- Page 1 AXICON 2D BARCODE VERIFIER DOCUMENTATION BOOKLET www.axicon.com...
-
Page 3: Table Of Contents
Running the application User Calibration Explanation of the ISO parameters Saving and retrieving results AXICON SOFTWARE LICENCE AGREEMENT AND TERMS (INCL DISCLAIMER ETC) AXICON WARRANTY AND SERVICE CONTRACT Warranty on all Products Service Contract - 1 -... - Page 4 VERIFIER SERVICING & FACTORY RECALIBRATION (VCAS) Axicon Factory Recalibration Service (VCAS) Other faults or damage Equipment Rental Scheme VCAS RECORD CONTACT US - 2 -...
-
Page 5: Axicon Verifier Password Certificate
(Electromagnetic Compatibility), 73/23/EEC (Low Voltage), based on our own relevant test reports. Axicon Auto ID Ltd also certifies that this equipment, when used in conjunction with the latest software, has all of the features necessary to meet the 21CFR Part 11 requirements. - Page 6 - 4 -...
- Page 7 This Axicon Verifier is a precision piece of quality control equipment. It has been manufactured to the highest standards through our ISO 9001 Quality Management System and has been thoroughly and extensively tested immediately prior to shipment. When used in accordance with the manufacturer’s...
-
Page 8: Important Information
The unit should be returned to Axicon or to your approved Axicon reseller for this check to be performed. 6. As the owner of an Axicon Verifier you are entitled to free software updates for life. The latest copy of the software is always posted on our website (www.axicon.com). -
Page 9: Introduction
The Axicon 2D Verifier is designed to work with any PC running Windows XP or later (including Vista and Windows 7). The Axicon 2D Verifier uses a high resolution camera to capture an image of a barcode symbol. It has... -
Page 10: What's In The Transit Case
• Wallet containing Documentation Booklet (includes Start Up Guide) and Calibration Sheet OPTIONAL EXTRAS Axicon also offer the following optional extras to be used in conjunction with the system:- - IQ/OQ Procedural Documentation - Performance Qualification Test Kit – Comprising a set of test cards traceable to international standards and full procedural instructions. -
Page 11: System Requirements
• USB 2.0 port • .NET Framework version 4.0 or later SOFTWARE INSTALLATION • The Axicon 2D Verifier application requires the .NET Framework version 4.0 or later to be installed. The Axicon software installation process will automatically check whether the .NET framework is present. If it is not present then the Axicon installation will install it for the user. -
Page 12: Running The Application
CD-ROM. RUNNING THE APPLICATION • Please note that on first use the password provided by Axicon for the hardware will be required. • When the application is launched it will first check to see whether the hardware is connected. - Page 13 • A red cross indicates where the centre of the camera image lies and the barcode should be located such that it is positioned roughly in the centre of this view. If the barcode extends to the edge of the camera view, then it may not be possible to achieve a decode of the symbol.
-
Page 14: User Calibration
It is not necessary to use a Data Matrix symbol for the calibration. The default values for the maximum and minimum reflectance values used for the calibration are those of the Axicon Calibration Card, but if an alternative reference test card is used then the known reflectance values used for the calibration process can be changed by going to the appropriate setup window. - Page 15 DISPLAYING THE RESULTS • The Summary Window will show an overall view of the quality of the barcode that has been decoded. A quality grade is shown, along with the aperture and illumination that has been used when making the analysis. The amount of print gain that has been measured is shown, in both X and Y directions and this will be a positive value if dark modules have grown in size or a negative value if the dark modules are...
- Page 16 data content, a pass or fail message being indicated on the Summary Window. • A Details Window provides a more in depth report on the individual parameters that have been measured and graded while analyzing the barcode. • Where appropriate, percentage measurements are displayed and for each of the ISO parameters that have been checked a grade is also displayed.
-
Page 17: Explanation Of The Iso Parameters
EXPLANATION OF THE ISO PARAMETERS • The parameters which are measured according to the method described in ISO/IEC 15415 for 2D matrix barcodes results in a grade for each parameter, with a grade of 4 being the best and a grade of 0 being a fail. -
Page 18: Saving And Retrieving Results
• Axial non-uniformity is a measure of the consistency of the grid spacing comparing one axis with the other. An elongation in one direction compared to the other results in a poor grade. • Grid non-uniformity is the worst case positional error of the centre of a module from its ideal grid position. -
Page 19: Axicon Software Licence Agreement And Terms
AXICON SOFTWARE LICENCE AGREEMENT This software is Copyright © 1995-2014 Axicon Auto ID Limited Use of the Software is subject to the Axicon Software Licence terms set forth below. Using the Software indicates your acceptance of these Licence terms. If you do not accept these Licence terms within 14 days, you may return the entire unused product for a full refund. - Page 20 The transferee must accept these Licence Terms as a condition of the transfer. TERMINATION Axicon may terminate your Licence upon notice of failure to comply with any of these Licence Terms. Upon termination, you must immediately destroy the Software, together with all copies, adaptations and merged portions in any form.
- Page 21 However since we have no control over the circumstances in which you might use the Verifier, you must satisfy yourself that the performance of the Verifier is suitable for your needs. Neither Axicon Auto ID Limited nor the vendor of this Verifier can accept any liability for any loss or damage (consequential or otherwise) which may be caused by use of this Verifier.
- Page 22 - 20 -...
-
Page 23: Axicon Warranty And Service Contract
AXICON WARRANTY AND SERVICE CONTRACT WARRANTY ON ALL PRODUCTS The Axicon 2D verification equipment is sold with a one year parts and labour warranty against manufacturing defects. This is a Return to Bench warranty with shipping costs in one direction being borne by the customer/distributor. -
Page 24: Service Contract
The availability of a swap-out unit to be used while the customer’s unit is being repaired. NOTE: Please see your Service Contract for full details including hire charges. For current cost of a Service Contract or equipment hire please contact either Axicon or your approved Axicon reseller. - 22 -... - Page 25 Should you decide not to take advantage of this service, we must remind you that Axicon Auto ID Ltd is unable to accept any responsibility for non- compliance to the appropriate GS1 STANDARDS once your verifier has exceeded the standard guarantee period provided on date of purchase.
- Page 26 EQUIPMENT RENTAL SCHEME Axicon Auto ID Ltd also offers an equipment rental scheme for customers who require replacement equipment for the duration of the service Please contact us for further details.
- Page 27 For service and support in the Americas please log on to www.axicon.com for contact details Due to Axicon’s continuing product improvement programs, specifications and features herein are subject to change without notice. All trademarks are acknowledged as belonging to their respective companies.
- Page 28 VCAS SERVICE RECORD Verifier Model Serial Number Date Service Serial no. of Name & Undertaken calibration card Signature A x i c o n A u t o I D L i m i t e d Company Registration Number: 2003365 2D Verifier Documentation Booklet VAT Registration Number: GB 578651102 Version 4–...
