OPERATOR'S MANUAL

AND

PARTS LISTING

FOR THE

HDL-1100 Series

version: 11-16 (12366)

starting at serial number 20484

TO THE OWNER AND OPERATORS

Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best

performance of the unit, familiarize yourself with each component and adjustment. Store this manual

where it can be readily available for future reference. In the event that the harrow or any part of the

unit should be sold, be sure that the new owner receives a copy of this manual for their reference.

1330 Dallas Street ∙ PO Box 100 ∙ Sauk City WI 53583

Phone (608) 643-3322 ∙ Toll Free (888) 627-8569 ∙ Fax (608) 643-3976

www.flexharrow.com

Table of Contents

Need help?

Do you have a question about the HDL-1100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for McFarlane HDL-1100 Series

Page 1 OPERATOR’S MANUAL PARTS LISTING FOR THE HDL-1100 Series version: 11-16 (12366) starting at serial number 20484 TO THE OWNER AND OPERATORS Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain the best performance of the unit, familiarize yourself with each component and adjustment. Store this manual where it can be readily available for future reference.
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION .......................3 LIMITED WARRANTY .....................3 SAFETY ..........................4 CONTACT INFORMATION ....................5 LIGHTING AND MARKING .....................6 SAFETY SIGN CARE ....................6 - 7 TIRE SAFETY........................7 BEFORE OPERATION....................7 - 8 DURING OPERATION ......................8 FOLLOWING OPERATION ....................9 HIGHWAY AND TRANSPORT OPERATIONS ............9 - 10 PERFORMING MAINTENANCE ...................10 MAINTENANCE AND SERVICE SCHEDULE .............11 OPERATING SUGGESTIONS..................11...
Page 3: Introduction
HDL-1100 Series If within one year from the date of purchase, this transport cart and/or its accompanying harrow sections fail due to defect in material or workmanship, McFarlane Mfg. Co., Inc. will repair it, free of charge. Warranty service is available by simply contacting the nearest McFarlane dealership throughout the United States or Canada.
Page 4: Safety
SAFETY TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS ...
Page 5: Contact Information
CONTACT INFORMATION If you have questions not answered in this manual, require additional copies, or the manual is damaged, please contact your local dealer or: McFarlane Mfg. Co., Inc. 1330 Dallas Street P.O. Box 100 Sauk City, WI 53583 PHONE:...
Page 6: Lighting And Marking
SAFETY FIRST! Equipment Safety Guidelines Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
Page 7: Tire Safety
 Be sure that the installation area is clean and dry.  Decide on the exact position before you remove the backing paper. Tire Safety  Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may result in serious injury or death.
Page 8: During Operation
 Securely attach to towing unit. Use a high strength, appropriately sized hitch pin with a mechanical retainer and attach safety chain.  Do not allow anyone to stand between the tongue or hitch and the towing vehicle when backing up to the equipment. During Operation: ...
Page 9: Following Operation
Following Operation:  When disconnecting, stop the tractor or towing vehicle, set the brakes, secure the wings in the wing rests, relieve hydraulic fluid pressure, shut off the engine and remove the ignition keys. Make sure all jack and support stands are in place before removing hitch pins. ...
Page 10: Performing Maintenance
 Be observant of bridge loading ratings. Do not cross bridges rated lower than the gross weight at which you are operating.  Watch for obstructions overhead and to the side while transporting.  Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased length and weight of the equipment when making turns, stopping, etc.
Page 11: Maintenance And Service Schedule
OPERATING SUGGESTIONS There are some important points to remember in order to obtain the best possible results from your McFarlane harrow.  To maximize the harrow’s performance, it should be towed at speeds ranging from six to nine (6 - 9) mph. This keeps the field debris moving through the harrow sections and avoids clogging.
Page 12: Assembly Suggestions
ASSEMBLY SUGGESTIONS  You will find the machine is easier to assemble if the set-up instructions are followed in the order given in the manual.  Before beginning, sort the various bolt bags, hardware bags and hydraulic bags according to what part of the unit that is being setup.
Page 13: Assembly Instructions
STEP - BY - STEP ASSEMBLY INSTRUCTIONS Main Frame Assembly 1. Bolt the Axle Brackets to the main frame. You will have either the Standard Walking Axle or the optional Tandem Axle assemblies. Both are shown in Figure 1. Use 5/8” x 2 1/4” bolts, lock washers, and hex nuts.
Page 14 Figure 2 Figure 3 ATTACH SAFETY CHAIN 1. Attach the Safety Chain as shown in Figure 4. Figure 4...
Page 15 Attach the Hitch Weights to the Main Frame HDL-1124 only 1. Attach the Hitch Weights to the Main Frame as shown in Figure 5. Dimension from front of side tube to front of weight mount plate should be approximately 41. The weights must be far enough back so that the jack can turn 90 degrees and pin into the field position.
Page 16 Attach the Center Bar to the Main Frame Attach the center bar to the square frame. Refer to Figure 7. Use the (SPR-2712) 1 1/2” x 8 5/16” hinge pins for HDL-1124 - 1138, (RT-2107) 1 1/2” x 9 5/8” for HDL-1140 – 1150 and (RD-5061) 1 1/2”...
Page 17 Figure 8 Attach the Wing Wheels Attach the hub/spindle to the Axle Bracket using 1/2” x 3 1/2” grade 8 bolts and lock nuts. Mount the wheels to the wing frames. Be sure the valve stem is pointing towards the outside. Refer to Figure 9.
Page 18 Attach the Wing Cylinders 1. Attach the Guide Brackets to the wing cylinder posts. Carriage bolts must face outward. Use the 1 1/2” x 8 5/16” hinge pins, 1/2” x 3 1/2” grade 8 bolts, and locking hex nuts. Refer to Figure 10. 2.
Page 19 4. Attach the two hoses from the right side tee to the rear tee of the main lift cylinders. Be sure to run the hoses through the loops welded to the frame. 5. Attach the two hoses from the right side tee to the hitch. Be sure to install the restrictor on the tee with hoses going to the base end of the main cylinders.
Page 20 Before further assembly, the hydraulic system must be filled with oil. Attach the unit to a tractor and connect the hydraulic lines. Using hydraulic controls rotate the center bar and wings several times to fill the cylinders and hoses with oil. Figure 12 Install the Main Frame Hydraulics HDL-1152 through 1160...
Page 21 7. Secure these hoses to the Hitch Storage Bracket with the Hydraulic Clamps. Refer to the parts diagram in appendix B for details. Be sure to run the hoses through the loops welded to the frame. Install the Wing Hydraulics Refer to Figure 13 and the hydraulic system diagram in appendix B for more details.
Page 22 Harrow Configurations McFarlane harrow sections may be attached in any one of several distinct configurations: 8-bar, 4+4-bar, 12-bar, 6+6-bar, 16-bar, and 8+8-bar. The 8, 12, and 16-bar harrow configurations utilize a single set of pull points located adjacent to the center bar and wings.
Page 23 Figure 14 Figure 15...
Page 24 Attach the Rear Pull Points 1. Attach a rear pull point assembly to the rear end of each lift arm. Use four 1/2” x 3” bolt and lock nuts. Refer to Figure 16. 2. Bolt an 8-link pull chain to the end of the rear pull point assembly with a 1/2” x 2” bolt, lock washer, and hex nut.
Page 25 Refer to Figure 18 to help clarify what is meant by ‘angle of attack.’ McFarlane flexible harrow sections have a built-in system which allows the harrow owner a choice between a steep or shallow angle of attack. To change the angle of attack, simply reverse the harrow section and pull it from the other end.
Page 26 Figure 19 Figure 20...
Page 27 Connect a 12 or 16-Bar Section 1. Bolt the pull chains to the front tabs on the front harrow sections. Refer to Figure 19. Use 1/2” x 1 1/2” bolts, flat washers, and locking nuts. The chains should be bolted to the bottom of the pull tabs.
Page 28 Figure 22 Attach the Lighting See Figures 23, 24 and 25. 1. To attach the lighting package, have the unit in the field position. 2. Lay out the wire harness wishbone across the rear tube of the main frame. Route each side along the hydraulic hoses leading to the wing fold cylinders.
Page 29 7. Tighten the light assemblies to the lift arms. 8. Bolt the light plug storage receptacle to the hitch storage bracket using the 1/4 x 1 bolts. 9. Check to make sure that all the plugs are properly and securely connected and the wire harnesses will not become entangled during operation or when the unit is folded into transport position.
Page 30 Figure 24 Figure 25...
Page 31 Attach the SMV Sign 1. Attach the SMV mount plate to the first lift arm to the right of center using the 3/8 x 2 x 3.75 U-bolts and locking nuts. 2. Secure the SMV sign to the mounting plate using the 1/4-20 x 1 hex bolts, lock washers and hex nuts.
Page 32 Figure 27 Apply the Reflective Decals 1. Apply the red/orange fluorescent (DC-305) and the red retroreflective (DC-303) decals to the Center Bar as shown in Figure 28. Figure 28...
Page 33 2. Apply the amber retroreflective (DC-304) decals to both wings as shown in Figure 29. Figure 29 3. Apply the amber retroreflective (DC-304) decals to both of the forward most lift arms, so that they are visible from the front as shown in Figure 30. Figure 30...
Page 34: Final Adjustments
Final Adjustments 1. Unfold the unit into the field position. 2. Pull the completed unit ahead a few feet to check that everything is properly assembled and that nothing is binding or misaligned. 3. Check to make sure that all bolts and fasteners are tight. 4.
Page 35: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Hydraulics actuate too rapidly Hydraulic restrictors not Install hydraulic restrictors installed Wings will not slide into wing Wing rests improperly Reposition wing rests rests positioned Main hinge plate stop bolt Readjust hinge plate stop bolt maladjusted Excessive clogging during Angle of attack too steep...
Page 36 HDL-1124 through HDL-1160 HARROW CART PARTS DIAGRAM APPENDIX B...
Page 37 HDL-1124 through HDL-1160 HARROW CART PARTS LIST Always order by Part Number - Not by Key Number PART # DESCRIPTION 11654 FRAME, MAIN (HDL-1124 – 1138) 11726 FRAME, MAIN (HDL-1140 – 1150) 11337 FRAME, MAIN (HDL-1152 – 1160) 11660 FRAME, TOOLBAR, CENTER, 10’ 11729 FRAME, TOOLBAR, CENTER,12' 11247...
Page 38 WDL-2505 SPINDLE HD-1361 HUB WITH RACES, 6-HOLE HUB HD-1367 DUST CAP, 6-HOLE HUB HD-1360 GREASE SEAL, 6-HOLE HUB HD-1363 OUTER BEARING, 6/8-HOLE HUB HD-1362 INNER BEARING, 6-HOLE HUB HD-1364 SPINDLE FLAT WASHER, 6-HOLE HUB WB-5010 WHEEL BOLT, 1/2 X 1 HD-1365 SPINDLE HEX NUT, 6-HOLE HUB CP-1517...
Page 39 BRACKET, DUAL LIGHT 12641 HDL-1124 WEIGHT (HDL-1124 ONLY) 10116 BRACKET, DUAL LIGHT, LEFT (HDL-1160-44) 10207 BRACKET, DUAL LIGHT, RIGHT (HDL-1160-44) McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 40 FH 8-BAR HARROW SECTIONS PARTS DIAGRAM & LISTING INCLUDES FH-500-8, FH-600-8, FH-700-8, FH-800-8, AND FH-900-8 16 BAR 4+4 SECTION SECTION ONLY ONLY FH-700-8 SHOWN ITEM # PART # DESCRIPTION FH-801 #1 HARROW BAR (FH-500-8) FH-805 #1 HARROW BAR (FH-600-8) FH-809 #1 HARROW BAR (FH-700-8) FH-813 #1 HARROW BAR (FH-800-8)
Page 41 FH-820 #4 HARROW BAR (FH-900-8) FH-803 #5 HARROW BAR (FH-500-8) FH-807 #5 HARROW BAR (FH-600-8) FH-811 #5 HARROW BAR (FH-700-8) FH-815 #5 HARROW BAR (FH-800-8) FH-819 #5 HARROW BAR (FH-900-8) FH-803 #6 HARROW BAR (FH-500-8) FH-807 #6 HARROW BAR (FH-600-8) FH-811 #6 HARROW BAR (FH-700-8) FH-815...
Page 42 FH 6-BAR HARROW SECTIONS PARTS DIAGRAM & LISTING INCLUDES FH-500-6, FH-600-6, FH-700-6, FH-800-6, AND FH-900-6 ITEM # PART # DESCRIPTION FH-830 #1 HARROW BAR (FH-500-6) FH-832 #1 HARROW BAR (FH-600-6) FH-834 #1 HARROW BAR (FH-700-6) FH-836 #1 HARROW BAR (FH-800-6) FH-838 #1 HARROW BAR (FH-900-6) FH-804...
Page 43 FH-834 #5 HARROW BAR (FH-700-6) FH-836 #5 HARROW BAR (FH-800-6) FH-838 #5 HARROW BAR (FH-900-6) FH-804 #6 HARROW BAR (FH-500-6) FH-808 #6 HARROW BAR (FH-600-6) FH-812 #6 HARROW BAR (FH-700-6) FH-816 #6 HARROW BAR (FH-800-6) FH-820 #6 HARROW BAR (FH-900-6) E-611 1/2”...
Page 44 FW-0100 WASHER, FLAT,1 CP-3620 PIN, COTTER,3/16x2 Note: When ordering cylinder replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 45 HYD HOSE,3/8(9/16F-9/16F 90°).168 HYF-4002 HYD DISCONNECT, MALE Note: When ordering cylinder replacement parts, please specify cylinder make & part number. McFarlane Manufacturing reserves the right to change specifications of design at any time without obligation to modify previous products. APPENDIX B...
Page 46: Layout Diagrams
HDL-1124 LAYOUT DIAGRAM APPENDIX C...
Page 47 HDL-1126 LAYOUT DIAGRAM APPENDIX C...
Page 48 HDL-1128 LAYOUT DIAGRAM APPENDIX C...
Page 49 HDL-1130 LAYOUT DIAGRAM APPENDIX C...
Page 50 HDL-1132 LAYOUT DIAGRAM APPENDIX C...
Page 51 HDL-1134 LAYOUT DIAGRAM APPENDIX C...
Page 52 HDL-1136 LAYOUT DIAGRAM APPENDIX C...
Page 53 HDL-1138 LAYOUT DIAGRAM APPENDIX C...
Page 54 HDL-1140 LAYOUT DIAGRAM APPENDIX C...
Page 55 HDL-1142 LAYOUT DIAGRAM APPENDIX C...
Page 56 HDL-1144 LAYOUT DIAGRAM APPENDIX C...
Page 57 HDL-1146 LAYOUT DIAGRAM APPENDIX C...
Page 58 HDL-1148 LAYOUT DIAGRAM APPENDIX C...
Page 59 HDL-1150 LAYOUT DIAGRAM APPENDIX C...
Page 60 HDL-1152 LAYOUT DIAGRAM APPENDIX C...
Page 61 HDL-1154 LAYOUT DIAGRAM APPENDIX C...
Page 62 HDL-1156 LAYOUT DIAGRAM APPENDIX C...
Page 63 HDL-1158 LAYOUT DIAGRAM APPENDIX C...
Page 64 HDL-1160 LAYOUT DIAGRAM APPENDIX C...
Page 65: Warranty Registration Form
WARRANTY REGISTRATION FORM This form must be filled out by the dealer and owner and sent to: McFarlane Mfg. Co., Inc., 1330 Dallas Street, P.O. Box 100, Sauk City, WI 53583. WARRANTY REGISTRATION FORM & INSPECTION REPORT WARRANTY REGISTRATION This form must be filled out by the dealer and signed by both the dealer and customer at the time of delivery.
Page 67 Dealer Contact Information McFARLANE MANUFACTURING CO. INC. 1330 DALLAS STREET, P.O. BOX 100 SAUK CITY, WISCONSIN 53583 PHONE: (608) 643-3322 TOLL FREE: (888) 627-8569 FAX: (608) 643-3976 WEB: www.flexharrow.com...
