MANUFACTURERS OF QUALITY AGRICULTURAL EQUIPMENT SINCE 1936
OPERATOR'S MANUAL
AND
SET-UP INSTRUCTIONS
FOR THE
RBH-200-3 Series
232 Through 236 Models
VERSION: 9-12
Serial Number 16648
through 17875
TO THE OWNER AND OPERATORS
Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain
the best performance of the unit, familiarize yourself with each component and adjustment.
Store this manual where it can be readily available for future reference. In the event that the
harrow or any part of the unit should be sold, be sure that the new owner receives a copy of
this manual for their reference.
1330 DALLAS STREET, P.O. BOX 100
SAUK CITY, WISCONSIN 53583
PHONE: (608) 643-3321
TOLL FREE: (800) 627-8569 FAX: (608) 643-3976

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RBH-200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for McFarlane RBH-200 Series

Summary of Contents for McFarlane RBH-200 Series

  • Page 1 MANUFACTURERS OF QUALITY AGRICULTURAL EQUIPMENT SINCE 1936 OPERATOR’S MANUAL SET-UP INSTRUCTIONS FOR THE RBH-200-3 Series 232 Through 236 Models VERSION: 9-12 Serial Number 16648 through 17875 TO THE OWNER AND OPERATORS Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best performance of the unit, familiarize yourself with each component and adjustment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION .......................3 LIMITED WARRANTY .....................3 SAFETY ..........................4 CONTACT INFORMATION ....................5 LIGHTING AND MARKING .....................6 SAFETY SIGN CARE ......................7 TIRE SAFETY ........................7 BEFORE OPERATION ....................7 - 8 DURING OPERATION ....................8 - 9 FOLLOWING OPERATION ....................9 HIGHWAY AND TRANSPORT OPERATIONS ............9 - 10 PERFORMING MAINTENANCE ...................10 MAINTENANCE AND SERVICE SCHEDULE .............11 OPERATING SUGGESTIONS ..................11...

  • Page 3: Introduction

    RBH-200 Series If within one year from the date of purchase, this transport cart and/or its accompanying harrow sections fail due to defect in material or workmanship, McFarlane Mfg. Co., Inc. will repair it, free of charge. Warranty service is available by simply contacting the nearest McFarlane dealership throughout the United States or Canada.

  • Page 4: Safety

    SAFETY TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS ...

  • Page 5: Contact Information

    CONTACT INFORMATION If you have questions not answered in this manual, require additional copies, or the manual is damaged, please contact your local dealer or: McFarlane Mfg. Co., Inc. 1330 Dallas Street P.O. Box 100 Sauk City, WI 53583 PHONE:...

  • Page 6: Lighting And Marking

    SAFETY FIRST! Equipment Safety Guidelines Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.

  • Page 7: Tire Safety

    How to Install Safety Signs:  Be sure that the installation area is clean and dry.  Decide on the exact position before you remove the backing paper. Tire Safety  Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may result in serious injury or death.

  • Page 8: During Operation

     Securely attach to towing unit. Use a high strength, appropriately sized hitch pin with a mechanical retainer and attach safety chain.  Do not allow anyone to stand between the tongue or hitch and the towing vehicle when backing up to the equipment. During Operation: ...

  • Page 9: Following Operation

    Following Operation:  When disconnecting, stop the tractor or towing vehicle, set the brakes, secure the wings in the wing rests, relieve hydraulic fluid pressure, shut off the engine and remove the ignition keys. Make sure all jack and support stands are in place before removing hitch pins. ...

  • Page 10: Performing Maintenance

     Be observant of bridge loading ratings. Do not cross bridges rated lower than the gross weight at which you are operating.  Watch for obstructions overhead and to the side while transporting.  Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased length and weight of the equipment when making turns, stopping, etc.

  • Page 11: Maintenance And Service Schedule

    OPERATING SUGGESTIONS There are some important points to remember in order to obtain the best possible results from your McFarlane harrow.  To maximize the harrow’s performance, it should be towed at speeds ranging from six to nine (6 - 9) mph. This keeps the field debris moving through the harrow sections and avoids clogging.

  • Page 12: Assembly Suggestions

    ASSEMBLY SUGGESTIONS  You will find the machine is easier to assemble if the set-up instructions are followed in the order given in the manual.  Before beginning, sort the various bolt bags, hardware bags and hydraulic bags according to what part of the unit that is being setup.

  • Page 13: Assembly Instructions

    STEP - BY - STEP ASSEMBLY INSTRUCTIONS Main Frame Assembly 1. Bolt the Hitch Tube to the Main Frame using 1 x 8 bolts and lock nuts. Note that there are different positions for the Hitch Tube. 2. Insert the Hub and Spindle into the Main Frame and secure using ½ x 3 ½ bolts and lock nuts. Install the 11L tires.
  • Page 14 CLEVIS HITCH PINTLE HITCH TOP PLATE BASE HITCH CUSHION V-PLATE CLEVIS 3/4" x 5" BOLT 3/4" x 2 1/2" BOLT AND LOCK NUT BASE HITCH Figure 2 Figure 3 Attach the Center Bar 1. Attach the Center Bar to the Main Frame using 1 ¼ x 5 ½ bolts and nylon jam nuts. Install the 4 x 8 cylinders as shown.
  • Page 15 Attach and Assemble the Wing Frame 1. Attach the Wing Frame to the Center Bar using the 1 ¼ Hinge Pins and ½ x 3 bolts and lock nuts. 2. Insert a Hub and Spindle into the tube on the end of the Wing and secure using a ½ x 3 ½ bolt and lock nut.
  • Page 16 7. Attach the 265” to the rod end of the 4 x 8 cylinder on the right hand side of the unit. Attach the 276” hose to the base end and then run both hoses to the hitch. 8. Secure all hoses to the frame to prevent damage between moving parts or from contacting the ground.
  • Page 17 Attach the Swing Arm and Pivot Bracket 1. Attach the Tension Spring to the Eye Bolt and Swing Arm using the Lock Clips, 7/16 x 1 1/2 bolts with locking nuts, one link chain and 1/2 x 1 3/4 bolt and locking nut. 2.
  • Page 18 Figure 7 Connect the Harrow Section 1. Bolt the pull chains to the front tabs on the front harrow sections. Use 1/2 x 1 3/4 bolts, square washers and lock nuts. The chains should be bolted to the bottom of the pull tabs. 2.
  • Page 19 Attach the Rolling Basket 1. Refer to the appropriate layout diagram in appendix C. Note the dimensions for the rolling basket locations. 2. Bolt the Rolling Basket to the Swing Arm Bracket using 1/2 x 3 x 4 U-bolts and lock nuts. Start with the Baskets centered on the two Lift Arms.
  • Page 20 Attach the Wing Cables 1. Open both wings so that they are straight out and in line with the center bar. Rotate the harrow sections down into the field position. 2. Attach one end of the Wing Cable to the plate on the Wing with a large shackle. 3.
  • Page 21 Figure 12 Attach the Wing Rests Place the Wing Rests approximately 18” ahead of the cylinder post on the Main Frame. Bolt firmly in place using the 5/8 x 6 x 4 U-bolts and lock nuts. Do not tighten yet.

  • Page 22: Final Adjustments

    Figure 13 Final Adjustments 1. Unfold the unit into the field position and fully extend all cylinders. 2. Slowly fold the unit into the transport position. Be sure the Wing Frames engage the ramp on the Wing Rest and fully sit on it. It may be necessary to adjust the Wing Rest back/forward. It may also be necessary to adjust the stroke control collar on the 4x8 main lift cylinders.

  • Page 23: Troubleshooting

    This completes the assembly of your harrow and transport cart. Before using the unit, double check that all components have been assembled properly. If there are any questions regarding any of the assembly steps, contact your local dealer for an explanation. Do not operate this or any equipment unless you are sure that all components operate as they were designed to operate.
  • Page 24 BOLT TORQUE SPECIFICTIONS Coarse Thread Series Fine Thread Series Nut Size Nut Size Tightening Tightening Threads Torque Threads Torque per Inch (lb.ft.) per Inch (lb.ft.) Grade C Nuts Grade C Nuts Max. Min. Max. Min. 1/4 - 20 14.7 1/4 - 28 14.7 5/16 - 18 22.3 15.2...
  • Page 25 RBH-232 through RBH-236 HARROW CART PARTS DIAGRAM APPENDIX B...
  • Page 26 HDL-236 WING CABLE PULL BRACKET, RIGHT Unnumbered items are not pictured. Please specify model number when ordering these parts. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
  • Page 27 LIFT ARM, DOUBLE BASKET PARTS DIAGRAM & LIST Always order by Part Number - Not by Key Number PART # DESCRIPTION RBH-237 3-BAR LIFT ARM – 58” RBH-234 LIFT ARM, DOUBLE BASKET ONLY – 22” NLT-6311 5/8-11 TOP LOCK NUT CH-0808 8 LINK CHAIN HDD-016...
  • Page 28 FW-0050 1/2 FLAT WASHER NLT-5013 1/2 TOP LOCK NUT ROLLING BASKET Please specify model number when ordering these parts. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
  • Page 29 FA-3 BAR HARROW SECTIONS INCLUDES FA-500-3, FA-600-3, FA-700-3, FA-800-3 AND FA-900-3 KEY PART # DESCRIPTION FA-551 #1 HARROW BAR (FA-500-3) FA-651 #1 HARROW BAR (FA-600-3) FA-751 #1 HARROW BAR (FA-700-3) FA-851 #1 HARROW BAR (FA-800-3) FA-951 #1 HARROW BAR (FA-900-3) FA-556 #2 HARROW BAR (FA-500-3) FA-656...
  • Page 30 HYO-2103 1" x 3 1/2" CLEVIS PIN Note: When ordering replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
  • Page 31 RBH-232 LAYOUT DIAGRAM APPENDIX C...
  • Page 32 RBH-234 LAYOUT DIAGRAM APPENDIX C...
  • Page 33 RBH-236 LAYOUT DIAGRAM APPENDIX C...

  • Page 35: Warranty Registration Form

    WARRANTY REGISTRATION FORM This form must be filled out by the dealer and owner and sent to: McFarlane Mfg. Co., Inc., 1330 Dallas Street, P.O. Box 100, Sauk City, WI 53583. WARRANTY REGISTRATION FORM & INSPECTION REPORT WARRANTY REGISTRATION This form must be filled out by the dealer and signed by both the dealer and customer at the time of delivery.
