- Page 1 THE BARCODE EXPERTS Axicon 15000 series 2D & linear barcode verifier user guide Church Road, Weston on the Green, Oxfordshire, OX25 3QP, UK Industry Tel: +44 (0)1869 351155 | Email: sales@axicon.com Partner Web: www.axicon.com...
- Page 2 Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 2 of 28...
-
Page 3: Table Of Contents
Operating the verifier Saving and using scan files Saving and printing reports Settings Warranty Software licence agreement Annual service Certificate of conformance Contact Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 3 of 28... -
Page 4: Introduction
Introduction The Axicon 15000 series verifiers are designed to work with any PC running a currently supported version of Windows (Windows 7, Windows 8, Windows 10 – both 32 bit and 64 bit versions). Specification and application The 15200’s field of view is 60mm x 45mm, and is designed to verify linear and 2D barcodes, including those used on retail point of sale and healthcare items. - Page 5 Connect the USB lead from the verifier to a USB2 or USB3 port on the computer. Please install the software before connecting the 15000 series verifier. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 5 of 28...
-
Page 6: How The Verifier Works
More details about this process, saving scan files, and saving verification reports are explained later on in this user guide. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 6 of 28... -
Page 7: Calibration
If the card shows any sign of damage – for example, scratches or any change in colour – please obtain a new card from us. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 7 of 28... -
Page 8: Getting Started
(the verifier). The Help menu provides access to the Axicon website, a check for software updates, and information about the software. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 8 of 28... - Page 9 Stop searching for barcodes. Edit the settings for the application, or use F5 Display and edit user-defined data for this scan. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 9 of 28...
- Page 10 When a verifier is connected, the message will be ‘Selected reader: xxxxx’, where ‘xxxxx’ is the serial number of the verifier. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 10 of 28...
-
Page 11: Operating The Verifier
Any linear barcode will be verified using ten different scan lines, as specified by ISO/IEC 15416, and the verification grade will be based on the average of these ten readings. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 11 of 28... - Page 12 For example, clicking on modulation will colour each module according to its modulation value. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 12 of 28...
-
Page 13: Saving And Using Scan Files
The plugin details will be included in each verification report. The full verification results are then shown and reports can be viewed (and printed) as required. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 13 of 28... -
Page 14: Saving And Printing Reports
‘Append Report’ box. If this box is left unticked and the file name is not changed, the data will be overwritten. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 14 of 28... -
Page 15: Settings
By default, many plugins are switched off. To change this, select the plugin you require, and choose from the drop-down list: will check relevant codes, Always Show will check every code, and will deactivate the plugin. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 15 of 28... - Page 16 There is an option to add the records to an existing file rather than replacing the file, which is of benefit with text files, including CSV files. Choose Append and then where you want these reports kept. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 16 of 28...
- Page 17 User Data: User Data allows you to program the Axicon 15000 series software to ask questions when a verification is being made, to collect the answers and to store these with the verification report.
- Page 18 There are also facilities to edit an existing User Data entry (ideal for adding items to a pull-down menu). You can also clear any existing User Data requirements. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 18 of 28...
- Page 19 ‘Read-only’ tick box and click on ‘OK’. The common configuration and user login options will now be enabled in the Advanced window of the Settings dialog. Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 19 of 28...
- Page 20 You must restart the software now so that these changes take effect. If you return to this window, you will see that it now looks like this: Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 20 of 28...
- Page 21 For further help and advice about using the 15000 series, please contact us at support@axicon.com Axicon Auto ID Limited | 15000 series verifier user guide | June 2018...
-
Page 22: Warranty
Warranty Axicon 15000 series verifier is sold with a two year parts and labour warranty against manufacturing defects. This is a return to bench warranty with shipping costs in one direction being borne by the customer/distributor. Should you need to return the unit to Axicon the original case (plus appropriate packaging) must be used. -
Page 23: Software Licence Agreement
14 days, you may return the entire unused product for a full refund. Axicon grants you a licence to use any number of copies of the software, but only for use with an Axicon verifier. “Use” means storing, loading, installing, executing or displaying the software. - Page 24 Verifier is suitable for your needs. Neither Axicon Auto ID Limited nor the vendor of this Verifier can accept any liability for any loss or damage (consequential or otherwise) which may be caused by use of this Verifier.
-
Page 25: Annual Service
Return the verifier (including all cables) in its original case with the completed RMA form, purchase order and your payment details to us at Axicon Auto ID Ltd, Church Road, Weston on the Green, Oxfordshire OX25 3QP. We cannot take responsibility for units returned in alternative packaging. - Page 26 Axicon Auto ID Limited | 15000 series verifier user guide | June 2018 Page 26 of 28...
-
Page 27: Certificate Of Conformance
Authorised signatory Signatory Name At or before the expiry date the verifier should be returned to Axicon for its annual servicing. This VCAS (verifier conformance and alignment service) will ensure that the verifier remains conformant to ISO/IEC 15426-1 and ISO/IEC... -
Page 28: Contact
+44 (0) 1869 351 155 Fax: +44 (0) 1869 351 205 Email: info@axicon.com Website: www.axicon.com As Axicon continually improves its products, their specifications and features are subject to change without notice. All trademarks are acknowledged as belonging to their respective companies. Your Axicon distributor...
