2.2

Hardware Features

2.2.1 MSP430F5529
The MSP430F552x is one of several USB-equipped MSP430 derivative families. It offers:
• 1.8-V to 3.6-V operation
• Up to 25-MHz system clock
• 128KB flash memory, 8KB RAM (in addition to 2KB shared RAM with the USB module)
• Ultralow-power operation
• Full-speed USB with 14 endpoints – enough for almost any USB application
• Five timers, up to four serial interfaces (SPI, UART, or I
comparator, hardware multiplier, DMA, and more
Figure 9 shows the pinout of the MSP430F5529 in the PN package (LQFP).
P6.4/CB4/A4 1
P6.5/CB5/A5 2
P6.6/CB6/A6 3
4
P6.7/CB7/A7
P7.0/CB8/A12
5
P7.1/CB9/A13
6
P7.2/CB10/A14
7
P7.3/CB11/A15
8
P5.0/A8/VREF+/VeREF+
9
P5.1/A9/VREF−/VeREF−
10
AVCC1
11
P5.4/XIN
12
P5.5/XOUT
13
AVSS1
14
P8.0 15
P8.1
16
P8.2
17
DVCC1
18
DVSS1
19
VCORE
20
SLAU533B – September 2013 – Revised June 2014
Submit Documentation Feedback
Figure 9. MSP430F5529 Pinout
MSP-EXP430F5529LP LaunchPad™ Development Kit User's Guide
Copyright © 2013–2014, Texas Instruments Incorporated
2
C), 12-bit analog-to-digital converter, analog
60
59
58
57
P5.7/TB0.1
56
P5.6/TB0.0
55
P4.7/PM_NONE
54
P4.6/PM_NONE
53
P4.5/PM_UCA1RXD/PM_UCA1SOMI
52
P4.4/PM_UCA1TXD/PM_UCA1SIMO
51
DVCC2
50
DVSS2
49
P4.3/PM_UCB1CLK/PM_UCA1STE
48
P4.2/PM_UCB1SOMI/PM_UCB1SCL
47
P4.1/PM_UCB1SIMO/PM_UCB1SDA
46
P4.0/PM_UCB1STE/PM_UCA1CLK
45
P3.7/TB0OUTH/SVMOUT
44
P3.6/TB0.6
43
P3.5/TB0.5
42
P3.4/UCA0RXD/UCA0SOMI
41
