serial Number Date Service Serial no. of Name & Undertaken calibration card Signature A x i c o n A u t o I D L i m i t e d 12700 Verifier Documentation Booklet Company Registration Number: 2003365 Version 2–...
