Operating Instructions • Warning Information • Parts Breakdown
Breakaway Torque ..................................600 Ft./Lbs.
Working Torque Range ..................... 25-350 Ft./Lbs.
Maximum Applied Torque ..................... 370 Ft./Lbs.
Free Speed ............................................. 11,500 RPM
Avg. Air Consumption .................................. 2.5 cfm
Overall Length ................................................ 5-3/4"
Weight ............................................................2.4 lbs.
Air Inlet (NPT) .................................................... 1/4"
Recommended Hose Size .................................. 3/8"
Sound Level ................................................ 93.5 dBA
WARNING
RATED RPM OF THE ACCESSORY
USED MUST EXCEED THE MAXIMUM
TOOL RPM SHOWN
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
CAT2150 / CAT2150G
SPECIFICATIONS
WARNING
CAT2150
CAT2150G
Super Duty 3/8" Dr.
Composite Impact
Wrench
Copyright © Professional Tool Products, 2018
All rights reserved
05/30/18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cornwell Tools blue POWER CAT2150
Summary of Contents for Cornwell Tools blue POWER CAT2150
- Page 1 Operating Instructions • Warning Information • Parts Breakdown SPECIFICATIONS Breakaway Torque ........600 Ft./Lbs. Working Torque Range ..... 25-350 Ft./Lbs. Maximum Applied Torque ..... 370 Ft./Lbs. Free Speed ..........11,500 RPM Avg. Air Consumption ........2.5 cfm Overall Length ..........5-3/4" Weight ............2.4 lbs.
- Page 2 If the manual or product labels are lost kept away from tool and accessories. or not legible, contact Cornwell Tools for replacements. • Note direction of rotation BEFORE operating this tool. If the operator is not fluent in English, the product and •...
-
Page 3: Operation
Operating Instructions • Warning Information • Parts Breakdown OPERATION WARNING The forward and reverse valve can be used as an air throttle, Always turn off the air supply, drain hose of air pressure if there are no other means of regulating air. Turn the valve and detach tool from air supply before installing, removing knob all the way to position 3 for maximum power. -
Page 4: Warranty & Service
WARRANTY Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials. - Page 5 PARTS BREAKDOWN - CAT2150 / CAT2150G ITEM PART NO PART NAME ITEM PART NO PART NAME RS2125101 HAMMER CASE RS2125401 TRIGGER A RS1081103 HAMMER CASE BUSHING RS2125402 SPRING PIN RS1734201 SOCKET RETAINER RS3125403 TRIGGER BUSHING RS2150104A O-RING RS4150405 PUSHER SPRING RS1081106A ANVIL ASSEMBLY (incl #103 &...
