Cleveland KGL-25 Specifications

™
Cleveland
GAS KETTLES
LEG TYPE, GAS-FIRED KETTLES
STATIONARY, 2⁄3 STEAM JACKETED
"SPLASH PROOF SERIES"
25 GALLONS (100 LITERS)
Cleveland Standard Features
I
Self-contained gas stationary kettle is easily installed, only
needs a gas connection and a 115 volt outlet.
I
Precise, consistent temperature control, less than 1ºC
temperature variance (ideal for simmering). Operating
temperature range from 145ºF-260ºF (63ºC-127ºC).
I
"Splash-Proof" Solid-State Control Panel for temperature, Low
Water Safety, and Power "On/Off" Switch. Accurate L.E.D.
Indicators for Heat Cycle and Low Water Warning.
I
Kettle and all exterior surfaces are a 304 Stainless Steel with
a #4 finish.
I
Energy efficient (65%), high performance gas-fired heating
system for fast heat-up and recovery time:
I
Twenty-five gallon model with 90,000 BTU firing rate and
58,500 BTU directly applied to the product.
I
Supplied with Gas Pressure Regulator.
I
Standard for natural gas operation.
I
Heavy-duty Rolled Rim design provides strong reinforcement,
prevents damages from abuse.
I
"Splash-Proof" rear-mounted pressure/vacuum gauge.
I
Steam jacket permanently filled with treated distilled water;
venting and/or refilling is not required.
I
50 psi Steam Jacket Rating. Safety Valve mounted toward
rear of kettle to avoid tampering.
I
Automatic Electronic Spark Ignition System.
I
Supplied with cord and plug for 115 volt controls.
I
Support Legs with level adjustable feet, flanged for floor
bolting.
I
Spring Assist Cover and 2" tangent draw-off are standard.
I
Typical approvals include AGA, CSA, CE, NSF and ASME.
Options & Accessories
Ë 316 Stainless Steel Liner (316)
Ë Propane Gas Option (LP)
Ë Kettle Markings (KM)
Ë Lift Off Cover (CL)
Ë Basket Strainer (BS and TBS)
Ë Measuring Strip (MS)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900 Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782 Email: Steam@ClevelandRange.com
MODEL: KGL-25
Short Form Specifications
Shall be CLEVELAND, Gas Kettle, self-contained, Stationary, Model KGL-25;
25 gallons, natural or LP gas, 2/3 Steam Jacketed, Type 304 Stainless Steel
and supports. Jacket rated at 50psi with Safety Valve. Complete with
"Splash-Proof" Solid-State Water Level, Temperature, and Safety Low Water
Power Cut-Off, including L.E.D. Indicators for Heat Cycle and Low Water
Warning.
Ë Food Strainer (FS)
Ë Hot and cold water faucet (DPK), or cold water (SPK).
Ë Kettle Accessory Kit (KAK) includes:
Ë Clean-up Brush (CB)
Ë 36˝ Kettle Whip (KW)
Ë Draw-Off Brush (DB)
Ë Correctional Packages
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
Ë 36˝ Kettle Paddle (KP)
Ë 36˝ Kettle Brush
Ë 24 oz. Ladle (KL)
IX
SECT. PAGE
5
0707
