OPERATING MANUAL
WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities contains chemicals
known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work
with approved safety equipment, such as those dust masks
that are specially designed to filter out microscopic particles.
CAT6100BP
WARNING INFORMATION
•
bluePOWER
1" Pistol Grip Impact Wrench
®
PARTS LIST
•
SPECIFICATIONS
Max. Free Speed .............................................6,000 RPM (Reverse)
Max Torque ...................................................................2,000 ft. lbs.
Breakaway Torque ........................................................2,700 ft. lbs.
Air Inlet ............................................................................. 1/2" NPT
Recommended Hose Size .................................................. 1/2" I.D.
Avg. Air Cons. ......................................................................7.5 CFM
Max. Air
Pressure ...............................................................90 PSIG (6.2 BAR)
Weight (w/side handle) ...................................................... 12.7 lbs.
Length .................................................................................... 10.25"
Width (w/o side handle) ........................................................ 4.375"
Height ..................................................................................... 10.25"
Copyright © Professional Tool Products, 2019
CAT6100BP
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
All rights reserved
03/28/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools bluePOWER CAT6100BP
Summary of Contents for Cornwell Tools bluePOWER CAT6100BP
- Page 1 CAT6100BP bluePOWER 1" Pistol Grip Impact Wrench ® OPERATING MANUAL WARNING INFORMATION PARTS LIST • • WARNING ALWAYS READ INSTRUCTIONS BEFORE USING POWER TOOLS ALWAYS WEAR SAFETY GOGGLES ALWAYS WEAR HEARING PROTECTION AVOID PROLONGED EXPOSURE TO VIBRATION WARNING SPECIFICATIONS Some dust created by power sanding, sawing, grinding, Max.
- Page 2 Use hear ing pro tec tion as rec om mend ed by your em ploy er or OSHA reg u la tion. • Use accessories recommended by Cornwell Tools. • Keep the tool in ef fi cient op er at ing con di tion.
-
Page 3: Air Supply
CAT6100BP bluePOWER 1" Pistol Grip Impact Wrench ® OPERATION Air Supply Whip Hose Do Not Install Filter Quick Coupling Nipple Nipple This tool is an impacting tool and not a torque meter. When specific Here torque is required, it must be checked with a torque meter after fitting the fastener with the impact. -
Page 4: Warranty Coverage
CAT6100BP bluePOWER 1" Pistol Grip Impact Wrench ® WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials. -
Page 5: Parts List
CAT6100BP bluePOWER 1" Pistol Grip Impact Wrench ® PARTS LIST Item Part No Parts Name Item Part o Parts Name RS61001C HOUSING WITH GRIP - BLUE RS110119 SPRING PIN RS110101 TRIGGER RS110120 CYLINDER RS110102 SPRING PIN RS110121 ROTOR RS110103 OIL SEAL SPRING (Included with #25) RS110104 PIN VALVE ROD...
