Parts List - Linear Technology DC1999A Demo Manual

DEMO MANUAL DC1999A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 3 C3, C10, C12
3 2 C4, C5
4 1 C6
5 1 C7
6 1 C8
7 1 C9
8 1 C11
9 1 L1
10 1 R1
11 1 R2
12 1 R3
13 1 R4
14 1 R5
15 1 R6
16 1 R7
17 1 U1
Additional Demo Board Circuit Components
1 0 C1 (OPT)
Hardware-For Demo Board Only
1 5 E1-E5
3 2 JP1, JP2
4 2 XJP1, XJP2
5 4 STAND OFF
4
PART DESCRIPTION
CAP CER 47µF 16V 20% X5R 1210
CAP CER 1µF 16V 10% X5R 0603
CAP CER 0.1µF 16V 10% X7R 0402
CAP CER 22pF 50V 1% NP0 0402
CAP CER 1500pF 16V 10% 0402
CAP CER 47pF 50V 5% NP0 0402
CAP CER 100µF 16V 20% X5R 1210
CAP CER 100pF 50V 5% NP0 0402
INDUCTOR, 10µH
RES 845k 1/16W 1% 0402 SMD
RES 158k 1/16W 1% 0402 SMD
RES 11.5k 1/16W 1% 0402 SMD
RES 41.2k 1/16W 1% 0402 SMD
RES 1.00M 1/16W 1% 0402 SMD
RES 0402 SMD (DNP)
RES 49.9Ω 1/16W 1% 0402 SMD
15V, 1.5A SYNCHRONOUS BUCK-BOOST DC/DC CONVERTER
CAP, TANT LOW ESR 47µF 35V 20% SMD
TURRET, 0.09 DIA
JMP, 3-PIN 1 ROW 0.079CC
SHUNT, 0.079" CENTER
STAND-OFF, NYLON 0.375" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM32ER61C476ME15L
MURATA, GRM188R61C105KA93D
MURATA, GRM155R71C104KA88D
MURATA, GJM1555C1H220FB01D
AVX, 0402YC152KAT2A
MURATA, GRM1555C1H470JZ01D
TAIYO YUDEN, EMK325ABJ107MM-T
MURATA, GRM1555C1H101JA01D
COILCRAFT, XAL5050-103M
PANASONIC, ERJ-2RKF8453X
PANASONIC, ERJ-2RKF1583X
PANASONIC, ERJ-2RKF1152X
PANASONIC, ERJ-2RKF4122X
PANASONIC, ERJ-2RKF1004X
PANASONIC, ERJ-2RKF49R9X
LINEAR TECH., LTC3111EDE #PBF
AVX, TPSE476M035R0200
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
KEYSTONE, 8832 (SNAP ON)
dc1999af
