Pulsar CAL. W440 Manual

Digital quartz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAL. W440
DIGITAL QUARTZ
Time/calendar
URL memo function
Message function
10-hour stopwatch
Countdown timer
with preset and adjustable timer functions
Regular alarm and 3-channel single-time alarm
Illuminating light (electroluminescent panel)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAL. W440 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar CAL. W440

Summary of Contents for Pulsar CAL. W440

  • Page 1 CAL. W440 DIGITAL QUARTZ Time/calendar URL memo function Message function 10-hour stopwatch Countdown timer with preset and adjustable timer functions Regular alarm and 3-channel single-time alarm Illuminating light (electroluminescent panel)

  • Page 2: Mode Change

    MODE CHANGE With each press, the mode changes in the following order: TIME/ URL MEMO MESSAGE CALENDAR ALARM TIMER STOPWATCH [vertical] [horizontal] With each press in TIME/CALENDAR mode, the display changes between horizontal and vertical alternately.

  • Page 3: Time/Calendar Mode

    TIME/CALENDAR MODE TIME/CALENDAR SETTING Clockwise turning: Digits decrease. Counterclockwise turning: Digits increase. Press for 2 to 3 seconds to show TIME/CALENDAR SETTING display. Selection of the digits Press to select the digits to be Seconds Minutes Hour adjusted. Date Turn clockwise or counter- 12-/24-hour clockwise to set the flashing digits.
  • Page 4 SHOWING CALENDAR DISPLAY Turn clockwise or counterclockwise to show CALENDAR display instead of TIME display. TURNING ON/OFF OF HOURLY TIME SIGNAL AND BUTTON OPERATION CONFIRMATION SOUND With each press, the hourly time signal and sound for button operation confirmation are alternately switched on and off.

  • Page 5: Displaying Messages

    DISPLAYING MESSAGES Press to show a message. * A message appears and scrolls three times. • If you have recorded any messages, such message alone will be displayed. • If no message is recorded, the built-in messages will be displayed one by one with each press of button E.

  • Page 6: Stopwatch Mode

    STOPWATCH MODE The stopwatch measures up to 10 hours in 1/100 second increments. Split / Split release / Reset (Press the button.) Start / Stop / Restart Split time measurement • • • • • • • START SPLIT RELEASE SPLIT STOP RESET...

  • Page 7: Timer Mode

    TIMER MODE Two types of timer are available: 10-channel preset timer and adjustable timer. The adjustable timer can be set up to 9 hours and 59 minutes in minute increments. PRESET TIMER SETTING Clockwise turning: Digits decrease. Counterclockwise turning: Digits increase. Turn clockwise or counterclockwise to select the preset time.

  • Page 8: Timer Operation

    ADJUSTABLE TIMER SETTING Turn clockwise or counterclockwise to select the adjustable timer. (See the previous page) Press for 2 to 3 seconds to show ADJUSTABLE TIMER SETTING display. Press to select the digits to be adjusted (hour/minutes). Turn clockwise or counterclockwise to set the flashing digits. Return to TIMER mode.

  • Page 9: Alarm Mode

    ALARM MODE Regular alarm and 3-channel single-time alarm are available. Each of the three single-time alarms can be set to ring only once at the designated time. As it rings, it is automatically disengaged. ALARM TIME SETTING Clockwise turning: Digits decrease. Counterclockwise turning: Digits increase.
  • Page 10 Press for 2 to 3 seconds to show ALARM SETTING display. Press to select the digits to be adjusted (hour/minutes). Turn clockwise or counterclockwise to set the flashing digits. Return to ALARM mode. * “ON” mark appears and the alarm is automatically engaged. ALARM ENGAGEMENT/DISENGAGEMENT The alarms can be engaged and disengaged independently of one another.
  • Page 11 URL MEMO MODE Up to 100 URL memos such as Internet homepage address and electronic mail address can be registered for display. Up to 60 characters can be entered for each URL memo. The residual memory capacity can also be indicated.
  • Page 12 ENTERING A NEW DATA Press for 2 to 3 seconds to show MENU display. Turn clockwise or counterclockwise to select the data entry operation (NEW). Selection of the operation Deletion of Deletion of New entry Correction ⇔ ⇔ ⇔ one data entire data EDIT While “NEW”...

  • Page 13: Correcting The Data

    CORRECTING THE DATA Turn clockwise or counterclockwise to select the data to be corrected. Press for 2 to 3 seconds to show MENU display. Turn clockwise or counterclockwise to select the data correction operation (EDIT). While “EDIT” is flashing, press to activate DATA CORRECTION function.
  • Page 14 DELETING ONE DATA Turn clockwise or counterclockwise to select the data to be deleted. Press for 2 to 3 seconds to show MENU display. Turn clockwise or counterclockwise to select the single data deletion operation (DEL). While “DEL” is flashing, press to activate SINGLE DATA DELETION function.
  • Page 15 DELETING THE ENTIRE DATA Press for 2 to 3 seconds to show MENU display. Turn clockwise or counterclockwise to select the all data clear operation (CLR). While “CLR” is flashing, press to activate ALL DATA CLEAR function. Press while “YES” is flashing. Press and hold for 4 seconds to delete all the data.
  • Page 16 DISPLAYING THE URL MEMO Selection of the URL memo Turn clockwise or counterclockwise. * With each turn, the first 16 characters of a stored URL memo are displayed. * The stored data is displayed one by one starting from the last to the first or the first to the last according to the data arrangement in memory by turning button E counterclockwise or clockwise, respectively.

  • Page 17: How To Enter Characters

    HOW TO ENTER CHARACTERS Selection of type of characters Press to select the type of characters. Katakana English English (Japanese characters) capital letters small letters Numerals and symbols Selection of characters in Japanese syllabary, alphabetical or numerical order Turn counterclockwise.
  • Page 18 Selection of characters in reverse Japanese syllabary, alphabetical or numerical order Turn clockwise. Character entry / rightward advancement of cursor Press to enter the character indicated by the cursor. Space insertion & Press at the same time. Deletion of one character &...
  • Page 19 MEMORY CAPACITY INDICATION Press to show the residual memory capacity for URL MEMO mode. * The residual memory capacity is displayed for 2 seconds, and the watch automatically returns to the display previously shown. * The watch will also return to the display previously shown by pressing button B, C or E.

  • Page 20: Message Mode

    MESSAGE MODE Up to 10 messages, each of which contains up to 60 characters, can be registered and displayed together with the date when they are to be displayed. On the designated date, the registered message scrolls on the display every 10 minutes.

  • Page 21: Notes On Using The Watch

    NOTES ON USING THE WATCH MODE CHANGE When the confirmation sound is turned on, a beep sounds with each press of button A to change over the mode. It sounds in a different tone when the TIME/CALENDAR mode appears, so that you can easily know the mode shown. Note on button E operation: To operate the watch with button E, push it, turn it clockwise or counterclockwise.
  • Page 22 minute is added and the seconds are reset to “00”. The flashing digits except the seconds and 12-/24-hour indication move quickly if button E is kept at the rightmost or leftmost position. If the watch is left untouched with the digits flashing, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes.
  • Page 23 TIMER MODE [PRESET TIMER SETTING] The selection of the preset time is made quickly if button E is kept at the rightmost or leftmost position. [ADJUSTABLE TIMER SETTING] The flashing digits move quickly if button E is kept at the rightmost or leftmost position. If the watch is left untouched with the digits flashing, it will automatically return to the TIMER mode in 2 to 3 minutes.
  • Page 24 [ALARM ENGAGEMENT/DISENGAGEMENT] When any one of the alarms is engaged, the alarm mark is displayed in the TIME/ CALENDAR mode. At the designated time, the regular alarm rings for 20 seconds as the message “Wake up!” scrolls. To stop them manually, press any one of the buttons.
  • Page 25 you have entered will not be registered in memory. Notes on correcting the data: • If the corrected data contains no character, that is, if all the characters of the data are deleted and button B is pressed, “DELETE? (YES/NO)” is displayed. After you choose “YES” or “NO”...
  • Page 26 CLR? (YES/NO)” is displayed, and press button E. The watch will return to the MENU display. • If button B is pressed while “ALL CLR? (YES/NO)” is displayed, the data will not be cleared and the watch will return to the URL MEMO mode. [DISPLAYING THE URL MEMO] When button E is turned clockwise or counterclockwise while a URL memo is scrolling, it will stop on the spot.
  • Page 27 while keeping button C pressed. Types of characters: The following characters can be used to enter the data. ア イ ウ エ オ カ キ ク ケ コ サ シ ス セ ソ タ チ ツ テ トナ ニ ヌ ネ ノ •...
  • Page 28 To protect the registered URL memos/messages from damage or loss in case of accident, malfunction, repair, loss or theft of the watch, be sure to keep data sources such as business cards or note down important URL memos/messages in a notebook or the like.

  • Page 29: Battery Change

    When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Battery life indicator When all the digits start flashing, have the battery replaced with a new one immediately.
  • Page 30 2) “SYSTEM ERROR 0” is displayed. 3) The display becomes blank. Necessary procedure after battery change After the battery is replaced with a new one, follow the procedure below to reset the IC. Press and hold buttons A, B, C and D at the same time for 2 to 3 seconds.
  • Page 31 CAUTION The battery is not rechargeable. Never attempt to recharge it, as this may cause battery leakage or damage to the battery.

  • Page 32: Troubleshooting

    TROUBLESHOOTING Trouble Cause Solution The display becomes •The battery has run Have the battery replaced with a new one blank. down. immediately by the retailer from whom the watch was purchased. “BATTERY LOW!” is •The battery nears its Have the battery replaced with a new one by the displayed or all the end.

  • Page 33: To Preserve The Quality Of Your Watch

    WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Do not operate the buttons when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 34 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...

  • Page 35: Periodic Check

    2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact.

  • Page 36: Static Electricity

    Keep the watch away read. Please contact your AUTHORIZED from close contact with objects PULSAR DEALER or SERVICE CENTER such as TV screens which emit if you wish to have a new panel fitted strong static electricity.
