OPERATING MANUAL
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
Tool Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.75"
Tool Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.50"
Tool Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.88"
Tool Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.71 lb
Maximum Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . 8750 RPM
Maximum Torque/Applied . . . . . . . . . . . . . . . . . . . . . . . 350 ft-lbs
Breakaway Torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 575 ft-lbs
Sound Pressure Level . . . . . . . . . . . . . . . . . . . . . . . . . . 97.8 dBA
Vibration Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.69 m/s²
Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3 cfm
Recommended Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" ID
Air Inlet Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4" NPT
CAT2238/CAT2238G
3/8" bluePOWER
WARNING INFORMATION
•
WARNING
SPECIFICATIONS
-Save these instructions-
3/8" bluePOWER
®
®
STUBBY IMPACT WRENCH - GREEN
PARTS LIST
•
1
CAT2238 / CAT2238G
STUBBY IMPACT WRENCH
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO
VIBRATION
Copyright © Professional Tool Products, 2019
All rights reserved
REV: 12/10/19
Advertisement
Table of Contents
Related Manuals for Cornwell Tools bluePOWER CAT2238
Summary of Contents for Cornwell Tools bluePOWER CAT2238
- Page 1 CAT2238 / CAT2238G 3/8" bluePOWER ® STUBBY IMPACT WRENCH 3/8" bluePOWER ® STUBBY IMPACT WRENCH - GREEN OPERATING MANUAL WARNING INFORMATION PARTS LIST • • WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm.
- Page 2 Use hear ing pro tec tion as rec om mend ed by your em ploy er or OSHA reg u la tion. • Use accessories recommended by Cornwell Tools. • Keep the tool in ef fi cient op er at ing con di tion.
-
Page 3: Air Supply
CAT2238 / CAT2238G 3/8" bluePOWER ® STUBBY IMPACT WRENCH 3/8" bluePOWER ® STUBBY IMPACT WRENCH - GREEN OPERATION Air Supply Whip Hose Do Not Install Filter Quick Coupling Nipple Nipple This tool is an impacting tool and not a torque meter. When specific Here torque is required, it must be checked with a torque meter after fitting the fastener with the impact. -
Page 4: Warranty Coverage
CAT2238 / CAT2238G 3/8" bluePOWER ® STUBBY IMPACT WRENCH 3/8" bluePOWER ® STUBBY IMPACT WRENCH - GREEN WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. -
Page 5: Parts List
CAT2238 / CAT2238G 3/8" bluePOWER ® STUBBY IMPACT WRENCH 3/8" bluePOWER ® STUBBY IMPACT WRENCH - GREEN PARTS LIST Item No. PART NO DESCRIPTION Item No. PART NO DESCRIPTION RS223801 HAMMER CASE ASS'Y (Incl. 102&109) STEM SEAL RS223802 ANVIL BUSHING STEM BUSHING RS223863 SOCKET RETAINER...
