McFarlane HDL-1000 Series Operator's Manual And Parts List

Hide thumbs

Table Of Contents

Quick Links

MANUFACTURERS OF QUALITY AGRICULTURAL EQUIPMENT SINCE 1936

OPERATOR'S MANUAL

AND

PARTS LISTING

FOR THE

HDL-1000 Series

version: 7-13 (MM-0300)

starting at serial number 18002

TO THE OWNER AND OPERATORS

Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best

performance of the unit, familiarize yourself with each component and adjustment. Store this manual

where it can be readily available for future reference. In the event that the harrow or any part of the

unit should be sold, be sure that the new owner receives a copy of this manual for their reference.

1330 Dallas Street · PO Box 100 · Sauk City WI 53583

Phone (608) 643-3321 · Toll Free (800) 627-8569 · Fax (608) 643-3976

www.flexharrow.com

Table of Contents

Need help?

Do you have a question about the HDL-1000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for McFarlane HDL-1000 Series

Page 1 MANUFACTURERS OF QUALITY AGRICULTURAL EQUIPMENT SINCE 1936 OPERATOR’S MANUAL PARTS LISTING FOR THE HDL-1000 Series version: 7-13 (MM-0300) starting at serial number 18002 TO THE OWNER AND OPERATORS Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best performance of the unit, familiarize yourself with each component and adjustment. Store this manual where it can be readily available for future reference.
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION .......................3 LIMITED WARRANTY .....................3 SAFETY ..........................4 CONTACT INFORMATION ....................5 LIGHTING AND MARKING .....................6 SAFETY SIGN CARE ......................7 TIRE SAFETY........................7 BEFORE OPERATION....................7 - 8 DURING OPERATION ....................8 - 9 FOLLOWING OPERATION ....................9 HIGHWAY AND TRANSPORT OPERATIONS ............9 - 10 PERFORMING MAINTENANCE ...................10 MAINTENANCE AND SERVICE SCHEDULE .............11 OPERATING SUGGESTIONS..................11...
Page 3: Introduction
HDL-1000 Series If within one year from the date of purchase, this transport cart and/or its accompanying harrow sections fail due to defect in material or workmanship, McFarlane Mfg. Co., Inc. will repair it, free of charge. Warranty service is available by simply contacting the nearest McFarlane dealership throughout the United States or Canada.
Page 4: Safety
SAFETY TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS ...
Page 5: Contact Information
CONTACT INFORMATION If you have questions not answered in this manual, require additional copies, or the manual is damaged, please contact your local dealer or: McFarlane Mfg. Co., Inc. 1330 Dallas Street P.O. Box 100 Sauk City, WI 53583 PHONE:...
Page 6: Lighting And Marking
SAFETY FIRST! Equipment Safety Guidelines Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
Page 7: Tire Safety
How to Install Safety Signs:  Be sure that the installation area is clean and dry.  Decide on the exact position before you remove the backing paper. Tire Safety  Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may result in serious injury or death.
Page 8: During Operation
 Securely attach to towing unit. Use a high strength, appropriately sized hitch pin with a mechanical retainer and attach safety chain.  Do not allow anyone to stand between the tongue or hitch and the towing vehicle when backing up to the equipment. During Operation: ...
Page 9: Following Operation
Following Operation:  When disconnecting, stop the tractor or towing vehicle, set the brakes, secure the wings in the wing rests, relieve hydraulic fluid pressure, shut off the engine and remove the ignition keys. Make sure all jack and support stands are in place before removing hitch pins. ...
Page 10: Performing Maintenance
 Be observant of bridge loading ratings. Do not cross bridges rated lower than the gross weight at which you are operating.  Watch for obstructions overhead and to the side while transporting.  Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased length and weight of the equipment when making turns, stopping, etc.
Page 11: Maintenance And Service Schedule
OPERATING SUGGESTIONS There are some important points to remember in order to obtain the best possible results from your McFarlane harrow.  To maximize the harrow’s performance, it should be towed at speeds ranging from six to nine (6 - 9) mph. This keeps the field debris moving through the harrow sections and avoids clogging.
Page 12: Assembly Suggestions
ASSEMBLY SUGGESTIONS  You will find the machine is easier to assemble if the set-up instructions are followed in the order given in the manual.  Before beginning, sort the various bolt bags, hardware bags and hydraulic bags according to what part of the unit that is being setup.
Page 13: Assembly Instructions
STEP - BY - STEP ASSEMBLY INSTRUCTIONS Main Frame Assembly 1. Bolt the Square Frame to the A-frame. Use 5/8” x 2” bolts (5/8” x 2 ¼ on 1048 through 1060), lock washers, and hex nuts. 2. Bolt the Axle Brackets to the main frame. Use 5/8” x 2” (5/8” x 2 ¼ on 1048 through 1060) bolts, lock washers, and hex nuts.
Page 14 CLEVIS HITCH PINTLE HITCH TOP PLATE BASE HITCH CUSHION V-PLATE CLEVIS 3/4" x 5" BOLT 3/4" x 2 1/2" BOLT AND LOCK NUT BASE HITCH Figure 2 Figure 3 Attach the Wing Rests HDL-1024 though HDL-1038 Attach the wing rests to the square frame. Refer to Figure 4. Use four 5/8" x 6" x 5 ½" U- bolts, lock washers, and hex nuts.
Page 15 Attach the wing rests to the square frame. Refer to Figure 4a. Use eight 5/8" x 5" bolts, lock washers, hex nuts and a wing rest clamp plate on each side of the square frame. Do not tighten yet. The distance (“D” in Figure 4.) from square frame splice plate to the wing rest mounting plate varies with the model (note that for models HDL-1048 through HDL-1050 the wing rest is bolted directly to the square frame behind the splice plates): HDL-1040...
Page 16 CENTER BAR HINGE PLATE CYLINDER PINS CENTER BAR SQUARE FRAME HINGE PIN BOLT & NUT Figure 5 Attach the Wings to the Center Bar WING HINGE PIN CENTER BAR LEFT WING Figure 6 Attach the wings to the center bar using two 1 ½” x 8 5/16” hinge pins and the ½” x 3” grade 8 bolts and locking hex nuts.
Page 17 Figure 7 The remainder of the assembly steps (except for the wing cable attachment and the cable lift attachment) can be done in either the transport or field position. Because most people will assemble the unit in the field position (and it is recommended that you do), for clarity, the following diagrams show the unit in the field position.
Page 18 Figure 8 Install the Wing Hydraulics Refer to Figure 9 and the hydraulic system schematic in appendix B for more details. 1. Insert a 3/8”m – 1/2o-ring elbow with restrictor into each of the base end ports on the 14” stroke cylinders.
Page 19 Figure 9 Harrow Configurations McFarlane harrow sections may be attached in any one of several distinct configurations: 8-bar, 4+4-bar, 12-bar, 6+6-bar, 16-bar, and 8+8-bar. The 8, 12, and 16-bar harrow configurations utilize a single set of pull points located adjacent to the center bar and wings. The 4+4, 6+6, and 8+8-bar harrow configurations (also known as dual sections) also utilize a second set of pull points located at the rear end of the lift arms.
Page 20 TOOL BAR 1/2 X 9 1/2 BOLTS, LOCK WASHERS AND HEX NUTS PLACEMENT MARK LIFT ARMS Figure 10 8 OR 10-LINK PULL CHAIN 1/2" x 2" BOLT, LOCK WASHER, AND HEX NUT Figure 11 3. Bolt an 8 or 10-link pull chain in between each of the lift arm pull points. (10-link for 8-bar harrow sections;...
Page 21 1/2" x 2" BOLT, LOCK WASHER, AND HEX NUT LIFT ARM 8-LINK LIFT CHAIN Figure 12 LIFT ARM REAR PULL POINT ASSEMBLY 1/2" x 2" BOLT, LOCK WASHER, AND HEX NUT 1/2" x 3" BOLTS & LOCK NUTS 8-LINK PULL CHAIN Figure 13 5.
Page 22 Refer to Figure 15 to help clarify what is meant by ‘angle of attack.’ McFarlane flexible harrow sections have a built-in system which allows the harrow owner a choice between a steep or shallow angle of attack. To change the angle of attack, simply reverse the harrow section and pull it from the other end.
Page 23 Harrow Identification The number of teeth on a bar is the same as the first digit of the harrow identification number. The last number is the number of bars per section. An FH-600-8 would have six teeth per bar and 8 bars;...
Page 24 LIFT ARM HEX NUT REAR HARROW BAR LOCK WASHER FLAT WASHER 1/2" X 1 1/2" BOLT Figure 17 Connect a 12 or 16-Bar Section 1. Bolt the pull chains to the front tabs on the front harrow sections. Refer to Figure 16. Use ½” x 1 ½”...
Page 25 LIFT ARM 7/16" V-BOLT DUAL SECTION CONNECTOR LINKS REAR SECTION FRONT SECTION 1/2" x 2" BOLTS Figure 18 LIFT REAR SECTION 1/2" x 1 1/2" BOLTS, FLAT WASHERS, LOCK WASHERS, AND HEX NUTS FRONT SECTION Figure 19 Connect 4+4, 6+6 or 8+8 Sections 1.
Page 26 2. Bolt the lift chains to the bottom of the rear lift tabs of the front harrow sections. Refer to Figure 19. Use ½” x 1 ½” bolts, flat washers, lock washers, and hex nuts. 3. Make sure that the harrow sections match each other, the angle of attack is correct, and the chains are not twisted.
Page 27 Figure 21 Attach the Wing Cable Lift Assembly 1. Bolt the cable lift bracket to the A-Frame just ahead of the wing cable bracket located on the side of the A-Frame. Refer to Figure 22. Use two1/2 x 4” x 7 1/4” U-bolts, lock washers, and hex nuts.
Page 28 Figure 22 Adjust the Wing Rests Adjust the position of the wing rests so that they provide support to the wings while in the transport position. Refer to Figure 23. Move them either backward or forward on the square frame until the wings rest solidly on the wing rest plate. If necessary, adjust the clevis on the main frame cylinder in/out to move the wings up/down.
Page 29: Final Adjustments
Final Adjustments 1. Unfold the unit into the field position. 2. Pull the completed unit ahead a few feet to check that everything is properly assembled and that nothing is binding or misaligned. 3. Check to make sure that all bolts and fasteners are tight. 4.
Page 30: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Hydraulics actuate too rapidly Hydraulic restrictors not Install hydraulic restrictors installed Wings will not slide into wing Wing rests improperly Reposition wing rests rests positioned Main hinge plate stop bolt Readjust hinge plate stop bolt maladjusted Excessive clogging during Angle of attack too steep...
Page 31: Bolt & Tire Specifications
BOLT TORQUE SPECIFICTIONS Coarse Thread Series Fine Thread Series Nut Size Nut Size and Threads Tightening and Threads Tightening per Inch Torque per Inch Torque (lb.ft.) (lb.ft.) Grade C Nuts Grade C Nuts Max. Min. Max. Min. 1/4 - 20 14.7 1/4 - 28 14.7...
Page 32 HDL-1024 through HDL-1038 HARROW CART PARTS DIAGRAM APPENDIX B...
Page 33 HDL-1024 through HDL-1038 HARROW CART PARTS LIST Always order by Part Number - Not by Key Number PART # DESCRIPTION QTY. PPI-300 BASE HITCH PPI-208 CLEVIS PPI-201 HITCH CUSHION PPI-203 HITCH V-PLATE, CAT II-IV HD-1151 JACK STAND (10") HDL-2110 A-FRAME (HDL-1024 through HDL-1036) HDL-2120 A-FRAME (HDL-1038 only) CP-3620...
Page 34 Unnumbered items are not pictured. Please specify model number when ordering these parts. length in inches (84" is 084, 112" is 112) McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 35 HDL-1040 THROUGH HDL-1050 HARROW CART PARTS DIAGRAM APPENDIX B...
Page 36 HDL-1040 through HDL-1050 HARROW CART PARTS LIST Always order by Part Number - Not by Key Number PART # DESCRIPTION QTY. PPI-300 BASE HITCH PPI-208 CLEVIS HD-1151 JACK STAND (10") PPI-201 HITCH CUSHION PPI-203 HITCH V-PLATE, CAT II-IV HDL-2132 A-FRAME, HDL-1040 through HDL-1046 only HDL-2160 A-FRAME, HDL-1048 &...
Page 37 Unnumbered items are not pictured. Please specify model number when ordering these parts. length in inches (84" is 084, 112" is 112) McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 38 HDL-1052 THROUGH HDL-1060 HARROW CART PARTS DIAGRAM APPENDIX B...
Page 39 HDL-1052 through HDL-1060 HARROW CART PARTS LIST Always order by Part Number - Not by Key Number PART # DESCRIPTION QTY. PPI-300 BASE HITCH PPI-208 CLEVIS HD-1151 JACK STAND (10") PPI-201 HITCH CUSHION PPI-203 HITCH V-PLATE, CAT II-IV HDL-2160 A-FRAME, HDL -1048-1060 BU-1249 U-BOLT (1/2"...
Page 40 Quantity depends on harrow sections used. Unnumbered items are not pictured. Please specify model number when ordering these parts. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 41 FH 8-BAR HARROW SECTIONS PARTS DIAGRAM & LISTING INCLUDES FH-500-8, FH-600-8, FH-700-8, FH-800-8, AND FH-900-8 16 BAR 4+4 SECTION SECTION ONLY ONLY FH-700-8 SHOWN ITEM # PART # DESCRIPTION FH-801 #1 HARROW BAR (FH-500-8) FH-805 #1 HARROW BAR (FH-600-8) FH-809 #1 HARROW BAR (FH-700-8) FH-813 #1 HARROW BAR (FH-800-8)
Page 42 FH-820 #4 HARROW BAR (FH-900-8) FH-803 #5 HARROW BAR (FH-500-8) FH-807 #5 HARROW BAR (FH-600-8) FH-811 #5 HARROW BAR (FH-700-8) FH-815 #5 HARROW BAR (FH-800-8) FH-819 #5 HARROW BAR (FH-900-8) FH-803 #6 HARROW BAR (FH-500-8) FH-807 #6 HARROW BAR (FH-600-8) FH-811 #6 HARROW BAR (FH-700-8) FH-815...
Page 43 FH 6-BAR HARROW SECTIONS PARTS DIAGRAM & LISTING INCLUDES FH-500-6, FH-600-6, FH-700-6, FH-800-6, AND FH-900-6 ITEM # PART # DESCRIPTION FH-830 #1 HARROW BAR (FH-500-6) FH-832 #1 HARROW BAR (FH-600-6) FH-834 #1 HARROW BAR (FH-700-6) FH-836 #1 HARROW BAR (FH-800-6) FH-838 #1 HARROW BAR (FH-900-6) FH-804...
Page 44 FH-834 #5 HARROW BAR (FH-700-6) FH-836 #5 HARROW BAR (FH-800-6) FH-838 #5 HARROW BAR (FH-900-6) FH-804 #6 HARROW BAR (FH-500-6) FH-808 #6 HARROW BAR (FH-600-6) FH-812 #6 HARROW BAR (FH-700-6) FH-816 #6 HARROW BAR (FH-800-6) FH-820 #6 HARROW BAR (FH-900-6) E-611 1/2”...
Page 45 3/8" x 180" HYDRAULIC HOSE w/restrictor & ½” end HYF-4002 HYD DISCONNECT, MALE Note: When ordering cylinder replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 46 (HDL-1048 & HDL-1050 only) HYF-4002 HYD DISCONNECT, MALE Note: When ordering cylinder replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 47 3/8" x 240" HYDRAULIC HOSE w/restrictor & ½” end HYF-4002 HYD DISCONNECT, MALE Note: When ordering cylinder replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 48 APPENDIX C...
Page 49 APPENDIX C...
Page 50 APPENDIX C...
Page 51 APPENDIX C...
Page 52 APPENDIX C...
Page 53 APPENDIX C...
Page 54 APPENDIX C...
Page 55 APPENDIX C...
Page 56 APPENDIX C...
Page 57 APPENDIX C...
Page 58 APPENDIX C...
Page 59 APPENDIX C...
Page 60 APPENDIX C...
Page 61 APPENDIX C...
Page 62 APPENDIX C...
Page 63 APPENDIX C...
Page 64 APPENDIX C...
Page 65 APPENDIX C...
Page 66 Notes...
Page 67: Warranty Registration Form
WARRANTY REGISTRATION FORM This form must be filled out by the dealer and owner and sent to: McFarlane Mfg. Co., Inc., 1330 Dallas Street, P.O. Box 100, Sauk City, WI 53583. WARRANTY REGISTRATION FORM & INSPECTION REPORT WARRANTY REGISTRATION This form must be filled out by the dealer and signed by both the dealer and customer at the time of delivery.
Page 70 Dealer Contact Information McFARLANE MANUFACTURING CO. INC. 1330 DALLAS STREET, P.O. BOX 100 SAUK CITY, WISCONSIN 53583 PHONE: (608) 643-3321 TOLL FREE: (800) 627-8569 FAX: (608) 643-3976 WEB: www.flexharrow.com...
