Hardware
2.1
Block Diagram
Figure 8
shows a functional block diagram of the board.
6MHz
12
MSP-EXP430F5529LP LaunchPad™ Development Kit User's Guide
USB Connector
5V VBUS
USB Data
TPS62237
ESD
5V-3.3V
Protection
DC-DC Converter
TUSB2046
Full-Speed
USB Hub
5V VBUS
USB BSL
Reset
Target Device
MSP430F5529
User LEDs and Switches
Figure 8. Block Diagram
Copyright © 2013–2014, Texas Instruments Incorporated
eZ-FET lite
Emulator
Emulator USB
MCU
Isolation
Jumper Block
32kHz
4MHz
SLAU533B – September 2013 – Revised June 2014
www.ti.com
4MHz
Submit Documentation Feedback
