I
NTRODUCTION
Your LG-40 is very unique! You may notice that the beams coming out of the projector are larger than
the 4.95mW projectors. There is a very distinct reason for this. Unlike 4.95mW projectors, the output
of the CHAUVET laser projectors with Fatbeam™ technology outputs <20mW for each beam.
Normally outputs greater than 4.95mW require a variance from the FDA. This product has been
designed to meet a special classification of ClassIIIA. Under this classification with the Fatbeam™
technology the acceptable energy levels (AEL) have been met. Therefore the maximum potential
exposure to the unaided eye is less than 4.95mW for a static beam. Additionally the Maximum
Permissible Exposure (MPE) with this product is below acceptable levels for human ocular or tissue
exposure.

Features

CONTROL FEATURES
•
2-channel DMX-512 controlled green laser
•
Operating modes: auto, sound active, master/slave
•
Scan and speed adjustment
•
Laser on/off
ADDITIONAL FEATURES
•
10mW Fat Beam™ laser produces 10-14mm beams that comply with IEC safety standards under
ClassIIIA
•
No variance required
•
Multiple array configurations with optional mounting brackets (LAB-40V, LAB-40CT)
•
Additional power output for daisy chaining units
•
Built-in automated programs via master/slave or DMX
•
Built-in sound activated programs via master/slave or DMX
•
Sound sensitivity control
•
Micro-stepping motors
•
Rugged construction
•
Fan cooled

DMX Channel Summary

C
HANNEL
1
2
LG-40 User Manual
F
UNCTION
Rotation
Speed
5
