THORLABS PM100D Quick Reference page 7

Button Appearance: Focus on Button
All sub menus can be left by navigating to the
soft button location or to any empty
System Settings
The following sub menus will appear:
- Measurement Settings
Remote state
Line filter
Default sensor
- Console Settings
Language
Backlight
Brightness
LCD Contrast
Sound
Shutdown
Firmware Upload
- Date and Time
- Console Info
- Sensor Info
Text Negative
... e ...
PM100D can be switched back to local mode
Sets the unit to the local line frequency 50Hz/60Hz
to avoid aliasing effects
Sets the PM100D in a mode to measure photo
current, thermal voltage or peak voltage from a pyro-
electric detector. See user manual.
User interface language setting
Switches the LCD and key backlight on and off
(Same function as the
Sets the brightness of the LCD and key backlight.
The setting range is 0 – 100% in 1% increments
Adjusts the LCD contrast.
The setting range is 0 – 100% in 1% increments
Switches on and off the key and warning sounds
The unit automatically powers off in battery
operation after a certain time without user action.
This feature can be set to 10 minutes, 1 hour or
switched off; and is not active when an external power
supply (AC adapter or USB) is connected.
Needs to be 'enabled' before uploading a new
firmware version. The function will automatically reset
to 'disabled' when powering down.
Enters a submenu to set date and time. It is
possible to chose various date and time formats.
Shows the console related information.
Shows the related information of the currently
connected power or energy sensor.
Edit Mode Blinking
.
EXIT button at the downright
button, and pressing the OK key.
key)
frame.
