Champion EUCC4 Specifications

STANdARd FEATURES
• Exclusive Dual Rinse Technology
• All-purpose 24"-wide peg belt
• Dish capacities up to 16,495 dishes per hour (NSF Listed)
• Automatic tank fill
• Chemical dispensing equipment
connection provisions
• Choice of tank heat: electric, steam
coils or direct steam injectors
• Common hot water connection
• Common drain connection
• Common electric connection
(separate connection required for
optional electric booster and blower-dryer)
• One piece stainless steel wash/rinse
manifold system, easy to remove
• Door safety switch
• Electric eye energy sentinel (idle pump shut-off)
• Easy-to-reach top-mounted controls
• Heavy-gauge stainless construction
• Low-water tank heat protection
• Push-button start-stop station – load end
• Recirculating flushing nozzles – load end with prewash
• Rinse saver device
• Conveyor shut-off shelf – unload end
• Stainless steel enclosure panels – front & ends
The DualRinse feature offers the
Lowest Water/Utility/Chemical Consumption
as low as 113 GPH usage while circulating
410+
as much as
Consistently Good Results
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: 905-562-4195 Fax: 905/562-4618
(3M) 6/07 Printed in U.S.A.
gallons of water for
Project
Item No.
Quantity
EUCC SERIES
A compact footprint that also reduces energy
consumption by more than 58%
SPECIFIER STATEMENT
Specified unit will be Champion model EUCC4,
EUCC6 or EUCC8 upright 24" conveyor water
saver dishwashing machine.
Features automatic tank fill, chemical dispensing
connection provisions, common water, drain and
electrical connections, door safety switch, low
water tank heat protection, rinse saver.
1 year parts and labor warranty.
Upright 24" Conveyor
Dual Rinse Dishwashing Machine
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: 336/661-1556 Fax: 336/661-1979
www.championindustries.com
