Televes MOSAIQ 6 Quick Manual

Multi-touch Meter/Analyser

1.- Battery charge

3.- Registration process

First of all please register yourself on our website (www.televes.com). You will need
your user name and password to register your Mosaiq6.
Follow the steps shown in the screen. Further details in the user manual.
The fi rst time you turn
your Mosaiq6 on, you will
see a message asking you
to register your Mosaiq6
in our web within 30 days.
You must have connection
to the internet.
Select Ethernet or Wi-Fi.
Enter the user name and
password you use on our
website.

6.- Bottom bar

Tap to change channel/freq. tuning
Tap to direct access to TV Analyser feature
Tap to change tuned channel

2.- ON/OFF

OFF (>3 sec.)
Skip
Mosaiq6 is connected
to the internet
Skip
Press
registration process.
You can use your Hexylon
During the next 30 days, each
time you turn your Mosaiq6 on,
the message will appear.
Tap to change selected service

4.- Keyboard

ON
1. Device ON/OFF button: To turn the
2. Menu button: First press: features
3. Up/Down buttons: Changes channel
4. Left/Right buttons: Changes screen in
5. OK button: Selects an option

5.- Gestures

skip to cancel the
Tap to change user profi le
Tap to change band
Quick Guide
1 3 5
equipment off , press and hold for more
than 3 seconds. If the Mosaiq6 is ON,
press ON/OFF button to enable/disable
the touch-screen
menu is shown. Second press: context
menu is shown. Third press: all menus
are hidden
multi screen features
Tap: one fast touch with one fi nger
Select menu/option/check.
Double tap: two fast consecutive
touches with one fi nger
Widget <=> Full screen.
Swipe: short swipe with one fi nger
Shows menus (see section 8.- Menus)
Spectrum => changes channel.
Drag: drag with one fi nger
Main menu wheel => feature search.
TV and Radio Analyser => switches
between screens.
Spectrum/Echoes/Measurements =>
moves markers.
Pinch/Spread: pinch/spread two
fi ngers on the screen
Spectrum => changes span.
Constellation => zoom in/out.
Drag and drop
Spectrum => changes tuned channel,
dropping it to the centre of the
spectrum.
Tap to save LOG
Tap to run MacroLOG
3 3
