MSP-EXPCC430RFx Experimenter Kit
ECCN 5A002A1A
User's Guide
Literature Number: SLAU460
November 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP-EXPCC430RF Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments MSP-EXPCC430RF Series

Summary of Contents for Texas Instruments MSP-EXPCC430RF Series

  • Page 1 MSP-EXPCC430RFx Experimenter Kit ECCN 5A002A1A User's Guide Literature Number: SLAU460 November 2012...

  • Page 2: Table Of Contents

    SimpliciTI Configuration for the MSP-EXPCC430RFx User Experience ....................5xx/6xx Core Libraries ..............MSP-EXPCC430RFx Experimenter Kit Software ......................Requirements ........................References ...................... Bills of Materials (BOM) Table of Contents SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 3 ..............MSP-EXP430F6137R9 Base Board (HW-V2.1) BOM ............MSP-EXP430F5137R9T Satellite Board (HW-V2.0) BOM ..............MSP-EXP430F6137R4 Base Board (HW-V2.1) BOM ............MSP-EXP430F5137R4T Satellite Board (HW-V2.0) BOM SLAU460 – November 2012 List of Figures Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 4: Msp-Expcc430Rfx Experimenter Kit Overview

    LCD and PC connection. Additionally, the kit also enables a complete development and prototyping environment to design a wireless application. MSP430, SimpliciTI are trademarks of Texas Instruments. All other trademarks are the property of their respective owners.

  • Page 5: Msp-Expcc430Rfx Experimenter Kit - Msp-Exp430F6137Rx Base Board (Front)

    MSP-EXPCC430RFx Experimenter Kit Overview www.ti.com Figure 1. MSP-EXPCC430RFx Experimenter Kit – MSP-EXP430F6137Rx Base Board (Front) SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 6: Msp-Expcc430Rfx Experimenter Kit - Msp-Exp430F6137Rx Base Board (Back)

    MSP-EXPCC430RFx Experimenter Kit Overview www.ti.com Figure 2. MSP-EXPCC430RFx Experimenter Kit – MSP-EXP430F6137Rx Base Board (Back) MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 7: Msp-Expcc430Rfx Experimenter Kit - Msp-Exp430F5137Rx Satellite Board (Front)

    Figure 4. MSP-EXPCC430RFx Experimenter Kit – MSP-EXP430F5137Rx Satellite Board (Back) The MSP-EXPCC430RFx Experimenter Kit is available for purchase from the TI eStore. SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 8: Kit Contents

    6. Double click on the appropriate .bat file for the version of the firmware that is required (433, 868, or 915 MHz). The MSP430 Flasher tool programs the device with this firmware. MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 9: Software Preparation

    The installer populates the folder with the source code and binaries for the kit's User Experience firmware and the PC GUI, the hardware design files, and the USB driver files. SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 10: Msp-Expcc430Rfx User Experience

    ED's information on the LCD. The exclamation mark (!) on the LCD also briefly turns on, further highlighting the Alert message to the user. MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 11: Cc430 Wireless Network Gui

    RSSI (relative distance from the AP), temperature, and remaining battery life. SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 12: Msp-Expcc430Rfx Experimenter Kit Hardware

    MSP-EXPCC430RFx Experimenter Kit Hardware MSP-EXP430F6137Rx Hardware Description Figure 5. MSP-EXP430F6137Rx Base Board Hardware MSP-EXP430F5137Rx Hardware Description Figure 6. MSP-EXP430F5137Rx Satellite Board Hardware MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 13: Schematics

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com Schematics Figure 7. MSP-EXP430F6137Rx Base Board Schematic – Page 1 SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 14: Msp-Exp430F6137Rx Base Board Schematic

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com Figure 8. MSP-EXP430F6137Rx Base Board Schematic – Page 2 MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 15: Msp-Exp430F6137Rx Base Board Schematic

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com Figure 9. MSP-EXP430F6137Rx Base Board Schematic – Page 3 SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 16: Msp-Exp430F5137Rx Satellite Board Schematic

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com Figure 10. MSP-EXP430F5137Rx Satellite Board Schematic MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 17: Pcb Layout

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com PCB Layout Figure 11. MSP-EXP430F6137Rx Base Board Layout SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 18: Msp-Exp430F5137Rx Satellite Board Layout

    MSP-EXPCC430RFx Experimenter Kit Hardware www.ti.com Figure 12. MSP-EXP430F5137Rx Satellite Board Layout MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 19: Msp-Expcc430Rfx Experimenter Kit Firmware

    Specifically they are 915-MHz band for the US, 868-MHz band for Europe, and 433-MHz for most other locations. SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 20: 5Xx/6Xx Core Libraries

    5. CC430 User's Guide (SLAU259) 6. eZ430-Chronos Wiki: http://processors.wiki.ti.com/index.php/EZ430-Chronos 7. eZ430-Chronos product folder: http://www.ti.com/tool/ez430-chronos 8. MSP430 home page: http://www.ti.com/msp430 9. SimpliciTI product page folder: http://www.ti.com/simpliciti MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 21: Bills Of Materials (Bom)

    100nF C0402 100nF C0402 ±0,25pF C0402 100nF C0402 ±0,25pF C0402 100nF C0402 100nF C0402 100nF C0402 1.5pF C0402 100nF C0402 10uF C0603 SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 22 100R R0402 33kR R0402 R0402 R0402 1.5kR R0402 6.8kR R0402 3.3kR R0402 1.5kR R0402 1.5kR R0402 100R R0402 15kR R0402 47kR R0402 MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 23 APT1608QBC/D(blu LED0603 Kingbright blue APT1608QBC/D LED2 APT1608MGC(gree LED0603 Kingbright green APT1608MGC LED3 APT1608SYCK(yello LED0603 Kingbright yellow APT1608SYCK LED4 APT1608SRCPRV(r LED0603 Kingbright APT1608SRCPRV SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 24 CON5 TFM-110-02-S-D-A- 10X2_SAMTEC_M SAMTEC TFM-110-02-S-D-A- CON6 n.m. STL_31-06 SGU STL_31-06 SGU 1,283mm x 100mm FR4, TG150, see x 120mm CC-EXP- 4306137RF9-HW- V1-PCB.pdf MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 25: Msp-Exp430F5137R9T Satellite Board (Hw-V2.0) Bom

    22-03-5035 CON4 n.m. 2x9, 2.54mm Pinhead CON5 BL31-006U 1x6, 1.27mm BL31-006U LED1 APT1608SRCPRV 0603 Kingbright ANT1 n.m. Johanson 433MHz, SMD Johanson 0433AT62A0020 SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 26: Msp-Exp430F6137R4 Base Board (Hw-V2.1) Bom

    C0402 100nF C0402 ±0,25pF C0402 100nF C0402 100nF C0402 100nF C0402 220pF C0402 specific for 433MHz var ***R4 100nF C0402 10uF C0603 MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 27 100R R0402 47kR R0402 47kR R0402 100R R0402 100R R0402 33kR R0402 R0402 R0402 1.5kR R0402 6.8kR R0402 3.3kR R0402 1.5kR R0402 SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 28 1028 LCD1 FH-1138H FH-1138H LED1 APT1608QBC/D(blue) LED0603 Kingbright blue APT1608QBC/D LED2 APT1608MGC(green) LED0603 Kingbright green APT1608MGC LED3 APT1608SYCK(yellow) LED0603 Kingbright yellow APT1608SYCK MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 29 TFM-110-02-S-D-A-K 10X2_SAMTEC_M SAMTEC TFM-110-02-S-D-A-K CON6 n.m. STL_31-06 SGU STL_31-06 SGU 1,283 mm x 100mm x FR4, TG150, see CC- 120mm, EXP-4306137RF9- HW-V2-PCB.pdf SLAU460 – November 2012 MSP-EXPCC430RFx Experimenter Kit User’s Guide Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...

  • Page 30: Msp-Exp430F5137R4T Satellite Board (Hw-V2.0) Bom

    22-03-5035 CON4 n.m. 2x9, 2.54mm Pinhead CON5 BL31-006U 1x6, 1.27mm BL31-006U LED1 APT1608SRCPRV 0603 Kingbright ANT1 0433AT62A0020 Johanson 433MHz, SMD Johanson 0433AT62A0020 MSP-EXPCC430RFx Experimenter Kit User’s Guide SLAU460 – November 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
  • Page 31 Any exceptions to this are strictly prohibited and unauthorized by Texas Instruments unless user has obtained appropriate experimental/development licenses from local regulatory authorities, which is responsibility of user including its acceptable authorization.
  • Page 32 FCC Interference Statement for Class B EVM devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 33 Also, please do not transfer this product, unless you give the same notice above to the transferee. Please note that if you could not follow the instructions above, you will be subject to penalties of Radio Law of Japan. Texas Instruments Japan Limited (address) 24-1, Nishi-Shinjuku 6 chome, Shinjuku-ku, Tokyo, Japan http://www.tij.co.jp...
  • Page 34 FDA Class III or similar classification, then you must specifically notify TI of such intent and enter into a separate Assurance and Indemnity Agreement. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2012, Texas Instruments Incorporated...
