- Page 1 Advisor Tech Vital Signs Monitor ® Quick Reference Guide Contact your Midwest Veterinary Supply Representative for more information! To place your order: 1-800-643-9378 | www.midwestvetsupply.com...
- Page 2 Advisor Tech Vital Signs Monitor ® Front Panel Alarm indicator Power switch/stand-by DC On AC On NIBP start/stop Alarm silence Setup Freeze Trend Record Rotary knob Left Side Panel AG/ETCO sensor connector (option) Oxygen saturation sensor connector (SpO Channel 1 IBP port (option) Channel 2 IBP port (option) NIBP connector Channel 1 temperature probe...
- Page 3 Advisor Tech Vital Signs Monitor ® Right Side Panel l Printer (option) Rear Panel Equipotentiality ground AC input External VGA display connector Ethernet interface RS-232 I/O digital interface connector Contact your Midwest Veterinary Supply Representative for more information! To place your order: 1-800-643-9378 | www.midwestvetsupply.com...
- Page 4 Advisor Tech Vital Signs Monitor ® OUT OF BOX SET UP Inserting the Battery into the Monitor Inserting the Battery Open the battery cover on the left side panel into the Monitor Insert battery (provided) and ensure it is aligned correctly Use lever to hold battery in place Close battery cover Plugging into a Main Power Source...
- Page 5 Advisor Tech Vital Signs Monitor ® Setting Up Initial Monitor Parameters Press the hard or soft key Setup button on the front panel (you can also use the rotary knob for navigation by rotating and pressing to select) The following settings can be found in the Setup area and can be set to your preferences by touching each option on the screen Factory Setup: Used for service purposes only Optional Module: Used to upgrade or add additional parameters (for example...
- Page 6 Advisor Tech Vital Signs Monitor ® PATIENT SPECIFIC PARAMETER SET UP Starting a New Case It is important to start a new case Touch Patient ID in the top left area of the display screen directly and enter new for every patient to ensure that information (outlined in the next section) unique readings, memories and Or, touch the Pause soft-key and then choose Start New Case...
- Page 7 Advisor Tech Vital Signs Monitor ® Alarm Switch: Adjustable (default = on) Alarm: Select to change high and low values Sweep Speed: Adjustable (default = 12.5 mm/s) Sweep Color: Adjustable (default = blue) ETCO Alarm Switch: Adjustable (default = on) ETCO Alarm: Select to change high and low values What does the Apnea Delay...
- Page 8 Advisor Tech Vital Signs Monitor ® Deleting a Patient The monitor can save eight sets of patient information for recall. The previous patient can be deleted in order to add a new patient. Open the Recall menu Enter Delete History Record area and choose a patient to delete Click Yes to delete the selected patient record Trend Viewing Press the Trend hard or soft key...
- Page 9 Advisor Tech Vital Signs Monitor ® Hemodynamic Calculation What is Hemodynamic Calculation? Select System Setup, then go to the Hemodynamic Cal menu Measures how blood is flowing Confirm input of the correct values through the patients’ body by Select the Calculation button monitoring heart pressure and the •...
-
Page 10: Troubleshooting
Advisor Advisor Tech Vital Signs Monitor Tech Vital Signs Monitor ® ® TROUBLESHOOTING Why isn’t blood pressure reading correctly? Is this a new patient? If yes, check the Auto Inflation Memory Mode in NIBP Settings, and ensure a new patient record has been set up so that the inflation pressure can reset itself and take a new unique measurement. - Page 11 Advisor Tech Vital Signs Monitor ® Clinical support The veterinary clinical support team is dedicated to assisting customers with expert information pertaining to the technical and clinical aspects of the Advisor tech vital ® signs monitor and our complete line of products. Each clinical support representative is a Certified Veterinary Technician with extensive experience and product knowledge.
- Page 12 Smiths Medical is part of the global technology business Smiths Group plc. Please see the Instructions for Use/Operator’s Manual for a complete listing of the indications, contraindications, warnings and precautions. Surgivet and the Smiths Medical design mark are trademarks of Smiths Medical. The symbol ® indicates the trademark is registered in the U.S. Patent and Trademark Office and certain other countries.
