  • Page 1 Field Strength Meter Multimetter FSM 500 U s e r M a n u a l Ref. 5903 w w w . t e l e v e s . c o m...

  • Page 3: Table Of Contents

    Multimetter FSM 500 Ref. 5903 Index ..........
  • Page 4 Multimetter FSM 500 Ref. 5903 3.3.2.- Equipment configuration ..........
  • Page 5 Multimetter FSM 500 Ref. 5903 3.3.3.3.- Channel search ...........

  • Page 6: Installation

    Multimetter FSM 500 Ref. 5903 SAFETY MEASURES Before using the equipment, read the user manual and read the section on SAFETY MEASURES. symbol on the equipment indicates: “SEE USER MANUAL”. This manual may also contain the Caution or Warning symbols.

  • Page 7: Power Supply

    Figure 1.- Connection to the mains 1.2.2.- Battery powered The FSM 500 comes with one 12V Ni-MH battery. This battery, using an average consumption, can power the equipment for more than four hours. The equipment features a complicated control system for charging and discharging the batteries which optimises their duration and life, and this in turn means that the equipment can use this form of powering without any abrupt decrease in the length of time.
  • Page 8 Multimetter FSM 500 Ref. 5903 While the equipment is charging the battery, the Battery (11) LED will flash. In any case, the equipment will stop charging once this is complete. The equipment is constantly monitoring the status of the batteries and it informs the user of their status via an LED icon (Battery (11)) and an audio signal.

  • Page 9: Start-Up

    Multimetter FSM 500 Ref. 5903 Note on charging the battery: => Whenever possible, it is advisable to recharge the batteries completely. In other words, when the recharging process begins, do not interrupt it, until the batteries are 100% full. => If you are not going to use the equipment for a while, the battery level should not be very low.

  • Page 10: Product Description

    Ref. 5903 2.- PRODUCT DESCRIPTION The FSM 500 is a portable meter with a 5” coloured screen which features all of the basic functions that are necessary to guarantee a high level of quality in an analogue or digital RTV installation.

  • Page 11: Specifications

    Multimetter FSM 500 Ref. 5903 2.1.- SPECIFICATIONS Next, you can see a list of the main specifications of the FSM 500. Monitor: Screen TFT 5" colour Standard Multistandard: PAL (B, G, D, K, I), SECAM (B, G, D, K, L)
  • Page 12 Multimetter FSM 500 Ref. 5903 External powering connection: Via a DC adapter provided with the FSM. External powering: 12 - 14,8V Maximum consumption: Batteries recharged using provided adapter for car lighter Measurements: Measurement units: dBµV Numerical indication onscreen using the OSD function...
  • Page 13 Multimetter FSM 500 Ref. 5903 Attenuator: Automatic Environmental working conditions: Height: Up to 2000 m Temperature margin: From 0 to 40 º C Maximum relative humidity: 80 % (Up to 31ºC), in a linear decrease until 50% at 40º C.

  • Page 14: Element Description

    Multimetter FSM 500 Ref. 5903 2.2.- ELEMENT DESCRIPTION The front panel features the following elements: Figure 3.- Front panel (1) Monitor TFT 5" colour screen (2) Short cut buttons Each of these buttons correspond to one of the menu functions that can be seen onscreen at that moment.
  • Page 15 Multimetter FSM 500 Ref. 5903 (4) Clear/Menu This makes the menu buttons appear and disappear from onscreen. It is also used to close the windows that appear in the middle of the screen (measurement windows, parameter selection windows, etc). (5) Back...

  • Page 16: 3.- Channel Search

    Multimetter FSM 500 Ref. 5903 (9) Freq Selects the frequency tuning mode. If there is a measurement window open and the equipment was previously in the channel tuning mode, when you press the Freq button, the information regarding the tuned channel disappears and the video carrier frequency of that channel appears in its place.
  • Page 17 Multimetter FSM 500 Ref. 5903 (24) Switching analyser / TV viewing modes (Button 5) This lets you change from the TV mode to the analyser mode and vice versa. (25) Printing measurements (Button 8) This automatically prints the measurement on an RS-232 printer.
  • Page 18 Multimetter FSM 500 Ref. 5903 Side view: 30 31 V.max. 24 V 12 ... 14,8 V I.max. 400 mA SCART RS-232 Figure 5.- The connectors on the side panels (30) RF input Input connector for the signal with an impedance of 75 ohm.

  • Page 19: How To Use The Product

    Multimetter FSM 500 Ref. 5903 3.- HOW TO USE THE PRODUCT 3.1.- THE MENU As explained previously, the different functions of the equipment have been placed in hierarchical order, so that they are very user-friendly. The menu texts appear onscreen, superimposed over the picture, which can be the demodulated picture from the tuned TV channel (TV mode) or the spectrum (analyser mode).
  • Page 20 Multimetter FSM 500 Ref. 5903 Config. Auto Monitor Language Dsconnect Paramtres Scart Info Equipo Informa. Clock Battery Battery Brigh. Color Volume Contrast Update Change Regenerat. Mode Sel. Audio Channel Measure View Mode Carrier Search (types) Measure Search Sel. Audio Sync.

  • Page 21: Tuning Modes

    Ref. 5903 3.2.- TUNING MODES The FSM 500 has 2 tuning modes: by channel or by frequency. To select one or the other, use the Chan. (channel tuning) and Freq. (frequency tuning). If using the channel tuning option, the measurements taken will be done on the video carrier of that channel.

  • Page 22: Measurement Configuration

    Multimetter FSM 500 Ref. 5903 3.3.1.- Measurement configuration By using the functions in this menu you can set the parameters that affect the measurements that you are going to take. All of the windows that are opened with the different functions of the “Measurement Configuration”...

  • Page 23: 2.1.- Lnb

    Multimetter FSM 500 Ref. 5903 Current status of the equipment Options. These are selected by using the rotating knob and Indicates the power that is are activated when this being supplied knob is pressed Indicates if the 22KHz tone is activated...
  • Page 24 Multimetter FSM 500 Ref. 5903 Current status of the equipment Options. Indicates the power that is being These are selected by supplied to the preamplifiers using the rotating knob and are activated when Indicates if the 22KHz tone is this knob is pressed...

  • Page 25: 2.2.- Diseqc

    Multimetter FSM 500 Ref. 5903 3.3.1.2.2. DiSEqC (satellite band only): The Diseqc protocol lets you work with multiswitches that have up to 16 inputs. To do so, when the meter is in the satellite band, you must enable, in the powering menu, the current and tone that corresponds to the desired polarity and satellite band.

  • Page 26: 3.- Channels And Standards

    Multimetter FSM 500 Ref. 5903 3.3.1.3.- Channels and Standards 3.3.1.3.1.- Standard This allows you to select the colour standard. The standards that are available are as follows: PAL B/G, PAL D/K, PAL I, SECAM B/G, SECAM L and SECAM D/K.

  • Page 27: 3.3.- Video Invertion

    Multimetter FSM 500 Ref. 5903 3.3.1.3.3.- Video invertion This function lets you select if the video signal that comes from a satellite band is inverted (ON) or not (OFF). By default, this option is OFF. It is useful when watching the video of satellites from the C band.

  • Page 28: 4.- Memory Logger

    3.3.1.4.1.- Memories. Short cut button The FSM 500 lets you save up to 100 different configurations (memories) for your equipment, which you will be able to retrieve very simply. The measurer is able to store any state in which is as mode, norm, measurement type, etc.

  • Page 29: 4.1.1- Save

    Multimetter FSM 500 Ref. 5903 To configure the equipment according to the stored parameters in a specific menu, simply press button (or go to the CONF. MEASURE => MEMORIES LOGGER => MEMORIES menu), select the desired memory from the list and press If there isn't any memory in the meter, the message "NO MEMORIES"...

  • Page 30: 4.1.2.- Delete

    Multimetter FSM 500 Ref. 5903 First free memory. Flashing digits with the On the lower part of lower disposable the window, the number. instructions that the user must follow to Press to save. save the memory appear. Figura 18.- Saving a memory When the user confirms that s/he wants to save the memory, the message "MEMORY SAVED"...
  • Page 31 Multimetter FSM 500 Ref. 5903 When the user confirms that s/he wants to erase a memory, the message "MEMORY ERASED" will appear onscreen. 3.3.1.4.1.3.- How to Edit a Name This function enables the user to modify the name of any memory, whether it has been saved or whether it is a new memory that the user wishes to save.

  • Page 32: 4.2.- Macromeasurements

    Multimetter FSM 500 Ref. 5903 3.3.1.4.2.- Macromeasurements A MACROMEASUREMENT is a group of a specific number of memories (different measurements), that the meter will be able to execute automatically and add the results to a specific measurement LOG. You can configure up to 100 different MACRO MEASUREMENTS! (automatic measurements with different memories).
  • Page 33 Multimetter FSM 500 Ref. 5903 When the is pressed, the MACRO OPTIONS menu is displayed. Figure 21.- Macro options Use the rotating knob to choose the different options of this menu: - Run Macro. Starts the execution of the selected Macromeasurement. If the selected macromeasurement does not contain any memory, the meter will display the following message "MACRO EMPTY".
  • Page 34 Multimetter FSM 500 Ref. 5903 Figure 23.- Change to satellite connector The other possibility that can be chosen using the button is the Broadband outlet where the equipment carries out the Macromeasurement in both bands with no interruptions. If you press...
  • Page 35 Multimetter FSM 500 Ref. 5903 To execute the Macromeasurement again in a new outlet, press again. If you want to finish the Macromeasurement, press any button. Figure 25.- Continue or cancel Macromeasurement - LOG options. This option lets us select the possibility of continuing with a LOG which we had previously created or of starting with a new one, in this case the equipment will suggest a name for the new "LOG"...
  • Page 36 Multimetter FSM 500 Ref. 5903 Figure 27.- Editing the LOG name Note: If we are executing a Macromeasurement, the function "Automatic shut-down" will be postponed until the end of this process.

  • Page 37: 4.2.1.- New Macro

    Multimetter FSM 500 Ref. 5903 3.3.1.4.2.1.- New Macro This option lets us create new Macromeasurements using the memories inside the meter. A window opens and the name of a Macromeasurement appears with the cursor flashing. The name that the equipment proposes to identify each Macromeasurement is: “MAC” and a two- digit number which will be the lowest number available at that time.

  • Page 38: 4.2.2.- Edit Macro

    Multimetter FSM 500 Ref. 5903 At the bottom of the window, we will be able to see some important information about each memory that has been selected and the number of memories that we are putting into the Macromeasurement. When we have finished the selection process, we must press CONFIRM and then .

  • Page 39: 4.3.1.- Erase Logs

    Multimetter FSM 500 Ref. 5903 If there aren't any DATALOGS stored in the meter's memory, the message "NO DATALOGS" will appear onscreen. By pressing a table with two columns will appear. On the left there are the outlets that have been measured and on the right there are the results of each outlet.

  • Page 40: 4.3.2.- Edit Logs

    Multimetter FSM 500 Ref. 5903 3.3.1.4.3.2.- Edit LOGS This option lets us change the name of the desired LOG at any time. To do so, use the rotating knob to select the LOG, confirm your selection by pressing the key. The name of this LOG will flash on and off and using the rotating knob and button, we can change the characters.

  • Page 41: 4.4.1.- Save Graphs

    Multimetter FSM 500 Ref. 5903 Figura 33.- List of graphs of a GLOG While we are reviewing the graphs, a flashing message will appear onscreen which displays the name of the GLOG and the graph. Using the rotating knob, we can scroll through the graphs in the GLOG.

  • Page 42: 4.4.1.1.- Glog Options

    Multimetter FSM 500 Ref. 5903 Figura 35.- Save a graph We can put the graphs together into groups called GLOGS. The name of the first group of graphs suggested by the meter will be GLOG00. In Analyser mode, we can easily save a graph using the short cut button 3.3.1.4.4.1.1.- GLOG options...

  • Page 43: 4.4.2.- Edit Name

    Multimetter FSM 500 Ref. 5903 3.3.1.4.4.2.- Edit Name This lets you change the name of the selected GLOG. 3.3.1.4.4.2.- Edit Graph Name This option displays a list of the current GLOG's graphs. To change the name, select the graph and then press Figura 37.- Editing the name of a graph...

  • Page 44: Equipment Configuration

    Figure 38.- Equipment configuration options 3.3.2.1.- Language The FSM 500 allows you to select the menu language. The languages that are available are: Spanish, English, Portuguese, French, German and Italian. The window that appears when this menu is selected looks as follows:...

  • Page 45: Automatic Shut-Down

    Multimetter FSM 500 Ref. 5903 3.3.2.2.- Automatic shut-down The equipment has the option of automatically turning off once a certain programmable time of inactivity has elapsed. This period of inactivity that can be selected ranges from 1 to 59 minutes. The user can also disable this function (OFF). The equipment has a default value for this period of inactivity of 15 minutes.

  • Page 46: Volume

    Multimetter FSM 500 Ref. 5903 3.3.2.3.1.- Volume (short cut button Use the rotating knob to increase or decrease the volume. The volume screen appears as follows: Figure 42.- Selection of volume 3.3.2.3.2.- Brightness (short cut button This increases or decreases the brightness of the picture onscreen. It operates in the same way as the volume control.

  • Page 47: Scart

    Multimetter FSM 500 Ref. 5903 3.3.2.5.- Scart A window opens that allows you to select the control of the signals of the SCART: Figure 44.- Scart options Scart auto: Normal operating mode of the scart, in other words, when there is a signal in the scart, it is automatically seen onscreen.

  • Page 48: Information About The Equipment

    Multimetter FSM 500 Ref. 5903 - If the meter has a digital measurement window open (Power or C/N) it will be impossible to see the scart signal, although this may be in auto mode. Therefore, if you wish to see the scart signal, make sure that the meter is not carrying out a digital measurement.

  • Page 49: Changing The Battery

    Ref. 5903 3.3.2.6.2.- Changing the battery The FSM 500 offers two possibilities when changing the battery: A) A possibility is to change the battery for another with a different capacity. The equipment comes with a Ni-MH 6 AH battery which will provide the equipment with more than 4 hours of battery life.

  • Page 50: Battery Regeneration

    Multimetter FSM 500 Ref. 5903 Standard battery Ni-MH 3,5 AH Long life battery Ni-MH 6 AH Figure 47.- Configuration of the switches according to the type of battery 4.- Switch the equipment off 5.- Disconnect the equipment from the mains B) Another possibility is to substitute the battery for another with the same characteristics.
  • Page 51 Multimetter FSM 500 Ref. 5903 other key is pressed, the meter returns to its previous state. Figura 48.- Battery regeneration When the charging process begins, the meter will switch off while the battery light and the ON light will flash on and off.

  • Page 52: Tv Mode

    Multimetter FSM 500 Ref. 5903 3.3.3.- TV mode (short cut button When this menu is selected, the equipment switches automatically to TV mode, in other words, the user will see the demodulated television signal of the tuned channel onscreen. The corresponding submenu is the following: 3.3.3.1.- Viewing mode...

  • Page 53: Synchronism

    Multimetter FSM 500 Ref. 5903 Figura 51.- Indication via bars 3.3.3.1.2.- Synchronism This option displays the representation of the synchronism burst on the left-hand side of the screen. If a digital measurement is being carried out (power, C/N, BER, MPEG), it will not be possible to see the synchronism burst, as the meter supposes that the tuned channel is digital and therefore does not represent this burst.

  • Page 54: Measurement Windows

    Multimetter FSM 500 Ref. 5903 3.3.3.1.3.- Measurements window (short cut button When this option is selected, the window that corresponds to the last measurement that was carried out, opens. In other words, if the last measurement that was carried out was the C/N (for example), the C/N window will open and the C/N measurement will be carried out in the tuned channel.

  • Page 55: Teletext

    Multimetter FSM 500 Ref. 5903 3.3.3.1.4.- Teletext When this function is selected, the teletext information of the tuned channel will appear onscreen (if the channel does not dispose of this information, NO TTX will appear). The representation level of the teletext function is 1.5 Figure 54.- Teletext window...

  • Page 56: Analogue

    Multimetter FSM 500 Ref. 5903 3.3.3.2.1 3.3.3.2.2 Figure 55.- Measurement menu 3.3.3.2.1.- Analogue measurements (short cut button The corresponding submenu is as follows: 3.3.3.2.1.1 3.3.3.2.1.2 3.3.3.2.1.3 3.3.3.2.1.4 Figure 56.- Analogue measurements 3.3.3.2.1.1.- Level If the channel tuning mode has been selected, this function will measure the carrier level of the tuned channel.
  • Page 57 Multimetter FSM 500 Ref. 5903 Frequency tuning mode: information on the tuned frequency Signal level Figure 57.- Abbreviated form You can vary the frequency by using the rotating knob (in the terrestrial band with a resolution of 50 KHz and in the satellite band 100 KHz), or by using the number pad.

  • Page 58: Automatic C/N

    Multimetter FSM 500 Ref. 5903 V/A measurement Tuned frequency Audio carrier Signal level in the tuned Audio carrier level frequency Figure 60.- V/A measurement. Frequency tuning The tuned frequency is taken as the video carrier, in other words, it is where the video level is measured.
  • Page 59 Multimetter FSM 500 Ref. 5903 Selected channel plan C/N measurement Tuned channel Channel bandwidth Figure 62.- Automatic C/N measurement. Channel tuning C/N measurement Tuned frequency Channel bandwidth Figure 63.- Automatic C/N measurement. Frequency tuning If in channel tuning mode, you will be able to see the channel with the carrier that is being used to carry out the level measurement.

  • Page 60: Channel Bw

    Multimetter FSM 500 Ref. 5903 3.3.3.2.1.3.1.- Channel BW When this option is pressed, a small window opens on top of the previous window, displaying the value of the video bandwidth which will be taken into account when automatically compensating the noise (we recommend 5 MHz for this measurement). As the user turns the rotating knob, the different options will appear.

  • Page 61: Reference Frequency

    Multimetter FSM 500 Ref. 5903 which you want to measure the noise level (reference frequency) and the channel bandwidth. To do so, this function has the following submenu: 3.3.3.2.1.4.1.- Reference frequency By pressing this option, the noise frequency is highlighted in the window (dark background).

  • Page 62: Digital

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.- Digital measurements (short cut button When a digital measurement is selected, the image from the TV signal will disappear from the screen, and a warning message will appear that indicates that this is a digital measurement.

  • Page 63: Channel Bw

    Multimetter FSM 500 Ref. 5903 To change this parameter, the following submenu appears: 3.3.3.2.2.1.1.- Channel bandwidth If this option is pressed, the value of the bandwidth is selected in the channel power window. You can change this value by using the rotating knob: Channel BW Tuned frequency.
  • Page 64 Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.1 3.3.3.2.2.4.3 3.3.3.2.2.4.2 Terrestrial band Satellite band Figure 72.- Options for the BER measurements The window that opens when any of the modulations is selected is the same, however the type of modulation varies: BER before Viterbi...

  • Page 65: Cofdm

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.1.- COFDM (only terrestrial band) Carry out the BER measurement of the digital terrestria signals with COFDM modulation. The submenu for this type of modulation is the following: 3.3.3.2.2.4.1.1 3.3.3.2.2.4.1.2 3.3.3.2.2.4.1.3 3.3.3.2.2.4.1.4 Figure 74.- COFDM measurements 3.3.3.2.2.4.1.1.- Parameters...
  • Page 66 Multimetter FSM 500 Ref. 5903 When the rotating knob is pressed, the window that corresponds to the selected parameter opens: Possible options that can be selected with the Spectrum Inversion parameter using the rotating knob Figure 76.- COFDM parameter options In the Offset option, if the COFDM channel has a frequency deviation, you can apply an offset (0, 1/6, 2/6, 3/6, -1/6, -2/6, -3/6, Auto) to correct this deviation.

  • Page 67: Error Packets

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.1.2.- Error packets When this function is selected, a window opens which displays the following information: the maximum number of error packets in a 10 minuted interval, the time that has elapsed since the last error and the time that the equipment has been locked onto the signal for (without a visible error on the screen).
  • Page 68 Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.1.1 3.3.3.2.2.4.1.2 3.3.3.2.2.4.1.3 3.3.3.2.2.4.1.4 Figura 79.- MPEG decoding of a COFDM channel In this option there is an extended window (short cut ) which displays some information about the tuned channel: the number of services, the selected service (if it is a scrambled channel, # will appear beside the name), the SID network identifier, VPID (for the audio channels the value 0 will appear) and the APID.

  • Page 69: Parameters

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.2.- QAM (only terrestrial band) When this function is selected, the equipment measures the BER of a digital signal with QAM modulation. The information window is identical to the previous one. The submenu for this function is the following: 3.3.3.2.2.4.2.1...

  • Page 70: Mpeg

    Multimetter FSM 500 Ref. 5903 BER parameters Constellation parameters Figura 82.- Parameter options 3.3.3.2.2.4.2.2.- BER When this function is selected, the parameters window closes and the BER measurement window appears again. 3.3.3.2.2.4.2.3.- MPEG By enabling this option, the user enters the MPEG decoding mode in a QAM channel. The operation mode is similar to MPEG of COFDM (see 3.3.3.2.2.4.1.4).

  • Page 71: Constellation

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.2.4.- Constellation (OPTION 1) This function can represent the QAM constellation. The screen can also display additional information in order to assess the signal quality (CBER and MER). By accessing "PARAMETERS" we can amplify any of the quadrants.

  • Page 72: Qpsk

    Multimetter FSM 500 Ref. 5903 3.3.3.2.2.4.3.- QPSK (only the satellite band) This function measures the BER of a digital signal with QPSK modulation. The information window is exactly the same as the window for the QAM and COFDM modulations. The submenu is the following: 3.3.3.2.2.4.3.1...
  • Page 73 Ref. 5903 3.3.3.3.- Channel search (short cut button The FSM 500 features an automatic channel search function. The search is carried out according to a certain threshold as defined by the user in the Search Level. It also depends on whether the meter is in channel tuning mode or frequency tuning mode.

  • Page 74: 3.1.- Search Level

    Multimetter FSM 500 Ref. 5903 3.3.3.3.1.- Search level This parameter defines the threshold that the video carrier must surpass for the equipment to tune a specific channel when carrying out an automatic search. When this function is selected, a window opens onscreen, and the value of the search level can be modified using the rotating knob.

  • Page 75: 4.- Nicam

    Multimetter FSM 500 Ref. 5903 3.3.3.4.- Nicam (OPTION 1) This function activates the NICAM mode. This mode presents the BER NICAM measurement, and it also disposes of the audio selection. To select the audio, we must choose the desired channel using the rotating knob and press (OFF, Nicam A, Nicam B).

  • Page 76: 6.- Fm Radio

    Multimetter FSM 500 Ref. 5903 Figure 89.- Audio carrier To close the window use the Clear button. 3.3.3.6.- FM radio This function lets you tune the radio in modulated frequency. When this function is selected, a window opens onscreen where you can see the frequency and the signal level of this frequency.

  • Page 77: Spectrum

    Multimetter FSM 500 Ref. 5903 3.3.4.- Spectrum (short cut button If this menu is chosen, the meter passes straight to the spectrum analyzer mode. In this mode you can see the signal spectrum according to the selected span and the tuned frequency. The lower part of the screen (under the spectrum) is used to display the parameters, measurements, etc.

  • Page 78: 1.- Reference Level

    Multimetter FSM 500 Ref. 5903 The information about the tuned frequency or channel appears at the bottom of the screen. If the equipment is in frequency mode, the central frequency of the spectrum will appear. If we turn the rotating knob, we can change the central frequency, in other words, we move the spectrum to one side or the other.

  • Page 79: 2.- Span

    When the rotating knob is pressed, the value is selected and the menus disappear from the screen. The possible values in the FSM 500 meter are: Terrestrial band: 8, 16, 32, 48, 96, 192, 496 MHz, Full Span...

  • Page 80: 3.- Measurements

    Multimetter FSM 500 Ref. 5903 3.3.4.3.- Measurements The measurements are displayed at the bottom of the screen. While any measurement is being viewed, the tuned frequency can be varied by turning the rotating knob. This means that the measurement can be carried out with different frequencies or channels.

  • Page 81: 3.1.3.- Automatic C/N

    Multimetter FSM 500 Ref. 5903 Figure 96.- A/V carrier ratio 3.3.4.3.1.3.- Automatic C/N The C/N measurement is also displayed on the lower part of the screen. As is the case with the V/A measurement, the carrier level is measured in the spectrum’s central frequency The equipment selects the frequency that is used to measure the noise.

  • Page 82: 3.1.4.1.- Reference Frequency

    Multimetter FSM 500 Ref. 5903 parameters are displayed on the lower left-hand part of the screen; the level measurement disappears for a moment, and once the desired value has been selected (by pressing the rotating knob), the level measurement re-appears:...

  • Page 83: 3.2.- Digital

    Multimetter FSM 500 Ref. 5903 3.3.4.3.2.- Digital 3.3.4.3.2.1.- Channel power The channel power is displayed on the lower left-hand part of the screen. For this measurement, the meter takes the spectrum’s central frequency (the tuned frequency) to be the central frequency of the digital channel.

  • Page 84: 3.2.2.- C/N Automática

    Multimetter FSM 500 Ref. 5903 3.3.4.3.2.2.- Automatic C/N The automatic C/N measurement for digital channels is the same as for analogue channels. This function has the following submenu: 3.3.4.3.2.2.1.- Channel bandwidth When this parameter is selected, the information about the channel power measurement disappears and the channel bandwidth appears in its place.

  • Page 85: 4.- Markers

    Ref. 5903 3.3.4.4. Markers The FSM 500 has the possibility of using two markers on the screen. Using the functions of this submenu, you can move them through the whole spectrum to carry out the level measurements in the two marked frequencies.

  • Page 86: 5.- Rbw

    Figure 104.- First marker enabled 3.3.4.5.- RBW The FSM 500 uses the four I.F. filters automatically, depending on the selected SPAN. Using this function you can modify the bandwidth of the resolution filter. The possible values are: 100 KHz, 250...

  • Page 87: 6.- Hold (On/Off)

    Multimetter FSM 500 Ref. 5903 3.3.4.6.- Hold (On/Off) This function represents pulse signals or signals that change quickly. When you select it, a yellow graph will appear which indicates the maximum signal levels at each point. When you select it again, this graph disappears.

  • Page 88: Error Warnings

    Multimetter FSM 500 Ref. 5903 3.4.- ERROR WARNINGS When the equipment detects an error in any of the modules or components, it warns the user through a series of messages as can be seen below: · NO BAT. : This message appears when the equipment is switched on and no batteries are detected.
  • Page 89 Multimetter FSM 500 Ref. 5903 · NO POWERING: This message appears when the user tries to charge the batteries and there is no external powering. · SHORT CIRCUIT: This message appears when the equipment detects a shortcircuit in the “F” connector. The equipment will also emit a noise.

  • Page 90: Description Of The Inputs And Outputs

    130 dBµV. This connector is easily replaced when this becomes necessary. 4.2.- RS-232C SERIAL PORT The FSM 500 features an RS-232C serial port for exchanging data with a PC or any other device. The signals in this connector are described below: Figure 106.- RS 232 connector...

  • Page 91: Scart Connector

    Multimetter FSM 500 Ref. 5903 4.3.- SCART (DIN EN 50049) Figure 107.- SCART Also known as a PERITEL connector (in compliance with standard NF-C92250). The signals in this connector are as follows: PIN Nº SIGNAL SPECS. PIN Nº SIGNAL SPECS.

  • Page 92: Maintenance

    Multimetter FSM 500 Ref. 5903 5.- MAINTENANCE 5.1.- REPLACING THE BATTERY The battery should be replaced when its capacity (fully-charged) has diminished considerably. To ensure that the equipment operates correctly, it should be provided by Televés, as it should incorporate the appropriate protective features.
  • Page 93 Multimetter FSM 500 Ref. 5903 WARNING Avoid any type of shortcircuit between the cables to the battery as this could cause serious damage to the equipment. Note: Remember to dispose of the batteries in the appropriate places provided Ni-MH...

  • Page 94: Cleaning Instructions

    Multimetter FSM 500 Ref. 5903 5.2.- CLEANING INSTRUCTIONS WARNING Before cleaning the cover, make sure that the equipment is disconnected. Do not use scented hydrocarbons or chlorinated solvents. These products may harm the materials used for the cover. The cover can be cleaned with a bit of normal cleaning liquid and water, using a soft damp cloth.

  • Page 95: Appendix 1.- Batteries

    Multimetter FSM 500 Ref. 5903 APPENDIX 1.- Batteríes Below is a list of the safety measures that must be taken into account as regards the batteries: This equipment contains a Ni-MH battery packet. · The charging of the batteries should always be carried out with the batteries located inside the meter and using the DC adapter that is provided with the equipment.

  • Page 96: Appendix 2.- Channel Plans

    Multimetter FSM 500 Ref. 5903 APPENDIX 2.- Channels Plan CCIR 48,25 E05 175,25 S16 266,25 S29 367,25 471,25 575,25 679,25 783,25 55,25 E06 182,25 S17 273,25 S30 375,25 479,25 583,25 687,25 791,25 62,25 E07 189,25 S18 280,25 S31 383,25 487,25...
  • Page 97 Multimetter FSM 500 Ref. 5903 The frequencies in this channel plan require the use of a universal LNB ASTRA 19 ASTRA HL ASTRA HH ASTRA VL ASTRA VH 1464 1120 1744 1479 1139 1763 1494 1158 1782 1008 1509 1178...
  • Page 98 Multimetter FSM 500 Ref. 5903 ASTRA 28º 1097 1120 1256 1392 1529 1666 1802 1112 1139 1276 1412 1548 1685 1822 1023 1126 1158 1295 1432 1568 1704 1841 1038 1141 1178 1314 1451 1588 1724 1860 1053 1156 1198...
  • Page 99 Multimetter FSM 500 Ref. 5903 AMAZONAS 1498 1376 1306 1184 1119 1010 1225 1489 1367 1254 1180 1062 1492 1428 1315 1245 1123 1058 1532 SIRIUS 5º 1121 1223 1358 1473 1703 1865 2034 2091 1139 1243 1377 1492 1722...
  • Page 100 Multimetter FSM 500 Ref. 5903 GUARANTEE Televés S.A. offers a one year guarantee, beginning from the date of purchase for countries in the EEC. For the batteries and due to the characteristics of this article, the guarantee period is limited to six months.
  • Page 101 Multimetter FSM 500 Ref. 5903...
  • Page 102 S.op.Viale Liguria 24 20068 Peschiera Borromeo (MI) Italia Tel.: (+39)-0251650604 (RA) Fax: (+39)-0255307363 televes.it@televes.com TELEVES MIDDLE EAST FZE P.O. Box 17199 JEBEL ALI FREE ZONE DUBAI, UNITED ARAB EMIRATES Tel.: 9714 88 343 44 Fax: 9714 88 346 44 televes.me@televes.com Rúa B.
  • Page 104 Field Strength Meter Multimetter FSM 500 U s e r M a n u a l Ref. 5903 w w w . t e l e v e s . c o m...
